VMC650 China new used 3 axis turning cnc vertical machine center

FOB Reference Price:Get Latest Price
$10,000.00 - $18,000.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
VMC650
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
No. of Spindles:
Single
Type:
Vertical
Dimension(L*W*H):
2500*2160*2300
Weight (T):
4.5 T
Number of Axes:
3
Table Travel (X) (mm):
650
Table Travel (Z) (mm):
500
Positioning Accuracy (mm):
0.01
Repeatability (X/Y/Z) (mm):
±0.003
Spindle Motor Power(kW):
7.5
Max. Table Load(kg):
450 kg
Min. Time of Tool Change(s):
8
Tool Magazine Capacity:
16, 12, 24
Key Selling Points:
Automatic
Warranty:
1 Year
After-sales Service Provided:
Online support, Video technical support, Overseas third-party support available
Place of Origin:
Shandong, China
Brand Name:
luyoung
Certification:
ISO CE
Voltage:
220V/380V
Applicable Industries:
Machinery Repair Shops, Manufacturing Plant, Construction works
After Warranty Service:
Online support
Local Service Location:
None
Showroom Location:
None
Marketing Type:
New Product 2020
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Warranty of core components:
1 Year
Core Components:
Motor
Machine Type:
VMC650 China new used 3 axis turning cnc vertical machine center
Product type:
VMC 650 Machining Center
Spindle speed:
8000 Rpm
Spindle taper:
BT40
Work counter (long * wide):
800*400
Table load:
450kg
specification:
3*18mm
Positioning accuracy:
0.01mm
Repeat positioning accuracy:
0.003mm
Table Travel (Y) (mm):
400
Supply Ability
Supply Ability:
60 Set/Sets per Month
Packaging & Delivery
Packaging Details
1.Non-fumigation packaging, we use seaworthy plywood.
2. Steel base plate, it is stronger 3-5 times than normal plywood base plate.
3.Water-proof and damp proof, water resistant film wraped all the machine.
4.Fully sheathed case,prevention of collision and keep the goods intact.
Port
Qingdao or Shanghai
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated

VMC650 China new used 3 axis turning cnc vertical machine center

Technical parameters

Specification of vertical machining center
Item VMC550L vmc650 VMC850
Size of worktable(length×width)mm 800×300 900×400mm 1000×500
T slot (mm) 3-14-100  3-18-160 3-18-150
Max loading weight on worktable 300kg 500kg 600kg
X-Axis travel(mm) 600 700 800
Y-Axis travel(mm) 350 450 500
Z-Axis travel(mm) 450 500 500
Distance between spindle nose and table 100 -550mm 120-670mm 150-650mm
Distance between  spindle
center and column(mm)
370   460 550
Spindle taper BT40
Max. spindle speed( rpm) 8000/10000
Spindle motor power(Kw) 5.5kw  5.5/7.5kw  7.5/11
Rapid feeding speed: X,Y,Z axis 18/18/16 24/24/18mm(linear guide way) 24(linear guide way)
Fast cutting speed mm /min 5m/min 10m/min 16m/min
Positional accuracy  ±0.01 mm
Repeat positional accuracy  ±0.005 mm
Tool changer type 16 tools head type tool changer
Max. tool length 300mm
Max. Tool diameter  Φ80(adjacent tool)/φ150(not adjacent tool)
Max.tool weight 8kg
Tool changing time(tool-to-tool) 7sec
Air pressure 0.6 Mpa
Voltage /frequency   380 V 50HZ
Total capacity  10KVA
Machine weight 2700KG 4000KG 5100KG
Overall sizse(mm) 2200×1750×2300 mm 2350×2150×2250mm 2700*2250*2700
Product Description
The VMC650 vertical machining center consists of main engine, CNC system, electrical control system, automatic lubricating system, cooling system, totally enclosed protective cover, automatic chip removal device (optional) etc.The machine has the X, Y, Z three axis linkage, in a clamping can finish milling, drilling, boring, expanding continuously, hinge, such as the internal and external screw thread processing a variety of rough and finish machining process, is suitable for processing all kinds of high precision, working procedure, shape more complex parts, to provide users with complex parts processing and quick, perfect integration solutions.
The VMC650  China new used 3 axis turning cnc vertical machine center milling of feed shaft for X, Y, Z three coordinate control, three axis through the servo motor drive, can achieve for a variety of plate, plate and shell, a complex parts, such as CAM, mold clamping, complete drilling, milling, boring, expansion, reaming, tapping and other process, are suitable for many varieties, small batch parts production, for complex, high precision parts processing and more shows its superiority.
Product features

