Solar System Price 100KW Grid Tied Solar Power System Solar Panel System 100 KW

  • 100000-499999 Watts
    $0.53
  • 500000-999999 Watts
    $0.51
  • >=1000000 Watts
    $0.46
Solar Power (W):
100kw
System Type:
On-Grid Solar System
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
10 day(s) after payment received
Customization:
Customized logo (Min. Order: 100000 Watts)
Customized packaging (Min. Order: 100000 Watts)

More

Graphic customization (Min. Order: 1000000 Watts) Less
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
Bluesun/OEM
Model Number:
BSM100K-ON
Battery Type:
Lead-Acid
Certificate:
CE / CEC / TUV / ETL / Inmetro
Output Frequency:
50/60HZ
Application:
HOME
Work Time (h):
24 Hours
Mounting Type:
Ground Mounting, Roof Mounting, Carport Mounting, Ground / Roof mounts
Output Voltage (V):
380V/480v, EU: 220-240/380-400V US: 110/120/208/240/277/480V
Load Power (W):
100kw, No limited
Controller Type:
MPPT
Solar Panel Type:
Monocrystalline Silicon, Polycrystalline Silicon
Grid Type:
on grid solar system 100kw
Serve Life:
25 years solar panel system
Optional Part:
Storage battery
Safety Class:
Class A solar panel
Complete Set:
sun power system
Technical Support:
Yes
Installation Manual:
Yes

Packaging & Delivery

Selling Units:
Single item
Single package size:
215X12X13 cm
Single gross weight:
105.000 kg
Package Type:
In well protected carton with pallet
Picture Example:
package-img
package-img
Lead Time :
Quantity(Watts) 1 - 999999 >999999
Est. Time(days) 10 To be negotiated
Product Description

Grid-tied, on-grid, utility-interactive, grid intertie and grid back feeding are all terms used to describe the same concept – a solar system that is connected to the utility power grid.

Residential

Commercial

Industrial

Configuration detail
100KW Grid-tied Solar Power System Components List
Item
Model
Description
Quantity
1
Solar Panel
Mono 380W or Poly 355W solar panel
288 pieces
2
Grid-tied Inverter
50000W EU standard or US standard
2 pieces
3
Wi-Fi Module
Monitoring device
1 piece
4
Mounting Support
Pitched / flat roof, ground
1 set
5
Cable
Single-core PV cable
1200 meters
6
Connector
PV connector
50 pairs
7
Tools Bag
5 kinds of PV installation tools
1 bag
More details please send inquiry below

Solar Panels

> 25 years Warranty
> Highest conversion efficiency of 17%
> Anti-reflective and anti-soiling surface power
loss from dirt and dust
> Excellent mechanical load resistance
> PID Resistant,High salt and ammonia resistance

Grid-tied Inverters

> 5 years standard warranty
> Max.Efficiency 99.6%,European efficiency 99%
> Integrated DC switch for added safety protection
> Power factor continuously adjustable
>Transformer-less design and high power density,
off lighter and more convenient installation
> Flexible communication connection, support RF WIFI

Mounting support

> Residential Roof(Pitched Roof)
> Commercial Roof(Flat roof&workshop roof)
> Ground Solar Mounting system
> Vertical wall solar mounting system
> All aluminum structure solar mounting system
> Car parking solar mounting system

Accessories

> PV Cable 4mm2 6mm2 10mm2, etc

> AC Cable
> DC/AC Switches

> DC/AC Breakers
> Monitoring device
> AC/DC Combiner box

> Tools bag

Advantages of Grid-Tied Systems

1. Save more money with net metering
Your solar panels will often generate more electricity than what you are capable of consuming. With net metering, homeowners can put this excess electricity onto the utility grid instead of storing it themselves with batteries.
2. The utility grid is a virtual battery
The electric power grid is in many ways also a battery, without the need for maintenance or replacements, and with much better efficiency rates. In other words, more electricity goes to waste with conventional battery systems.

Packing & Delivery
By sea
Delivery from Shanghai or Ningbo seaport
By air
Departure from Shanghai Pudong Airport
By express
TNT / DHL
Project

250KW on grid solar project in Malta, EU

60KW on grid solar project in Guatemala, South America

1.2MW solar power plant in Ecuador, South America

144KW on grid solar project in California, USA

150KW on grid solar project in Japan

Our Company

History:

From 1983, first for silicon business, 2004 beginning produce solar cell, solar panel, capacity 50MW per year

Capacity:

Full automatic production line, all machine import from Germany. Now capacity 500MW per year

International:

400MW export to more than 80 countries, EPC company in Germany, Italy, USA and Canada

World Partner:

More than 20 famous international famous company partner in the world, solar city, Solar world, Q-Cell, Tesla...

Office&Warehouse:

More than 4 office in the world, Germany, USA, Brazil, Canada, Ukraine, Los Angeles & Rotterdam warehouse

Service:

100 international sales, English, Spain, France Language. We support all time all language service.
