ROOFTOP! 1kw small wind turbine, 1kw wind generator permanent magnet generator 3 phase AC , 2.8m blades rotor, 9m/s

FOB Reference Price:Get Latest Price
$520.00 - $560.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
HLD
Model Number:
1kw
Type:
Wind Power Generator
Rated output power:
1kw
Max output power:
1.5kw
Rated wind speed:
9m/s
start up wind speed:
2m/s
Blades rotor diameter:
2.8m
Working voltage:
12v 24v 48v 120v 240v 300v 380v
Working system:
on grid system, off grid system, wind solar hybrid system
Wind turbine type:
horizontal axis, directly drive, yawing wind turbine
Generator type:
3 phase AC pma
Tower height:
6m-15m
Supply Ability
Supply Ability:
300 Set/Sets per Month
Packaging & Delivery
Packaging Details
plywood case for wind turbine main body, controller with dump load, inverter
Soft packages for tower.
Port
qingdao
Lead Time :
5
  HENRYD! 1kw small wind turbine for home use, 12v 24v off grid system, 240v 300v on grid system, wind solar hybrid system
Product Description



 1kw wind power generator is an equipment to convert wind energy into electric power which is changed into

storage battery group. It can be widely used in rich wind areas but without normal energy supply from any

power system .It is capable of providing power for lighting, TV, telecommunication equipment and so on.







Technical Data



FD2.8-1kw wind turbine Normal spec:





Model:                       FD2.8-1000W
Rotor Diameter:         2.8m
Number of Blades:      3pcs
Material of Blades:       Fibre glass expoxy
Cut-in wind speed:        2m/s
Working wind speed:    2.5-25m/s
Survival wind speed:     40m/s
Rated wind speed:      9m/s
Rated rotate speed:    350r/min
Rated output power:    1000w
Max output power:    1500w
Type of tower:              Guy wire tower
Type of generator:        Permanent-magnet 3 phrase AC
Speed regulation method:Yaw
Working voltage:         DC48V/DC24V
Operating Temperature:-60℃---+60℃
Tower height:            15m stand alone tower
Tower weight:           80kg
Wind turbine main body weight: 60kg
Measurement(CBM): 0.32cbm
Life span:WT 20 years;
Warranty:3 years after installation



FD3.2-1kw wind turbine normal spec:



Model:                       FD3.2-1000W
Rotor Diameter:         3.2m
Number of Blades:      3pcs
Material of Blades:       Fibre glass expoxy
Cut-in wind speed:        2m/s
Working wind speed:    2-25m/s
Survival wind speed:     40m/s
Rated wind speed:      8m/s
Rated rotate speed:    350r/min
Rated output power:    1000w
Max output power:    1500w
Type of tower:              Guy wire tower
Type of generator:        Permanent-magnet 3 phrase AC
Speed regulation method:Yaw
Working voltage:         DC48V/DC24V
Operating Temperature:-60℃---+60℃
Tower height:            guy wire tower 9m
Tower weight:           60kgs
Wind turbine main body weight: 61kg
Measurement(CBM): 0.32 cbm(wind turbine, controller, inverter)
Life span:15-20 years
Warranty:3 years after installation





FD2.8-1kw wind turbine output power curve:







Application:




Recommend for





• Household, Garden, farm

• Telecom sites.
• Rural electrification programs. Island , sentry, island, sight lighting





Details pictures



Wind turbine assembly:



Generator(stator and rotor, aluminum housing, front cover, back cover), rotor body, blades, hub, nose cone, tail rod, tail vane





Working system



 1. wind turbine (hybrid solar panel) off grid system:


Wind turbine with tower/solar panel with solar frame + PWM charge controller with dump load + battery group + inverter--home appliance, system as below:









