Well Hydraulic Water Rotary Well Drilling Rig

$79,000.00 / Unit | 1 Unit (Min. Order)
Power(W):
60
$79,000.00
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
45 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Usage:
Oil Well
Condition:
New
Warranty:
1 year
After-sales Service Provided:
Online support, Engineers available to service machinery overseas
Place of Origin:
China
Brand Name:
ZEGA
Model Number:
ZEGA D335
Voltage:
24V/220V/380V
Weight:
3500KG
Certification:
API
Type:
Rotary Drilling Rig
Power Type:
Diesel
Dimension(L*W*H):
5,500 mm*2,035 mm*2,460 mm
Applicable Industries:
Construction works , Energy & Mining
Feed Force(Max.):
15 kN
Tramming Speed:
high 3 km/h
Traction Force( Max.):
35 kN
Ground Clearance:
450 mm
Fuel Tank Capacity:
60 L
Length:
5,500 mm
Width:
2,035 mm
Height:
2,460 mm
Weight(options excluded):
3500 kg

Packaging & Delivery

Selling Units:
Single item
Single package size:
5500X2035X2460 cm
Single gross weight:
3000.0 kg
Package Type:
Nude package for well hydraulic water rotary well drilling rig
Picture Example:
package-img
package-img
Lead Time :
Quantity(Units) 1 - 100000 >100000
Est. Time(days) 45 To be negotiated
Product Overviews

.PNG





Engine ManufacturerCumminsEngine Model4BTAA3.9-C80
Engine Rated Power60 kWEngine EmissionEuro II
F.A.D8-20 m3/minWorking Pressure7-25 Bar
Rotation Speed0-105 rpmRotary Torque1,250 Nm
Hole Diameter RangeØ90-108 mmDTH Hammer3.5 inch
Hole Depth20 mNumber of Pipes6+1
Drill pipe typeØ 60 mm (option 76 mm)Pipe Length2,000 mm
Feed TypeCylinder / ChainLength of Feed Beam4,380 mm
Feed Extension970 mmFeed Travel Length2500 mm
Feed Speed0.5 m/sPull Up Force(Max.)26 kN
Max. Climbing Ability25°Feed Force(Max.)15 kN
Tramming Speedhigh 3 km/hTraction Force( Max.)35 kN
Ground Clearance450 mmFuel Tank Capacity60 L
Length5,500 mmWidth2,035 mm
Height2,460 mmWeight(options excluded)3500 kg
