Surgery electric operation table match X-ray and C-arm Function / Hospital Orthopedic Bed / Urology Surgical Instruments

FOB Reference Price:Get Latest Price
$5,000.00 - $10,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Heilongjiang, China (Mainland)
Brand Name:
HOWELL Neurosurgery Operating
Model Number:
HE-608-M
Properties:
Orthopedic Surgical Instruments
Type:
C-arm and X-ray Table Manufacturers
Tabletop Length:
2000mm
Tabletop Width:
520mm
Height Adjustment:
720mm-1020mm
Trendelenburg/Reverse Trendelenburg:
30°/35°
Lift/Right Tilt:
25°
Manual Adjustment of Head Plate(Up/Down):
30°/90°
Back Plate(Up/Down):
75°/35°
Foot Plate(Up/Down):
30°/90°
Foot Plate(Horizontal):
90°
Built-in Kidney Bridge:
0-120mm
Instrument classification:
Class I, Class II
Supply Ability
Supply Ability:
1000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Wooden Case
Port
Dalian
Lead Time :
15Working Days

 HE-608P Electrical Operating Table

Detailed Images



Product Description

------ It is the latest high-end multifunctional operating table, which adopts the most advanced microcomputer controlled and electro-hydraulic transmission system. It is unique in structure, its operation is easy, safe and reliable, and its quality has reached the international level. With its unique single- side column design which provide excellent X-ray space, it is even more suitable for the urology surgery, thoracic surgery, nephrology and those departments which utilize the C arm X-ray machine.

Advantages and charateristics:

*It applies a microcomputer control and adopts advanced electro-hydraulic drive technology instead of traditional electric pushing rod drive technology, realizing more accurate body positions as well as more uniform and smooth running speed;

*Main parts of the hydraulic system adopt imported parts, so that it is more reliable in whole performance and durable in use.

*It has complete functions and easy to be operated. The one-key horizontal table restore function makes it possible to restore the table to its transverse position quickly no matter what angle the table is positioned. With the surgical operation position memory function, if a surgical operation position has been set for the table, this position can be restored at any time.

*Two sets of independent hydraulic power sources: the hydraulic motor, hydraulic pump, microcomputer control panel and controller for the operation table are equipped with two sets of independent systems and it is possible to switch over from one system to the other.

*New material of memory foam mattress thickness if 70mm, using 30mm memory foam and 40mm high density sponge optimal combination, can release the long time operation caused by patient body and the bed surface caused by the contract pressure.

*Classical and elegant model made of high quality #304 stainless steel. Advanced model is made by aluminum alloy #304 stainless steel. Good looking, easy cleaning, anti-crash and anti-corrosion.



 Main performance and feature



 HE-608-M series including three types---Classic type,Elegant Type and High-end Type, the detail parameter as following:



Specification

HE-608-M Series Electro-hydraulic Operating Table



Classic Type

Elegant Type

High-end Type

Tabletop Length

2000 mm

2000 mm

2000 mm

Tabletop Width

520mm

520mm

520mm

Tabletop Width(with side rails)

580mm

580mm

580mm

Height Adjustment(without mattress)

720to 1020mm

720to 1020mm

720to 1020mm

Trendelenburg / Reverse trendelenburg

30° / 35°

30° / 35°

30° / 35°

Left/Right Tilt

20° / 20°

20° / 20°

20° / 20°

Manual Adustment of Head Plate(up/down)

+30° to -90°

+30° to -90°

+30° to -90°

Back section(up/down)

+75° to -35°

+75° to -35°

+75° to -35°

Leg Section(up/down)

+30° to -90°

+30° to -90°

+30° to -90°

Leg spread(Horizontal)

90°

90°

90°

One-key horizontal reset

------------

yes

yes

Storage battery function

------------

yes

yes

One-key V-shape function

------------

------------

yes

Carbon fiber tabletop

------------

------------

yes

Two set of system

One set

One set

Two sets

Electro-hydraulic adjustment

Table up/down ,Normal/reverse orientation ,Lift/right tilt ,Back plate up/down

Mechanical

Head plate, leg plate





Accessories



Standard Accessories
 PUR Mattress(for four sectional table)1 set
 Manual Controller1 piece
 Lateral Support2 pieces
 Shoulder Support2 pieces
 Arm Plate2 pieces
 Leg Holder2 pieces
 Anesthetic Screen Frame1 piece
 Joint Adapter2 pieces
Fixer (A type round)3 pieces
