SWQC Series 5 hp 3 Phase Salt Water Fish Pond Submersible Vortex Pump

FOB Reference Price:Get Latest Price
$70.00 - $180.00 / Sets | 1 Set/Sets (Min. Order)
Horsepower:
1~10hp
Maximum Flow Rate:
20~123m3/h
Maximum Head:
11~31m
Lead Time:
Quantity(Sets) 1 - 200 >200
Est. Time(days) 35 Negotiable
Customization:
Customized logo (Min. Order: 100 Sets)
Customized packaging (Min. Order: 100 Sets)

More

Graphic customization (Min. Order: 100 Sets) Less
Samples - $100.00 /Sets, 1 Sets (Min. Order): Buy Samples
Loading...
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Tianjin, China (Mainland)
Brand Name:
Stream
Model Number:
SWQC
Structure:
Single-stage Pump
Usage:
Water
Application:
Submersible
Power:
Electric
Fuel:
electric
Pressure:
Low Pressure
Theory:
Vortex Pump
Type of water:
clean water and sea water
Fluid temperature:
0 to 60℃
Impeller:
semi-vortex
Insulation:
class B
Phase:
single or three phase
Voltage:
110V,220-240V,380V
Cable:
3.5m
Max solid:
25mm
OEM service:
available
Supply Ability
Supply Ability:
10000 Set/Sets per Month
Packaging & Delivery
Packaging Details
packing in seaworthy cartons
Port
any port in China
Lead Time :
Quantity(Sets) 1 - 200 >200
Est. Time(days) 35 To be negotiated
Product Description





Performance Range

Max.Flow: 123m³/h
Max.Head: 31m

Application

Domestic/Commercial/Industrial use
Drainage of wastewater from individual residences
Apartment buildings, recreational developments
To transfer various wastewater and sewage

Operating Conditions

Liquid temperature up to +40°C
Ambient temperature up to +40°C
PH: 4~10
Maximum liquid density: 1.2x10³kg/m³
Max working pressure: 6 bar
Submersible depth: 0.5~5m

Motor

2 pole induction dry motor
Single-phase/Three-phase 50Hz
Insulation: Class F
Proctor: Auto-cut
With capacitor and thermal overload protection

Advantages and Features

Bearing: ball type. NSK
Stainless steel shaft extension, carbide double-sides mechanical sealing.
The SWQ-SC Series can cut up the objects.
The SWQ-C Series can select and match the water leakage festival or the flange.

More detail information,Click here



Technical Reference



More Applications



Our Services

* Sample service : we can supply as customer specify requires , and customer need take the EXPRESS cost .after received the official order , we can return the sample fee.

* Customized Service:(1) Accept OEM  (2) One year warranty from ETD  (3) Professional design team can meet  customer special requirements.

* After sale service : (1)During the warranty time, we can replace a new one .  (2) Our engineer and sales team can visit our core agent for promotion.
