UN38.3 Approved Latest Customized Crazy Sale lipo battery 602248 600mah 3.7V lithium battery for robotic sweeper with PCB

FOB Reference Price:Get Latest Price
$1.47 - $1.60 / Pieces | 500 Piece/Pieces (Min. Order)
Nominal Capacity:
10000mAh
Nominal Voltage:
3.7V
Battery Size:
lipo
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
YJ / OEM
Model Number:
YJ602248
Type:
Li-polymer
Size:
6.0*22*48mm
Certificate:
CE/RoHS/UN38.3/MSDS
Cycle life:
500-1000 Times
Warranty Time:
1-2years
Dimension:
Customized
Application:
robotic sweeper
Battery type:
Li-PO
High discharge current:
Yes
OEM/ODM:
Acceptable
PCB:
SEIKO brand (optional)
Supply Ability
Supply Ability:
1500000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
Standard Safe Packing or Customized
Port
Shenzhen / HongKong
Product Description
UN38.3 Approved Latest Customized Crazy Sale lipo battery 602248 600mah 3.7V lithium battery for robotic sweeper with PCB
Specification
Item
Rated Performance
Remark

Rated Capacity
Typical
10000mAh

Discharge at 0.2C after standard charged fully.
Minimum
9500mAh
Nominal Voltage
3.7V
Mean operation voltage during standard discharge.
Cut-off Voltage
3.0V
Discharge cut-off voltage
Charging Voltage
4.2±0.03V
/
AC (1KHz) Impedance New Cell Max.(m)
≤200mΩ
/
Standard Charge
Constant Current 0.5C

Constant Voltage 4.2V

Cut-off current 0.01C
Charge  time: Approx 4.0h.
Standard Discharge
Constant current 0.2 C

end voltage 3.0V
End voltage 3.0V
Fast Charge
Constant Current 1C

Constant Voltage 4.2V

Cut-off current 0.01C


Charge time: Approx 2.5h.
Fast Discharge
Constant current 1 C

end voltage 3.0V

/
Maximum Continuous Charge Current
1.0C
/
Maximum Continuous
Discharge Current
1.5C
/
Operation Temperature Range
Charge: 0~45C
Discharge: -20~60C
60±25%RH.

Bare Cell
Storage Temperature

Range
Less than 1 year: -20~25C
Less than 3 months: -20~40C
Less than 1 months: -30~45C
Less than 12 hour: 45~60C

/
Storage Humidity Range
60±25%RH.
/
Weight
Approx: 3g
Whole product
Product Dimension
Length: Max. 115.5mm
Width: Max. 58.5mm
Thickness: Max.11.2mm

Initial dimension
Package
Standard International transportation package, based on UN3480 PI965[RLI] Lithium lon Cells/Batteries ONLY
Electric features:
Item
Type value
Unit
Over charge detection voltage
4.28±0.03
V
Over charge detection delay time
80-200ms
ms
Over charge release voltage
4.08±0.03
V
Over discharge detection voltage
3.0±0.08
V
Over discharge detection delay time
20-60ms
ms
Over discharge release voltage
3.0±0.25
V
Over current detection voltage
150±30mv
V
Over current protection current
1.8±0.5A
A
Over current detection delay time
10-20ms
ms
Cycle life
≤500 times(≥70% 0.5C)

Main Application

Telecommunication: cellular phone, web phone, interphone, Bluetooth earphone. Portable office devices: Notebook, PDA, portable electrograph, portable printer. Video devices: GPS, digital camera, camcorder, portable DVD,  portable television, MP3, MP4. Portable exchange devices: POS, Handy, Fingerprint machine, portable stock machine. Illuminate devices: miner lamp, searchlight. Others: toys, models.

Similar products
Company Information
Certifications
Packing & Delivery
Why Choose us
Contact Details

Army Feng(Project Manager)

Mobile/Wechat: +86-13590450411

QQ: 2355930124

Alibaba ID: cn1522704373kazl

E-mail : army(@)yjbattery.com

10 years of Li-ion battery supplier

FAQ

About Guarantee

1) 12 months Manufacturer`s limited Warranty for defective items (excluding items damaged and/or misused after receipt). Accessories come with a 3-month warranty.
2) Defective items MUST BE reported and returned within the warranty period (and in the original packaging, if possible). You must tell us what the defect is and give us your order number. WE DO NOT REPAIR OR REPLACE ITEMS WITH AN EXPIRED WARRANTY.

About Sample
1)Sample Leadtime: 24 hours for stock, 10-15 days for customized batteries.
2)Sample Fee: We charge you 150% of unit price.
3)Carrier Cost: Not included


ABOUT MOQ
No MOQ requirement for our existant model. but MOQ 1000pcs for modified ones.

About Lead Time
3~5 days for stock, 15 ~35 days for customized or modified batteriers Inquiry now!
