Shenzhen OEM Smart Electronics PCB PCBA Manufacturer Multilayer Printed Circul Board

FOB Reference Price:Get Latest Price
  • 1 - 499 Pieces
    $5.00
  • 500 - 999 Pieces
    $3.00
  • >=1000 Pieces
    $2.00
Lead Time:
Quantity(Pieces) 1 - 10 11 - 1000 1001 - 10000 >10000
Est. Time(days) 7 10 14 Negotiable
Customization:
Customized logo (Min. Order: 1 Pieces)
Customized packaging (Min. Order: 1 Pieces)

More

Graphic customization (Min. Order: 1 Pieces)
PCB (Min. Order: 1 Pieces) Less
Samples - $0.20 /Pieces, 1 Pieces (Min. Order): Buy Samples
Loading...
Report Suspicious Activity
Overview
Quick Details
Supplier Type:
oem Manufacturing
Model Number:
MX757
Place of Origin:
Guangdong, China
Copper Thickness:
0.5OZ-12OZ
Board Thickness:
0.2mm-7.0mm
Min. Hole Size:
0.20mm
Min. Line Spacing:
0.003"
Material:
FR4 CEM1 CEM3 Hight TG
Surface Finishing:
HASL Lead Free, ENIG
Solder mask color:
Black.Red.Yellow.White.Blue.Green
Silkscreen color:
Black White
Shipment:
DHL UPS TNT FEDEX EMS
Certificate:
ISO9001/Iso14001/CE/ROHS
Supply Ability
Supply Ability:
1000000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Vacuum package, ESD package, Carton package, ect.
Port
FOB SHENZHEN
Picture Example:
package-img
Lead Time :
Quantity(Pieces) 1 - 10 11 - 1000 1001 - 10000 >10000
Est. Time(days) 7 10 14 To be negotiated
Video Description
Product Description

Shenzhen OEM Smart Electronics PCB PCBA Manufacturer Multilayer Printed Circul Board


21 years focus on PCBA making services included:

1) PCB manufacturing

Needed: Gerber file(main), .Pcb.Doc and KiCAD-PCB, etc.

2)Components sourcing

Needed: BOM list included detailed Part number and Designator.

3) PCB assembly

The above of PCB files and BOM lists.

Our sales & engineer teams will reply you completely PCBA Quotation within 2-12 hours.

          IOT application field PCBA with BGA Assembly

           AI control application field PCBA with Blind buried hole

 Industrial control application field PCBA with impedance

        Security control application field PCBA with laser drill

Our Company

Hua Xing PCBA Limited was founded in 1998, start up from small FPC factory in first 5 years. Until now, we have developed PCB factory, 2 PCBA factories, sales office both in SHENZHEN and USA, purchaser & engineer departments in SHENZHEN,etc.

From now on, we can provide turnkey services included PCB manufacturing,Components sourcing and PCB assembly. With professional/fast engineering suggestion, BOM list managements,very competitive price options plus assured high quality and after-sales support with trace-ability!

No MOQ required, support small Quantity production.

Support larger production volume with stable and fast delivery time, quality stability.

Help you easily achieve your electronic product.


PCB Marking

Layers: 2-58 layers

Max. Thickness: 394mil (10mm)

Material: FR-4 (Standard FR4, Mid-Tg FR4, High TG FR4, Lead free assembly material), Halogen-Free, Ceramic filled ,Teflon, Polyimide , BT, PPO, PPE, Hybrid, Partial hybrid, etc.

Min. Width/Spacing: Inner layer: 3mil/3mil (0.5OZ), Outer layer: 4mil/4mil(1OZ)

Max. Copper Thickness: UL certificated: 6.0 OZ / Pilot run: 12OZ

Min. Hole Size: Mechanical drill: 8mil(0.2mm) / Laser drill: 3mil(0.075mm)

Max. Panel Size: 1150mmx560mm

Aspect Ratio: 18:1

Surface Finish: HASL lead free,Immersion Gold, Immersion Tin, OSP, ENIG + OSP, Immersion Silver, ENEPIG, Gold Finger

Special Process

Buried Hole, Blind Hole, Embedded Resistance, Embedded Capacity, Hybrid, Partial hybrid, Partial high density, Back drilling and Resistance control.

Supply Capacity

SMT

Position accuracy: 20 um

Components size:

0.4x0.2mm(01005)-130x79mm,Flip-CHIP,QFP,BGA,POP

Max. component height: 25mm

Max. PCB size: 680x500mm

Min. PCB size: not required

PCB thickness: 0.3mm to 6mm

   Wave-Solder

   Max. PCB width: 450mm

   Min. PCB width: not required

   Component height: Top 120mm     Testing

    ICT,Probe flying,burn-in,function           test,temperature cycling
    PCB weight: 3KG

  Sweat-Solder

   Metal type: part, whole, inlay,side

   Metal material: Coppe,Aluminum

   Surface Finish: plating Au,plating

   sliver , plating Sn

   Air bladder rate: less than20%

   Press range: 0-50KN

   Max. PCB size: 800X600mm

Certifications
FAQ

1. What service can you provide?

We can provide PCB Gerber file design, Copy and Clone, OEM and ODM service.

Not only offer PCB manufacturing and Assembly service, but also customize Plastic Enclosure and Complete products.

2. Are my design files secure when I send them to you?

Your files are held in complete safety and security while Hua Xing PCBA Limited is in possession of them.

Your files are never shared with any third parties, only our colleagues have access to your design files.

Since they are your property, we respect the copyright of your files.

The customer controls the disposition of these files per your requirements and written approval.

3. For small quantity orders, can you produce prototype PCB?

Hua Xing PCBA Limited has the capability to produce circuit boards in any amount. But, the more quantity, the more you'll save.

4. Do you have an minimum order quantity ?

NO MOQ.

5. Do you have the capability of manufacturing high frequency materials?

We can manufacture these, while expensive,pls just contact us for price prior to place the order.

Cuture & Activities

Starting an Order

All customers make orders on Alibaba, named Trade Assurance Order, we'll give you 5% discount based on total amount(below 5000 dollar) for our production services.

For order amount higher than 5000 dollar in trade assurance orders, we'll provide 2% discount to customer.

Thank you so much for your support! Welcome to ask for the quote.
By Sales Department / Hua Xing PCBA Limited
