SFX rotational head small hole edm drilling machine hot sale

Feedback Ratings
  • 1 Sets
    $2,380.00
  • 2-4 Sets
    $2,023.00
  • >=5 Sets
    $1,428.00
Quantity:
- + Sets available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
2 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Condition:
New
CNC or Not:
Normal
Drilling Speed:
1mm/min
Place of Origin:
Henan, China (Mainland)
Brand Name:
XINCHENG
Model Number:
SFX-4000
Voltage:
AC220V±10%
Power(W):
3000W
Dimension(L*W*H):
525*325*460
Weight:
26kg
Certification:
CE
Model and Size of Workhead:
DK8 300*50*50mm
Electrode Chuck Diameter:
2-13mm
Working Liquid:
Tap Water
Features:
Depth Setting, Auto Feed, Alarm and Auto Retract
Power Frequency:
50Hz
Can Remove Taps Size(mm):
M2-M36
Input power:
3000w
Input voltage:
220V/110V±10%
Package size:
528*325*460mm
Max Processing Speed:
2mm/min
After-sales Service Provided:
Overseas third-party support available

Packaging & Delivery

Selling Units:
Single item
Single package size:
52X32X46 cm
Single gross weight:
24.0 kg
Package Type:
Special carton packing. Double-layer carton filling up foam to reduce the shock force.
Picture Example:
package-img
Lead Time :
2

 SFX rotational head small hole edm drilling machine hot sale

Just to be No.1



The details show



Specification for SFX-4000B:

SFX rotational head small hole edm drilling machine hot sale

Technical Specification:



Item:

SFX-4000B

Input Voltage:

AC220V/110V±10%

Input Power(W):

3000W

Electrode Chuck Diameter(mm):

2~13mm

Working Liquid:

Tap Water

Max Processing Depth of Spindle Servo(mm):

70mm

Max Processing Speed(mm/min):

2mm/min

Gross Weight:

26kg

Adjustable Current:

Stepless Adjustment

Set Depth:

Alarm Automatically for Certain Depth

Power box size(mm):

420*220*370

Packing Size(mm):

525*325*460



Field Processing



Usage Skills

Our Services

First of allour product will have to go through a thorough quality exam process

to ensure that our devices won’t have any glitch before delivery.

Secondlythe warranty period is usually around one year and within this time

frame, if there are any technical problems,we would repair them for free including the

new parts that needed for the repair.

PS:we would offer free repair only when the damages are caused by technical

deficiencies of the product itself, not man made errors, namely, the damages were

done by mishandling the machine.



FAQ

1.Question: why our product is so cheap?

Answer: We have mass production to lower the cost, make interest to customers not

pursuing high profit from one set of machine, but chasing large quantity to make

profits.With the increase of sales, from 5 sets per time,50 sets per time,100 sets per

time to now, our company produce thousands sets of main type machine, here comes

the economic profit naturally.

2.Question: why our products’ quality are good?

Answer: Because of focus, so we are professional. We only make two kinds of machine.

1. The portable EDM machine with “remove broken taps as the main function”.
2. The hole machine whose processing object is “line cutting through the wire hole”. Our products are simple in category but easy for technology research,manufacture

and organization. Which is suitable for the micro-small entrepreneur like us. Our company has always “take the light as the heavy”, and take “make good products to move the world” as our responsibility.

3.Question: why we promote sales on line?

Answer: our quality is stable, and we can receive money when we make the product

customers receive with satisfaction! At the same time, we also hope to develop the

cheapest way of sales, and to make earning to customers!

4.Question: Why sometimes we would refuse customers’ purchasing request?

Answer: Some clients knows little of the function of our machine, we will offer a more proper processing solve solution with patience to avoid the mis-choice which would cost waste. After the clearly telling of us to customers honestly, although we lost a

sale, the thanks which customers say to us make we pleased. “Rose to others, smell

in hands”.

Contact Us

Contact Information:

Linda

Mobile/Wechat:+86-18137906716

Fax: +86-0379-69960770

Tel:+86-037963512276

Luoyang Xincheng Precision Machinery Co.,ltd
