Vertical Non-Clogging submersible Slurry Pump, solid slurry pump, Centrifugal vertical slurry pump

FOB Reference Price:Get Latest Price
US $66-1,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
YONQIU
Model Number:
NL
Theory:
Centrifugal Pump
Structure:
Single-stage Pump
Usage:
slurry
Power:
Electric
Standard or Nonstandard:
Standard
Fuel:
ELECTRIC
Pressure:
Low Pressure
Application:
Sewage
color:
blue or according to client
warranty:
one year
slurry pump OEM:
available
slurry pump MOQ:
1 set
application:
flood, river, water, sewage,wine,oil, mine, fish tank
material:
cast iron
certificate:
CE/ISO9001:2008
slurry pump Brand:
YONJOU Or OTHER
struction:
simi-open impeller centrifugal pump
slurry pump drive engine:
Electric motor
SupplyAbility
SupplyAbility:
1000 Set/Sets per Month
Packaging & Delivery
Packaging Details
standard export Plywood Case per Vertical Non-Clogging Slurry Pump,Submersible solid slurry pump,Centrifugal vertical slurry pump
Port
NINGBO
Lead Time :
5 Days according to quantity

 Vertical Non-Clogging submersible Slurry Pump, solid slurry pump, Centrifugal vertical slurry pump

Product Description





    NL sewage mud pump can be vertical or inclined to use, small footprint, volute to be buried

in a working medium, easy to start, without diversion, the rotation from the direction of the

motor tail clockwise work. The Switchboard length available in various specifications according

to the application in order to use the unit chosen according to local conditions.







Main purpose:



1, NL sewage mud pump can be used for mining, paper-making, printing and dyeing, environmental protection, graphite, mica, gold, ceramic, oil refining,

petroleum, chemical industry, farms, salt, iodine field, dyeing, brewing, food, fertilizer, coking,

 processing plant construction, marble factory, gold, mud, quicksand, mud, sewage ponds,

contaminated fluid sent thick absorption liquid filling and suspended substances in sewage

operations, but also can be used for mine drainage and fluid containing mud.



2, with high pressure water pump, water gun with a hydraulic mechanized earthmoving unit,

it can be used as in the formation of land, river and pond dredging, drilling of small water

conservancy projects of excavation and transportation side, as well as the city's air defense

projects, underground works.



3, fish used as a water-clear pond, fish pond aerator.



Technical parameters:

Performance:

Flow range: 20 m3 / h ~ 180m3 / h

Head range: 8 ~ 20m

Motor power: 1.5kw ~ 22kw





Model significance of Vertical Non-Clogging Slurry Mud Concrete Pump (NL), Slurry Pump,Submersible Slurry Pump,Centrifugal slurry Pump :

Examples: NL (C) 150 (A) -12

N ------- mud pump

L ----------- vertical

C ------- derived in line: the water stretch

150--------- caliber (mm)

A ------- improved A-mechanical seal

12----------- head (m)





Model

Speed
n
r/min
capacity
Q
m3/h
head
H
m
efficency
n
%
power
KW
pump total length
mm
pump weight
kg
NL50-8
NL50A-8
1450
20-30
-9
42
1.5
1310
63
NL50-12
NL50A-12
1450
25-38
12-14
41
3
1310
80
NL76-9
NL76A-9
1450
50-70
9-10
42
3
1350
90
NL65-16
NL65A-16
1450
50-60
15-18
42
5.5
1430
152
NL80-12
NL80A-12
1450
80-120
11-13
56
7.5
1430
145
NL100-16
NL100A-16
1450
80-100
15-17
61
15
1510
270
NL150-12
NL150A-12
1450
100-150
11-13
66
18.5
1690
350
NL150-16
NL150A-16
1450
120-180
15-20
68
22
1690
370















Packaging & Shipping

Standard plywood case









TESTING



FAQ









Company Information
