Quality LED Spot 90 Moving Head Projector Rotating 90W Disco Stage Lighting /Gobo LED Moving Light Intelligent Control

FOB Reference Price:Get Latest Price
$187.00 - $200.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Moving Head Lights
Input Voltage(V):
AC90-240V, 50/60Hz
Lamp Power(W):
150
Lamp Luminous Flux(lm):
1234
CRI (Ra>):
85
Working Temperature(℃):
-25 - 45
Working Lifetime(Hour):
50000
IP Rating:
IP33
Certification:
CCC, CE, EMC, LVD, RoHS
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
VanGaa
Model Number:
VG-LM90CS-c2af
Emitting Color:
color wheel change
Light Source:
LED
Light sources:
1pc 90W import high brightness LED Lamp
Color:
white
Service hours:
50000h
Beam angle:
15
Optimal projection distance:
5-20m
Color wheel:
6 colors + blank
Gobo wheel:
7 gobos + blank, with gobo autorotation function
Dimmer:
linear dimmer 0-100%
Strobe:
0~10times/second, adjustable
Prism:
1pc trihedral prism, with prism autorotation function
Color Temperature(CCT):
Pure White
LED Light Source:
90W LED lamps
Lamp Luminous Efficiency(lm/w):
4356
Supply Ability
Supply Ability:
1000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Carton: 44*32*25cm(1pcs/carton)
N.W/G.W: 7kg/9kg
Port
Guangzhou
Lead Time :
3-15 days based on quantity
Product Description

Quality LED Spot 90 Moving Head Projector Rotating 90W Disco Stage Lighting /Gobo LED Moving Light Intelligent Control

mini led spot moving head light

Product Detail

Light sources1pc 90W import high brightness LED Lamp
Colorwhite
Service hours50000h
Beam angle15
Optimal projection distance5-20m
Color wheel6 colors + blank
Gobo wheel7 gobos + blank, with gobo autorotation function
Dimmerlinear dimmer 0-100%
Strobe0~10times/second, adjustable
Prism1pc trihedral prism, with prism autorotation function
Product KeywordsLed Spot 90 Moving Head Spot Projector Rotating 90W 90w Disco Stage Lighting /Gobo LED Moing Head Light,Led Moving Head Light 90w Spot light with Prism,Led Moving Head 90w Rotating Gobo Spot Stage Lights

Features:

To replace 575W traditional computer moving head light, we have researched this new style LED Moving Head Light. It has brightness light beam and clear gobo pattern effect. Using the 90W LED Lamp as the light source, power saving, super low noise of head moving, small sharp to realize fast moving. It’s your first choice for your wonderful stage.

Product Features

The luminance is 2520lux(3m), can replace the 575W traditional intelligent moving head light easily;

6 colors add white color, 1 gobo wheel has 7 different gobos;

16 DMX channels, a variety of stage effect combination, meanwhile has the prism effect;

Control panel with the digital display.

Technical Parameters

Light Source

LEDs: 1pc 90W import high brightness LED Lamp

Color: white

Service life: 50000h

Optical System

Beam angle: 15°

Optics: high precision quartz lens group, which can reduce the light loss rate to a minimum

Light Output

Optimal projection distance: 5-20m

Electromechanical Effects

Color wheel: 6 colors + blank

Gobo wheel: 7 gobos + blank, with gobo autorotation function

Dimmer: linear dimmer 0-100%

Strobe: 0~10times/second, adjustable

Prism: 1pc trihedral prism, with prism autorotation function

Movement

Pan: 540degree, 8bit/16bit adjustable, electronic error correction

Tilt: 255degree, 8bit/16bit adjustable, electronic error correction

Control and Programming

Control mode: DMX-512; Master/slave mode; Demo mode; Sound active

DMX channel: 16CH

Control panel: LCD display + 4 buttons

Thermal Specification

Maximum ambient temperature: 45 °C (113 °F)

Maximum surface temperature: 170 °C (338 °F)

Electrical Specification

Power supply: Electronic auto-ranging

Input voltage range: AC90-240V, 50/60Hz

Power consumption: 150W

Mechanical Specification

Light size: 240Dx240Wx370Hmm

Weight: 6kg

Material: ABS

Appearance color: black, white is optional

Using Environment

IP rating: IP20

Working temperature: -25-40℃

Cool system: Fan

Installation

Installation style: hanging/stand on floor/connection pieces by pieces/stand on tripods

Standard Accessories Light

1pc DMX cable

1pc power cable

1pc English version user manual

1pc clamp bridge

Optional Accessories Light

Safety cable: choose the model which you need, chargeable

Clamps: choose the model which you need, chargeable

Flight case: choose the quantity which need pack, chargeable

Package

Carton: 44*32*25cm(1pcs/carton)

N.W/G.W: 7kg/9kg

Selling Spare Parts List

Switching power supply: VG-LM90CS-P

LED lamp board: VG-LM90CS-L

Main board: VG-LM90CS-M

Drive board: VG-LM90CS-D



Quality assurance:

1. We equips high quality spare parts for this light, the quality is very good and stable;
2. The light has 1+4 years quality assurance;
3. If you have any quality request, please contact with us freely.

Packaging & Shipping

PACKAGE:

Carton board box package, or flight case package(chargeable).

DELIVERY TIME:

3-15 days after confirming order,detail delivery date should be decided according to
production season and order quantity.

Company Information

ABOUT US

VanGaa Lighting Co., Limited(Guangzhou VanGaa Lighting Technology Co., Ltd) is an internationally recognized company that specializes in energy efficient LED technology for LED Studio Light, we are always focus on the led studio light and stage light technology development and revolution.




FAQ
Q

How can I get the sample to check your quality?

A

After price confirmation, you can require for samples to check our product’s quality. Because this is the professional lighting industry, we don't provide the free samples.

Q

What can I get the price?

A

We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please tell us in your email so that we will regard you inquiry priority.

Q

What is your term of delivery?

A

We accept EXW, FOB Shenzhen or FOB Guangzhou. You can choose the one which is the most convenient or cost effective for you.


Q

What about the lead time for the mass production?

A

Honestly, it depends on the order quantity and the season you place the order.
