Professional vibrating linear series with low price

FOB Reference Price:Get Latest Price
US $100-9,999 / Set | 1 Set/Sets (Min. Order)
Supply Ability:
60 Set/Sets per Month
Port:
shanghai,tianjin,qingdao
Overview
Quick Details
Condition:
New
Type:
Raymond Mill
Motor Type:
AC Motor
Power(W):
50KW
Capacity(t/h):
0.6-2.6
Place of Origin:
Henan, China (Mainland)
Brand Name:
TYM
Model Number:
3R2715
Dimension(L*W*H):
18x4.6x8.6m
Weight:
10-25t
Certification:
ISO9000,CE
Warranty:
1 year
After-sales Service Provided:
Engineers available to service machinery overseas
Model:
3R2715
Roller's Number:
3,3,4,5
Roller's Diameter (mm):
270,300,320,410
Ring's Diameter (mm):
830,880,970,1280
Maximum Feed Size (mm):
15-20,15-20,20-25,<30
Finished Powder Size (mm):
0.045-0.165
Power of the Main Frame (KW):
22,30,37,75
Capacity:
0.5-20tph
Packaging & Delivery
Packaging Details
Standard 20ft or 40ft container
Delivery Time
7-15 days after getting the downpayment
Product Description
High capacity with lowest power cost. 0.5-20tons per hour with 30-425 mesh powder size adjustable.

Product details

Model3R2715
Roller's Number3,3,4,5
Roller's Diameter (mm)270,300,320,410
Ring's Diameter (mm)830,880,970,1280
Maximum Feed Size (mm)15-20,15-20,20-25,<30
Finished Powder Size (mm)0.045-0.165
Power of the Main Frame (KW)22,30,37,75
Capacity0.5-20tph
Product Keywords vibrating linear series,type roller mill grinding,pe150x250 crusher

Features:

1.Raymond Mill (grinding mill)is applicable to the grinding and processing of more than 280 kinds of non-flammable and non-explosive materials with hardness less than 7 and humidity less than 6% in mining, construction, chemical industry and metallurgy, such as bentonite,barite, calcite, feldspar, talcum, marble, limestone, clay, glass. The fineness of the finished product can be adjusted from 100 mesh to 325 mesh according to requirements.



2.Characteristic of Raymond Mill:
1)The whole machine is a vertical structure of strong systematic characteristic, so it occupies small area. From crushing of raw material to grinding and packing is an independent production system.

2)Compared with other milling plants, its passing ratio achieves 99%, this is what other mill can not reach;

3)Driving system of main frame adopts airtight gearing and pulley, drives smoothly and operates reliably,

4)Main parts of the whole plant are made from cast and steel of high quality. The technics is so subtly that insures the durability of whole plant,

 5)The electric control system is centralized controlled, so the automaticity is high, no people are needed in the operating room.



3.Working Principle:

Firstly, raw material is crushed by jaw crusher to the size required, then elevated into a hopper from which the material is transported through the electro-magnetic vibrating feeder evenly and continuously into the grinding chamber for powder-processing. The rollers oscillate outward to press the ring because of the centrifugal force and the shovel scoops up the materials, send to the middle between the ring and rollers to accomplish the grinding. After grinding, the rough materials will be recycled by the air from the fan back into the grinding chamber for regrinding and the fine powders are blew into the cyclone and poured out through the output-powder pipe as the final products.



4.Technical Data of Raymond Mill:

Model

3R2715

3R3016

4R3216

5R4121

6R4427

Roller

Number

3

3

4

5

6

Diameter (mm)

270

300

320

410

440

Height (mm)

150

160

160

210

270

Ring

Diameter (mm)

830

880

970

1280

1600

Height (mm)

150

160

160

210

270

Maximum Feed Size (mm)

15-20

15-20

20-25

<30

<35

Finished Powder Size (mm)

0.044-0.165

0.044-0.165

0.044-0.165

0.95-0.033

0.95-0.033

Power of the Main Frame (KW)

22

30

37

75

132

Fineness of Final Product
(mm)

0.125

Capacity (t/h)

2.3-2.8

0.6-1.2

3.2-4.5

6-9.5

18-22

0.075

1.8-2.3

1.9-2.6

2.4-3.1

4.5-8

10-15

0.044

0.9-1.7

1-1.9

1.8-2.5

3-5

8-10


Quality assurance:

1. Vinner is equiped with world advanced computer driving production lines
2. Whole set of pure water processor line featured with RO anti-saturation and advanced testing devices
3. Manufactured in Class 100,000 Cleanroom

Packaging & Shipping

PACKAGE:Nude or wooden box

Standard export carton packing.

DELIVERY TIME:7-15 days after downpayment

Company Information

ABOUT US

Zhengzhou General Mining Machinery Co., Ltd was founded in 2004, is a set design, production and after-sale service in one professional unit.Over the past years, with a strong technical force, advanced production technology, sophisticated processing equipment, complete testing means, high-quality product performance, first-class after-sales service