Type

1KW-24Vdc

1KW-48Vdc

1KW12V

Wind turbine rated power

1KW

1KW

1KW

Wind turbine max. power

2KW

2KW

2KW

Solar panel

300Wp

300Wp

300Wp

Battery

24Vdc

48Vdc

12Vdc

Function

Rectifier,charge, control

Display mode

LCD

Display content

Wind turbine voltage, wind turbine current,

wind turbine power, solar panel voltage,

solar panel current, solar panel power, battery

 voltage, charge current

PWM constant pressure voltage

>28Vdc

>56Vdc

>14Vdc

3-phase load voltage of the wind turbine

29±1Vdc

58±1Vdc

15±1Vdc

Recovery charging voltage of the wind turbine

27±1Vdc

54±1Vdc

13.5±1Vdc

Solar stop charge voltage

29±1Vdc

58±1Vdc

15±1Vdc

Solar recovery charging voltage

<28Vdc

<56Vdc

<14Vdc

Low-voltage of the battery

20±1Vdc

40±1Vdc

10±1Vdc

Self-provided connecting wire of the battery

>8mm²

>6mm²

>16 mm²

PWM fuse

63A

25A

100A

Solar fuse

16A

10A

40A

Charging fuse

63A

32A

125A

Work environment temperature

-30-60°C

Relative humidity

<90% No condensation

Noise (1m)

<40dB

Degree of protection

IP20(Indoor)

Cooling method

Forced air cooling

*Communication interface (optional)

RS485/USB/GPRS/Ethernet

*Temperature compensation (optional)

-4mv/°C/2V,-35°C~+80°C,

Accuracy:±1°C

Size of the controller (mm)

480*360*230

480*360*230

480*360*230

Weight of the controller

12Kg

11Kg

12 Kg

Size of the load (mm)

395*300*125

395*300*125

395*300*125

Weight of the load

5.5 Kg

5 Kg

5.5Kg


2. wind turbine (hybrid solar panel) on grid system:

Wind turbine with tower/solar panel with solar frame + PWM on grid controller with dump load + grid tie inverter--home appliance/utility grid; system as below:



Power of the equipped wind turbine (W)

1.5K

Operating mode

Continuous

Function

Commutation, control

Operating environment

Temperature -30~60℃, humidity≤80%

PWM unloading voltage (DCV)

≥220V

brake voltage (DCV)

260±5V

brake delay time (min)

10-20 minutes

Low voltage indicator (V)

≤130V

Self-provided connecting wire of the brake (mm²)

>2.5mm²

Self-provided connecting wire of the PWM dump load(mm²)

>2.5mm²

PWM unloading fuse (A)

10A

DC output fuse (A)

10A



Other  fixed pitch wind turbine model list:



ModelWorking voltage
FD2.2-300WDC24V
FD2.5-500WDC24V
FD2.8-1KWDC24V/DC48V
FD3.2-1.5kwDC24V/DC48V
FD3.2-2KWDC24V/DC48V
FD3.8-2.5kwDC48V
FD4-3KWDC48v
FD4-4KWDC120v
FD5-5KWDC120v
FD8-10KWDC120V
FD8-15kwDC240
FD10-15KWDC240V
FD10-20KWDC500V
FD10-25KWDC500V
FD12-30KWDC500V

FD2.8-500WDC24V
FD3.2-1KWDC24V/DC48V
FD3.8-2KWDC24V/DC48V
FD6-5KWDC120V
FD10-10KWDC120V
FD12-20KWDC500



Packaging & Shipping

1. Wind turbine use inner foam protection outer Plywooden case .

2. Tower with Foam package only .

3. Solar panels controller invertor  with inner carton box outer plywooden case.

4.Pakage size and weight please refer to our sales.

5.Shipping  by sea with FCL LCL or by air .

If you have any request in package and shipping please tell our sales we will do according to your request.