1. VMC650  China new used 3 axis turning cnc vertical machine center Adopting the world advanced numerical control system, the M60S series are servo-driven, ensuring the stability of the control system is high, the speed is fast, and the surface is smooth.
The advantages of high precision, the ability to make moulds, is the best choice for mold production.
2.VMC650  3 axis vertical machine centerAll M60S series controllers are marked with RISC64 bit CPU.
3. Coordinate display value conversion can be freely switched (program value display or manual insertion quantity display switching)
4. VMC650 Vertical machine center Standard internal carrier profile function, working position coordinates and central point measurement functions.
5. Buffer correction function extension: can correspond to IC card/computer link B/DNC/MDI mode.
6. Edit the edit mode in the edit screen, and switch to edit or edit the whole page.
7.VMC650 Graphical display function improvement: can contain the prop path information to fully display the work coordinates and the actual location of the props compensation.

Company Information

Company specializing in CNC machinery research and development in 20 years, we have good technology, and advanced team, to provide efficient service, for the ball more than 40 countries research and development, production, sales of the company.CNC lathe, CNC milling machine, machining center

Our company has independently developed a series of numerical control lathes for CK0620, CK6130 and CK6132, and has established a large number of special machine tools for many enterprises, whose products are reliable.Price discount, deeply loved by new and old customers.High-quality finished products, perfect pre-sales and after-sales service, is our company's quality purpose, is the pursuit of all employees of our company, is also the guarantee of the majority of users' trust.

1. Our customers come from more than 40 different countries and promote the most suitable products for different countries to provide the best service;

2 we participated in many exhibitions, the Chinese machinery exhibition, guangzhou commodities fair, through the exhibition to expand overseas market, we invite customers to visit our factory, also can be customized according to customer demand, through our products and services for customers

Customer feedback


Packaging & Shipping

1.Non-fumigation packaging, we use seaworthy plywood.
2. Steel base plate, it is stronger 3-5 times than normal plywood base plate.
3.Water-proof and damp proof, water resistant film wraped all the machine.
4.Fully sheathed case,prevention of collision and keep the goods intact.

Our Services

Why choose us

 1. We have excellent technology, have a professional r&d team and quality control system, manufacture and sell the most reliable and reliable technical products, and strictly control each product.Make sure the products are 100% qualified, and can be customized according to your requirements.

2 we have a solid strength, committed to the development achievements of numerical control equipment customers, innovation, honest business philosophy, through the international quality certification standards, products many times get the patent certificate.

3. We have reliable quality, strict control of quality control, high quality products and high efficiency services. We have received the approval of customers, and our price is excellent.

4 have perfect service, equipped with professional service team, perfect after-sales service team, quickly solve the problem for you.

FAQ

 How long is your warranty period?



A: our warranty period is one year, and we will maintain the product free of charge during the warranty period.Use our machines to supply standard parts and accessories during shipment.In the correct operation, if there are any damaged parts or accessories, we will replace them immediately by airmail or express mail.



What kind of packing do you have?



Answer: we use a plywood cases, to ensure the packing quality durable, fully protect the safety of the goods in the cabinet, appearance is bright and clean, smooth and beautiful, durable, has low cost, big load, afraid of sun rain no moth, etc.



How long will your delivery date be?



A: our delivery date is one month.30 days



VMC650  China new used 3 axis turning cnc vertical machine center products can be customized?



A: of course, if our product can't meet your need, tell us the model and send us the drawing, recommend suitable products to you, we can also design and produce the machine meet your requirements.



How can I contact you?



Through cell phone number and QQ, there is also email contact.
