Shock price!!!!!multi-usage p10,p12,p16,p18,p20,p25 outdoor full color led sign board

FOB Reference Price:Get Latest Price
US $930-1,130 / Square Meter | 1 Set/Sets (Min. Order)
Supply Ability:
3000 Square Meter/Square Meters per Month
Port:
Shenzhen
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Lightwell--RGB A
Model Number:
LW-PH12-2R1G1B D
Usage:
Semi-outdoor/indoor/outdoor
Tube Chip Color:
red/green/blue/yellow/pink/dual/full color
Display Function:
Text,message,graphic,excel sheet,flash,video,picture,flash
Pixels:
12mm
Screen Dimension:
mini/giant,any size,3*2m,4*3m.....
Pixel pitch:
12mm(PH12mm) monitor,displayer
LED chip:
cree/epistar/silan/opto/Nichia
high waterproof:
Front:IP67/IP68 back:IP65(shockproof ,dustproof,waterproof)
installation methods:
one pillar/two pillar/hanging/rental/truck/wall mounted
Led display:
outdoor waterproof commercial advertising digit video module display
outdoor display:
advertising video led display screen/sign/panel/board/billboard
control system(box):
LINSN/colorlight,3G/GPRS/GSM/WIFI/U DISK/USB wireless system
led lamp:
346/546
Many selection:
p3/p4/p5/p6/p7.62/p8/p10/p12/p14/p16/p18/p20/p25
warranty time:
5 years
Packaging & Delivery
Packaging Details
1.Anti-shaking wooden package(plywood)
2.Air freight case
3.Anti-static carton case.
Delivery Time
3-12 working days(including testing time)

Specifications

P12 full colors advertising screen
1.Programmable digit
2.High density/bright
3.CE,ROHS,SGS,UL
4.Outdoor advertisng video

Outdoor advertising video full color led display



Display advantage and feature



1.Description

outdoor full color led display, full color led display board, full color led screen

2.Our main product:
outdoor led display and indoor led display:
advertising led display, rental led display, stage background led display,curtain led display,perimeter led screen,mobile led display, taxi top led display,scoreboard led display

3.Application:
plaza,leisure square,exoressways, entertainment square,commercial center, banks,scools,hospitals,hotel.

----------------------



1.RGB deep Gray level processing ,video synchronous display ;



2;Support multi-window flexible player and interactive software



3.No masac problem with good display performance.



4.Realible automatically products.



5.Could be repaired in the front of the screen ,repair simple .



6.Certification ;CE,ROHS,FCC,CCC,ETC.



7.Low power Consumption ,Cool quickly and prolong the life span.



8.Each pixel dot with 1red 1 green 1bule ,Total 3LED Sealed in .





Module:

Back shell
Bayer materials
Electroplating processing
-- Anti- high/low temperature(85°C/ -40°
C)
-- Anti- chemical corrosion
-- Strong & durable

PCB board
FR4 A2 material
Four-layer
-- enlarge circulation area
-- decentralizing driving current

Front mask
High-strength material,adding10% fiber
High-low temperature test & rapid aging-destructive test &anti-impact test
Streak & special oil processing
-- Three-dimensional quality
-- High level planeness
-- Distinguish presentation
-- Square hole design
-- Excellent optical performance



Structure Profile



description of design:each pixel was made up with LED of 1 Red 1Green 1Blue.

Specifications of Pixel

No.

Item

Specifications

1

Module Dimension (mm)

192mm×192mm

2

pixel pitch

12mm

3

Pixel Configuration

1 Red 1Green 1Blue

Specifications of LED

NO.

Item

wavelength

Brightness



1

Red LED

625±2.5nm

750~950mcd



2

Green LED

520±2.5nm

1900~2100mcd



3

Blue LED

465±2.5nm

390~450mcd



Specifications of Display

1

Display Dimension

Module Dimension (mm):192mm×192mm

2

Display Resolution

Module Resolution(dots):16 dots×16dots

3

Pixel density

6944 dots/m2

4

Brightness

≥7500cd/ M2

5

Scan Mode

1//4 Scan

6

viewing angle

(look left or right) 110°(look up)55°(look down)55°

7

Viewing Distance(m)

12~200m

8

gray scale

256 of each color

9

Colors

16777216 kinds

10

frame rate

≥180

11

Display Refresh Rate(Hertz)

>600HZ

12

Panel Input Format

VGA

13

display mode

1024×768 or 800×600

14

Lifespan

>100000 hours

15

Blind Spot Rate

≤0.00001

16

operating voltage

AC220V±15% 47~64HZ

17

Input Power

800W/ M2

18

Average Power

300W/ M2

19

Cabinet Weight(Kg)

<60KG/ M2

20

Control Distance

<120m

21

Operating Temperature

-20°C~60°C ,10%~90%RH











                      Find the display,Find the professional



1.P10 Module 160*160





2.P12 module 192*192





3.P16 256*128



    P16 256*256 BIG BOARD

4.P20 module 320*160

5.P25 module 200*200









6.FULL SET CABINET



 7.Display testing





8.Usage





9.PACKAGE





Display module catalog

P3 full color led module------------Size:96mm*96mm------------------32*32

P4 full color led module------------Size:128mm*128mm---------------32*32

P5 full color led module------------Size:160mm*160mm---------------32*32

P6 full color led module------------Size:192mm*96mm-----------------32*16

P7.62 full color led module--------Size:244mm*122mm---------------32*16

P8 full color led module------------Size:256mm*128mm----------------32*16

P10 full color led module-----------Size:160mm*160mm----------------16*16

P16 full color led module-----------Size:256mm*128mm-----------------16*8

P16 full color led module-----------Size:256mm*256mm-----------------16*16

P20 full color led module-----------Size:320mm*160mm-----------------16*8

P25 full color led module-----------Size:200mm*200mm------------------8*8

P31.25 full color led module-------Size:250mm*250mm------------------8*8

.................................

Our service:

1.Your inquiry related to our products or prices will be replied in 24hrs.
2.Well-trained and experienced staffs to answer all your enquires in fluent English .
3.OEM&ODM, any your customized screen we can help you to design and put into product.
4.Distributoer ship are offered for your unique design and some our current models .
5.Protection of your sales area, ideas of design and all your private information .
