Submersible type water level sensor transmitter

FOB Reference Price:Get Latest Price
$48.00 - $98.00 / Units | 1 Unit/Units (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shaanxi, China
Brand Name:
Yunyi
Model Number:
YD322-A
Model:
YD322-A
Power supply:
24VDC, 12VDC
Output:
4-20ma, 0-5v, 0-10v
Measure range:
0 - 200m
Process connection:
M20*1.5, 1/2npt, 1/4npt
Medium temp:
-20 to 80°C
Measurement object:
liquid
Accuracy:
0.5% or 0.25%
Supply Ability
Supply Ability:
1000 Unit/Units per Month
Packaging & Delivery
Packaging Details
Standard export package
Port
Any port of china
Lead Time :
About 7 days



Description Submersible type water level sensor transmitter



Submersible type water level sensor transmitter is comsed of full sealed isolation membrane filled level sensor

and special instrument circuit. With the advantages of high measuring precision, good stability, long service

life, convenient installation, etc.With unique technology of sealing structure form, and good anti-leakage performance, immersed in a liquid reliable operation for a long time.



Detailed Images submersible type water level sensor transmitter





Specification submersible type water level sensor transmitter



1).  Measurement object: liquid level of water, oil, paste
2).  Measuring range: 0 200m
3).  Output signal: 4 ~ 20mA or 0 ~ 10mA
4).  Power supply voltage: 24VDC
5).  Temperature: -20 to 80℃
6).  Index Table: user select
7).  Material: die-casting aluminum alloy shell, epoxy coating surface
8).  Diaphragm: 316 stainless steel
9).  Probe: 1Cr18Ni9Ti



Features submersible type water level sensor transmitter



1.Prevent from the surge voltage, over-voltage, over-current and the protection of reversed polarity;
2.Do the test to make sure the ability of overload resistance and shock resistance,precisely ensure the overloadcapacity;
3.Implement the electromagnetic interference resistance to avoid the problem taken place under the condition of complicated electromagnetism environment;
4.All sensitive chips are from the imported OEM parts,in order to keep the long-term stability.



Applications submersible type water level sensor transmitter



Submersible type water level sensor transmitter is mainly used for petrochemical, metallurgy, electric power, pharmaceuticals, water supply and drainage, environmental protection and other systems and industries of the liquid level measurement.



Selection Guide submersible type water level sensor transmitter



CODE

Level transmitter mode

2088T A

  Cable type

CODE

Measurement Range

1

(0-1)mH2O

2

(0-5)mH2O

3

(0-10)mH2O

4

(0-20)mH2O

5

(0-30)mH2O

T

Special specification

CODE

Accuracy grade

1

 0.2

2

 0.5

CODE

Explosion proof type

N

Standard type

i

EX iaⅡCT6

d

EX dⅡBT4

CODE

display

M0

None

M1

LCD digital display

CODE

Output

E

4~20mA

V

0-5V

S

0-10V

T

Special specification

CODE

Probe material

A1

SUS304

A2

SUS316L

CODE

Cable sheath material

B1

Polyethylene rubber

B2

PTFE

B3

Teflon

CODE

Power supply

V1

 24V DC

V2

Special specification