Packing details for 1 set wind turbine main body + 1 set controller with dump load:



Item#Product descriptionSpecUnitQ'tyRemark
1main bodyFD2.8-1kw24vset1Including splitpin
hex nutM20*1.5pcs18.8 grade
flat washerφ20pcs1
hexagon boltM10*25pcs4
hexagon boltM10*80pcs4
hex nutM10pcs4
flat washerφ10pcs8
2bladesFD2.8 L=1.34mpcs6
3hubFD2.8set1
hexagon boltM12*80pcs98.8 grade
hex nutM12pcs9
flat washerφ12pcs9
elastic pinφ5*25pcs3
hexagon boltM6*20pcs38.8 grade
flat washerφ6pcs3
4nose coneFD2.8pcs1
5tail vane1kwset1
6tail rod1kwpcs1
hexagon boltM10*70pcs28.8 grade
self lock nutM10pcs2
flat washerφ10pcs2



Our Services

System Design Service ;



We cam design diffirent system for customers according their request  For example, on-grid or off-grid system , solar wind hybrid system or  solar wind  diesel generator  system  like below:



After Sale Service :



Solar panels &main parts of wind turbine are free 3 years warranty, controller and invertor are 2 years warranty.

All lifelong  technical support and part cost supply.



(1) The warranty period is start from the date of shipment which show on the bill of loading or air waybill.
(2) Free maintenance services during the warranty period the cost involved be borne by the company, do not charge a fee to customers, free warranty if any damage outside the warranty period, the company will charge a fee for labor costs and materials.
(3) the warranty period, company's quality problems caused by the maintenance of the freight borne by the company, if not under warranty or man-made damage, the freight charges by the customer.

Company Information

We started to manufacture wind turbine in 1994. In 2004, there are only 4 small wind turbine manufactures in China. We keep improving and develop in the small wind turbine field. We are not the leading small wind turbine exporter, but we are the leading wind turbine manufacture and designer now.



 We manufacture 300w-30kw fixed pitch wind turbine;



2kw, 3kw, 5kw, 10kw, 20kw, 30kw, 50kw, 60kw pitch controlled wind turbine;



1kw, 2kw, 3kw, 5kw Vertical axis wind turbine;



On grid system/off grid system, wind solar hybrid system; Water heating system;



For more details, pls contact with us via e-mail.







IEC TEST REPORT, CE CERTIFICATION, EN61400-2 CERTIFICATION



 work shop, stock, office

FAQ



1. Wind turbine model selection



It depends your local annual average wind speed, daily/monthly home power consumption.



Low average wind speed place, select larger blades rotor, higher rated working voltage;



Rich wind place select speed limited wind turbine: variable pitch wind turbine, stall out vertical axis wind turbine.



The safety and steady working system is the first choice.



2. Wind turbine tower selection



Now we have guy wire tower, stand alone tower, tilting up tower, hydraulic tower.

Guy wire tower cost is lower, easy to delivery. But the installation area is larger;



Tilting up tower is for 500w-5kw wind turbine.  Easy installation, small installation area. But the delivery cost is higher.



Hydraulic tower: It is used for no crane place. Easy installation and put down. The cost is higher.



Stand alone tower for the installation place with crane.



The tower height:  Make sure blades rotor is higher than wind turbine surrounding barrier height.



3. Working system selection



On grid system: wind turbine with tower + PWM controller with dump load + grid tie inverter;



Off grid system: wind turbine with tower + PWM charge controller with dump load + battery group + inverter;



Wind solar hybrid on/off grid system: Safety and reliable than only wind or solar system.



Wind turbine water heating system: work in rich wind place. Average wind speed higher than 8m/s.

For more question, pls contact with us directly.  We will give you a professional response.



Why select us:



We are the wind turbine designer and manufacture. We know our wind turbine advantage and disadvantage in different wind condition.



I have more than 10 years wind turbine sales experience. We provide the right wind turbine and working system to different user according to their different situation and request.

In 2004, there are 4 small wind turbine manufacture. Now there are so much trading company and manufacture, we know Chinese small wind turbine market well and can provide user more useful advise.
