USB 3 Tracks Stripe Smart Micro Magnetic Card Reader Writer For POS System HCC750U-06

  • 2-49 Pieces
    $20.00
  • 50-99 Pieces
    $17.00
  • 100-999 Pieces
    $16.00
  • >=1000 Pieces
    $14.00
Model Number:
HCC750U-06 (USB)
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Customization:
Customized logo (Min. Order: 500 Pieces)
Customized packaging (Min. Order: 500 Pieces)

More

Graphic customization (Min. Order: 500 Pieces) Less
Samples: $20.00 /Piece, 1 Piece (Min. Order): Buy Samples
Contact Supplier
Samples - $20.00 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China
Brand Name:
HCCTG
Interface:
USB-keyboard
Message Format:
ASCII
Card Speed:
10cm/sec. ~140cm./sec (5 ips ~55 ips)
Humidity:
10 ~ 90 % relative
Operating Temp:
-10℃ ~ +60℃
MTBF Electronics:
- 100,000 hours; Head Life - 500,000 passes
Size:
L90 *W 27.5*H 28 mm
Weight:
< 250g
Standards:
ISO/ANSI/AAMVA/CA DMV
Recording Method:
Two-frequency coherent phase (F2F)

Packaging & Delivery

Selling Units:
Single item
Single package size:
9X2.75X2.8 cm
Single gross weight:
0.25 kg
Package Type:
general package for USB 3 Tracks Stripe Smart Micro Magnetic Card Reader Writer For POS System HCC750U-06
Picture Example:
package-img
Lead Time :
Quantity(Pieces) 1 - 10 11 - 50 >50
Est. Time(days) 7 10 To be negotiated

HCC750U

USB 3 Tracks Stripe Smart Micro Magnetic Card Reader Writer For POS System

Overview

The Universal Magnetic Swipe Reader can read Track 1 & 2 or Tracks 1,2, & 3 magnetic information with a single swipe in either direction. This reader accepts both high and low coercivity magnetic cards, and can read all ISO 7811, AAMVA and California Driver's license.



Features

1.USB/RS232C/PS/2 interface; Bi-directional card reader

2.Reads credit cards, bank cards, driver's licenses and ID cards

3.All tracks are available (Tracks 1, 2 and 3)

4.Small in size, easy to handle

5.Reads low and high coercivity cards (300 to 4000 Oe)

6.LED for status

7.Watch dog



Specifications

Interface:

USB-keyboard;

PS/2

Serial

Cable connector:

   USB: standard USB

   PS/2: standard PS/2

   Serial: RS-232 DB9/ TTL 4pin

Operating:

Standards: ISO/ANSI/AAMVA/CA DMV

Recording Method: Two-frequency coherent phase (F2F)

Message Format: ASCII

Card Speed: 10cm/sec. ~140cm./sec (5 ips ~55 ips)

MTBF: Electronics - 100,000 hours; Head Life - 500,000 passes

Environment:

Operating Temp :  -10℃ ~ +60℃

Storage Temp : -20 ~ +65℃

Humidity : 10 ~ 90 % relative

Dimensions :

Size: L 90 x W 27.5 x H 28  mm

Weight: < 250g

Color: Black

Mounting : Portable or Any surface



Specifications

Interface

USB-keyboard; PS/2 ;Serial

Cable connector

USB: standard USB ;PS/2: standard PS/2 ; Serial: RS-232 DB9/ TTL 4pin

Operating

Standards: ISO/ANSI/AAMVA/CA DMV

Recording Method: Two-frequency coherent phase (F2F)

Message Format: ASCII

Card Speed: 10cm/sec. ~140cm./sec (5 I p s ~55 I p s)

MTBF: Electronics - 100,000 hours; Head Life - 500,000 passes

Environment

Operating Temp :  -10 ~ +60

Storage Temp : -20 ~ +65

Humidity : 10 ~ 90 % relative

Dimensions





Size: L 90 x W 27.5 x H 28  mm ;

Weight: < 250g ;

Color: Black

Mounting

Portable or Any surface



HCC750U-4HCC750U-3HCC750U-1HCC750U-6
