SB Series Oil and Gas Slurry Pump

FOB Reference Price:Get Latest Price
US $200-2,000 / Units | 1 Unit/Units (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
SUNDREAM
Model Number:
SB
Theory:
Centrifugal Pump
Structure:
Single-stage Pump
Usage:
Oil
Power:
Electric
Standard or Nonstandard:
Standard
Fuel:
eletrical and diesel
Pressure:
High Pressure
Application:
oil industry
flow rate:
20-400m3/h
delivery head:
12-62M
power:
7.5-75kw
speed:
1450rpm
Supply Ability
Supply Ability:
40000 Ton/Tons per Year
Packaging & Delivery
Packaging Details
export plywood case
Port
SHANGHAI ,NINGBO ,QINGDAO,TIANJIN
Lead Time :
5 days per unit

Product Description

Specifications
SB drilling oil Sand Pump
1 Perfect mechanical seal
2 Pump mud for drilling oilfield
3 Durable use
4 oil well sand pump
SB series drilling oil Sand Pump
A) Caliber: DN25-DN300mm
B) Flow: 5-800m3/hr
C) Head: 12-60 m
D) Rotate speed: 1450-2900r/min
E) Motor power: 2.2-55 KW
F) Working temperature: ≤ 200° C
G) Material: Cast iron, stainless steel

2, product overview:
SB series Sand Pump is the ideal equipment to provide impetus for Desander, Desilter and Jet Mud Mixer. It can also be used as Charge Pump auxiliary perfusion for mud pump and Trip Pump for drilling well head. Centrifugal pump is also called sand pump. We considered completely the set equipment can work in excellent condition in the process of designing parameters). Most parts can be exchanged, with convenient operation and maintenance, less seal leakage, reliability, long life and other advantages.
3, main feature:
A)Open impeller, apply to transport high viscosity drilling liquid
B)Combination seal for a long service life
C)Use universal bearing houses and bearings, convenient to maintain and cut the costs
D)The major parts are made from antiwear nodular iron, and longservice life
 model flow(m3/h head(m) speed(rpm) eff(%) Npsh(m) shaft power(kw motor power(kw)
 SB2"x3"-7.5"  42   11  1480  60   2.5   2.3   4
 SB2"x3"-8"   50   14   1480  60   2.5   3.2   5.5
 SB3"x4"-9"   80   23   1480  58   2.8   8.6   11
 SB3"x4"-10"   85   25   1480  58   2.8   10   15
 SB4"x5"-9"   90   24   1480  58   2.8   10    15
 SB4"x5"-10"  100   28   1480  58   2.8   13    22
