Xi'an FANGZE 9KV Surge Arrester Composite Types Of High Voltage Lightning Arrestor Price

FOB Reference Price:Get Latest Price
$10.00 - $20.00 / Pieces | 1 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 100 101 - 1000 1001 - 10000 >10000
Est. Time(days) 7 14 30 Negotiable
Customization:
Customized packaging (Min. Order: 10 Pieces)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shaanxi, China (Mainland)
Brand Name:
XCCK
Model Number:
HY5W-9, HY10W-9
Product name:
9KV Surge Arrester Composite Types Lightning Arrestor
Application:
Distribution
MOQ:
1 Piece
Color:
Gray,Red
Standard:
IEC
Packing:
Customer Requirement
Rated Voltage:
9KV
Port:
Tianjin/Shanghai
OEM Production:
accept
Trade Term:
CIF, CNF, FOB Shanghai/Tianjin Port
Supply Ability
Supply Ability:
100000 Piece/Pieces per Year
Packaging & Delivery
Packaging Details
Carton for FCL shipment / pallet for LCL shipment
Port
TIANJIN/SHANGHAI
Lead Time :
Quantity(Pieces) 1 - 100 101 - 1000 1001 - 10000 >10000
Est. Time(days) 7 14 30 To be negotiated

Xi'an FANGZE 9KV Surge Arrester Composite Types Of High Voltage Lightning Arrestor Price



OEM Service



Product Description






Normal operating conditions for Lightning Arrester:



1. The ambient air temperature is no higher than +40°C, no lower than -40 °C .

2. The altitude above sea level does not exceed 1000m. ( the plateau area should be indicated when order.)

3. AC system frequency is 50Hz or 60Hz.

4. Power frequency voltage brought to bear on arrester for a long time does not exceed the continuous operation voltage of the arrester.

5. Maximum wind speed does not exceed 35m/s.

6. Te earthquake intensity does not exceed 7 degrees.

7. The pollution area should be indicated.





Gapless Arrester Electrical Parameter

Type

Rated Voltage

MCOV

Max.Residual Viltage

2ms square wave impulse withstand current

High current impulse withstand 4/10μs

Steep current impuise1/4μS

Switching current lmpulse30/60μs

Nominal current lmpulse 8/20μs

kV

kV

kV

kV

kV

A

kV

HY5W-9

9

7.65

28.5

23.1

27.0

100

65

HY10W-9

9

7.65

28.5

23.1

27.0

250

100

Read More
