Sunpal Solar Panels Monocrystalline 380W 36 Volt 380 Watt 380Wp

Feedback Ratings
  • 10-99 Pieces
    $110.20
  • 100-999 Pieces
    $102.60
  • >=1000 Pieces
    $95.00
Material:
Monocrystalline Silicon
Max. Power:
380W
Number of Cells:
72pcs
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China (Mainland)
Brand Name:
Sunpal
Model Number:
SP380M6-72
Type:
Standard Solar Panel
Size:
1960 * 992 * 40 mm
Module:
380W Monocrystalline Solar Panel
Solar Cells:
Mono 156.75 * 156.75 mm (6 inches)
Cell Orientation:
72 cells (6 * 12)
Weight:
22.5 kg (49.6 lb)
Glass:
3.2 mm (0.13 inches), High Transmission, AR Coated Tempered Glass
Backsheet:
White
Frame:
Silver / Black Anodized Aluminium Alloy
Junction Box:
IP 67 or IP 68 rated
Cables:
4.0mm2 1000 mm (39.4 inches)
Connector:
MC4

Packaging & Delivery

Selling Units:
Single item
Single package size:
196X99.2X4 cm
Single gross weight:
22.5 kg
Package Type:
carton with pallet
Lead Time :
Quantity(Piece) 1 - 1000 >1000
Est. Time(days) 7 To be negotiated
You May Like
Product Description

ELECTRICAL DATA(STC)

Module
SPxxxM6-72       xxx = Peak Power Watts
Peak Power Watts(Pmax/W)
365
370
375
380
385
Power Output Tolerance(W)
0 ~ +5
Maximum Power Voltage(Vmp/V)
38.9
39.0
39.2
39.4
39.6
Maximum Power Current(Imp/A)
9.39
9.49
9.57
9.65
9.73
Open Circuit Voltage(Voc/V)
47.6
47.7
48.0
48.3
48.5
Short Circuit Current(Isc/A)
9.94
10.04
10.11
10.19
10.26
Module Effciency(%)
18.8
19.0
19.3
19.5
19.8

STC:Irradiance 1000W/m2,Cell Temperature 25°C,Air Mass AM1.5.

*Measuring Tolerance: ±3%.

ELECTRICAL DATA(NOCT)

Module
SPxxxM6-72      xxx = Peak Power Watts
Maximum Power(Pmax/W)
269
273
277
280
284
Maximum Power Voltage(Vmp)
35.9
36.1
36.3
36.5
36.7
Maximum Power Current(Imp)
7.50
7.57
7.63
7.70
7.76
Open Circuit Voltage(Voc)
44.0
44.3
44.6
44.9
45.0
Short Circuit Current(Isc)
7.98
8.05
8.10
8.17
8.23

NOCT:Irradiance 800W/m2,Ambient Temperature 20°C,Wind Speed 1m/s.

Grade A Material

>90% Higher Transmittance EVA,Higher GEL Content To Provide Good Encapsulation And Protect Cells From Vibration With Longer Durability.

21kV High-Voltage Breakdown Test, Better Durability Withstand Fire/Dust/UV/Tear Tests For Super Isolation Back Sheet,Multi-layer Structure.

12% Ultra Clear Tempered Glass.
30% Lower Reflection

22% Higher Efficiency,5BB Cells

93 Fingers PV Cells, Anti-Pid

120N Tensile Strength Frame
110% Seal-lip Design Glue Injection
(Black/Silver Optional)

IP67 Waterproofness Junction Box
Innovative Full-Glue-Filled

4mm2 Qualified cable with MC4
500N Tensile Strength

Waterproof Labels
OEM Optional

Our Factory
Strict QC System




100% Cells Sorting

Ensure Colour and Power Difference.

Ensure high yields,consistent performance and durability,

First of 52 steps strict quality control and inspection process.




100% Inspection

Before and After Lamination.

Most stringent acceptance criteria and tightest tolerance,

Intelligent alarm and stop mechanism in case of any deviation or errors.




100% EL Testing

Before and Following Lamination
Ensure "Zero" micro crack monitoring before final inspection, Continuous line monitoring and video/photo record for each cell and panel.




100% "Zero"

Defects Objective Before Shipment.

Most stringent acceptance criteria and tightest tolerance,

Ensure the best modules on the market- guaranteed!




100% Optimal Testing

Ensure 3% Positive Power Tolerance

Comprehensive QC information management system with barcode ID.Quality traceable system in place to allow quality data flow constantly.



Professional Packing
Model
SPxxxM6-72
Modules per box
27 pieces
Modules per 40' container
648 pieces

Note: The Above packing information contained in this web is subject to change without notice. We will offer wooden box packing with extra material and labor costs if your order less than a pallet, we accept any customized packing as per your requests.

Project Cases

3.22MW Utility Scale Project in Chile. Totally 10062 Piece SP320M6-72 Solar Panels,Project Finished in April 2014.

360KW Commercial Roof Project in USA.

4.6KW Residential Solar Power System in Canada.
