Shaft drive 250/500cc quad bike atv 4x4

FOB Reference Price:Get Latest Price
US $5,500-5,900 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Fuel:
Gas / Diesel
Displacement:
>300cc
Engine Type:
4 Stroke
Transmission Type:
Automatic
Transmission System:
Shaft Drive
Certification:
ECE
Brand Name:
MG
Place of Origin:
Henan, China (Mainland)
Model Number:
JS192MG
Product Name:
Shaft drive 250/500cc quad bike atv 4x4
Engine:
4stroke Single Cylinder
Transmission:
Shaft Drive Transmission
Brake:
Hydraulic Disc Brake
Bore Stroke:
92 X 61.5mm
MAX SPEED:
95km/h
Fuel Capacity:
18L/92# 95# 98# Petrol
Starting System:
Electric Start
Transmission Mode:
Automatic CVT with H/L/N/R
Loading capacity:
250kg
SupplyAbility
SupplyAbility:
500 Set/Sets per Month High quality Quad motorcycle 460cc Shaft drive 4WD ATV for sale
Packaging & Delivery
Packaging Details
Steel frame/carton
Shaft drive 250/500cc quad bike atv 4x4
Port
Shanghai/guangzhou
Lead Time :
15days after payment

Shaft drive 250/500cc quad bike atv 4x4

Product Description



460cc 4X4 ATV Parameters

ENGINE



Engine Type

Single Cylinder, V-Twin, 4-Stroke

Engine Displacement

460cc

Bore x Stroke

92 X 61.5mm

Fuel System

Delphi Electronic Fuel Injection

Cooling System

Water-Cooled

Ignition

ECU Control Start

Max. Power Output

26.5kw/6600r/min

Max. Torque

40N.M/5500r/min

Fuel Capacity

18L/92# 95# 98# Petrol

lubricating oil model

SAE 15W-40/SF

Lubrication System

Splash & Press

Starting System

Electric Start

Transmission Mode

Automatic CVT with H/L/N/R

Final Drive

Shaft Drive 4WD

Battery

12V 10Ah

Wheels and Brakes



Tyre Front

25X8-12

Tyre Rear

25X10-12

Parking

Mechanics Parking Brake

Suspension Front / Rear

Twin-A Arm Independent Suspension

Brakes Front / Rear

Hydraulic Disc Brake

Max speed

95km/h

Dimension and Weight



Product Dimension(LxWxH)

2,300x1,150x1,400mm

Carton Dimension(LxWxH)

2,350x1,370x865mm

Seat Height

900 mm

Wheelbase

1,370mm

Ground Clearance

270mm

Dry Weight

350kg

Gross Weight

430kg

Container Loading

8 units/20'GP

26 units/40'HQ



Packing and shipping



Trading Process







Trade Terms: FOB, CIF, EXW



Payment terms : T/T, Western Union, PayPal, L/C, MoneyGram.



Payment Condition: 50%T/T deposit in advance, 50% balance before delivery



Delivery Time: 10-15 working days after deposit



Packing: One Pc/Cardboard Ctn/Mental box



Shipping: By sea, by air and by express delivery





  Welcome to inquire !
