Vibrating Tumbler Swing Screen Used for PVC Grading and Separation

FOB Reference Price:Get Latest Price
$4,500.00 - $6,500.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
CWYS
Power:
2.2kw
Lead Time:
Quantity(Sets) 1 - 10 >10
Est. Time(days) 30 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, other
Local Service Location:
none
Showroom Location:
none
Video outgoing-inspection:
Provided
Machinery Test Report:
Provided
Marketing Type:
New Product 2020
Warranty of core components:
1 Year
Core Components:
Motor
Condition:
New
Type:
Circular
Application:
Food Processing
Place of Origin:
China
Brand Name:
CWJX
Voltage:
220v/280v/380v/optional
Dimension(L*W*H):
1400mm*1400mm*1600mm
Weight:
700kg
Certification:
BV SGS CE ISO
Warranty:
1 Year
After-sales Service Provided:
Online support, Video technical support, Field installation, commissioning and training
Product name:
Tumbler Swing Screen
Keyword:
Swing Screen
Material:
SUS 304
Layer(s):
3
Diameter:
1200mm
Function:
Screening\separation\sorting\sieving
Usage:
Separation Screening
power:
2.2
Frequency:
50 HZ/ 60 HZ
Capacity:
10Kg-10Tons/hour
Product Certification certification
CE Certified.
Valid from 2019-09-22 until 2024-09-22
Supply Ability
Supply Ability:
500 Set/Sets per Month
Packaging & Delivery
Packaging Details
1. The inner packaging:stretch film; outer packaging:standard export fumigation-free wooden box
2. According to customer requirements
Port
Qingdao Guangzhou Shenzhen Shanghai Ningbo Suzhou Dalian Rizhao Tianjin Yingkou
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 10 >10
Est. Time(days) 30 To be negotiated
Video Description
Product Description

 Introduce of swing screen


CWJX series tumbler screening machine is a kind of inertial equipment with mature technology and classical application.Its new design Philosophy and unique structure making it the closest manual screen machine. The Tumbler screening machine have bright application prospects for its perfect screening effect. From the aspect of its trajectory, it is a non-linear inertial vibrating screen. The Tumbler screening machine is particularly used to classify small materials and fine powder according to its unique structure and working principle. It is not only apply to dry sieving, but also wet sieving.

Working principle

The machine is drived by a unbalance motor, which is with variable eccentric weights on both sides of motor shaft, The screening time and movement of material on the screen surface can be controlled by adjusting the angle of the two eccentric weights.

Product Application

--Chemical industry: resin pigment, calcium carbonate, decorative coatings, medicine, grease, paint, palette, etc.

--Abrasive material and ceramic industry: building sand, mica, alumina, silica sand, abrasive, refractory material, slurry, etc.

--Food industry: sugar, salt, alkali, flour powder, nut powder, farina, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice, etc.

--Paper-making industry:coated slurry, exhaust liquid, paper making liquid and waste water reclamation, etc.

--Metallurgy and mining industry: quartz sand, sand, ore, titanium oxide, zinc oxide, etc.

--Mechanical industry: casting sand, charcoal, grafito, powder metallurgy, electromagnetic material and metal powder, etc

Advantage characteristic


*High effect screening:5 times output per until arear compared with vibrating screen;Up to 6 grade separation and 90%-99%
screening precision.

*Artful design: optimizing gravity isostasy; totally ciosed design, safe operation; low noise under 75db.
Using silica ball and rubber ball, ultrasonic and other high effect screen cleaning device, screen won't clog.

*Fructify and durability: accelerated speed is four or five times slower than vibrating screen, which increases thr serve life anddecreases the maintenance of screening parts.

Size information
Model
Screen mesh area  (m²)
Frequency
(r/min)
Screen
slope
(゜)
Granularity
size
(mm)
Amplitude
(mm)
Power
(kw)
CWYS-600
0.28
220-280
0-10
≤100
20-70
0.75
CWYS-1000
0.66
220-280
0-10
≤100
20-70
1.5
CWYS-1200
0.98
220-280
0-10
≤100
20-70
2.2
CWYS-1500
1.67
220-280
0-10
≤100
20-70
3.0
CWYS-1800
2.37
220-280
0-10
≤100
20-70
4.0
CWYS-2000
2.89
220-280
0-10
≤100
20-70
4.0
CWYS-2600
5.3
220-280
0-10
≤100
20-70
5.5
Detailed Images
Customizable construction deck
According to the needs of the buyer, the number of swing screen layers can be customized. At present, our factory supports the customization of one to four layer swing screen.
Customizable construction material
Stainless steel material is the first choice for medical grade and food grade buyers, carbon steel is the first choice for cost saving, contact with stainless steel can not only meet the health requirements, but also save costs.
Packing & Delivery
About us
We are direct factory of Vibrating Screen, Conveyor equipment and Mixer for many years, we are glad to build longlasting business relationship with you.
We have the enterprising and energetic team of excellence who are dedicated to their career. More than 200 staff work for us, including 65 technicians and engineers with senior title . In 2000, we established CAD workstation earlier than others in China.
Exhibition
Certifications
FAQ

Q:What factors I need to get a quotation?
A: Material size and bulk density,height of discharge port, ideal capacity for proper type is recommended. product material requirement (carbon steel Q235A, stainless steel SUS304 or SUS316,etc.) Voltage & Frequency(Hz) is also needed for a precise quotation.

 Q:What is the real delivery time of your factory?
A: 7 to 15 days for general series products, meanwhile, batches products & customized products would need 30 days to 60 days based on different situations. Q: How do you ensure the quality of your products?
A: Generally, our equipments are the most durable type in the industry, this is also the feature of the label impression of CWJX for most of our customers at home or abroad.Skilled workers and strict quality control system can ensure every machine with best working performance. Q: How do your after-sale service work if the product got damaged? A: In the guarantee time 12 months, our general after-sale service is changing the damaged parts for the customer, but if the damage could be repaired by slight cost, we would wait for the customer's bill for the fix cost and refound this part of cost.(note: Vulnerable parts do not include.) CW 1200mm 1-4 layer circular calcium carbonate zinc graphite pottery powder tumbler vibrating sieve
