ZOOMLION 55 ton pickup truck crane ZTC550V552

$180,000.00 / Unit | 5 Units (Min. Order)
Model Number:
ZTC550V552
$180,000.00
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
30 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Max. Lifting Height:
58m
Feature:
Truck Crane
Condition:
New
Place of Origin:
Hunan, China
Brand Name:
ZOOMLION
Certification:
CE/ISO9001
Application:
Construction
Rated Loading Capacity:
55t
Rated Lifting Moment:
2009kN.m
Max. Lifting Load:
55ton
Span:
5.92
Min. ground clearance mm:
260
Color:
Black
Max. gradeability %:
40
Max. traveling speed km/h:
76
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1 Year

Packaging & Delivery

Selling Units:
Single item
Single package size:
14000X2800X3800 cm
Single gross weight:
42000.0 kg
Package Type:
Nude packing by RORO shipment;
Lead Time :
Quantity(Units) 1 - 5 >5
Est. Time(days) 30 To be negotiated
Product Description



55t lifting ZOOMLION crane QY55D531.1 price



Feature

• Continuously overall promotion makes our lifting capacity of crane be improved once and once again.
• 43 m main boom , two section jibs (9.5m ,16m).
• Optimized central slewing position increases the lifting capacity of the crane over rear.
• Large outrigger span improves the working stability of the crane greatly,
• Adopt internationally advanced structure analysis and calculation methods to develop the lifting capacity of crane deeply.
• Leading boom manufacturing process in trade.



Parameters

Working performanceMax. rated lifting capacitykg55000
Max. load moment of basic boomkN.m2009
Max. load moment of main boom(fully extended)kN.m1050
Max. load moment of basic boomm12.6
Max. lifting height of main boomm43.6These parameters do not include deflection of main boom and jib
Max. lifting height of jibm58
Working speeds    Max. hoist rope speed(Main winch)m/min120
Max. hoist rope speed(Auxiliary winch)m/min120
Boom demrricking up times50
Boom demrricking up times95
Slewing  speedr/min0-2.2
Driving parametersMax. height above sea levelm2000
Max. driving  speedkm/h76
Max. gradeability%40
Min. turning diameterm≤24
Min.  ground clearancemm260
Oil consumption per hundred kilometersL43
MassDeadweight in driving conditionkg42000
Complete vehicle kerb masskg41870
Front axle loadkg16000
Rear axle loadkg26000
DimensionsOverall dimensions(L×W×H)mm13700×2800×3800
Outrigger spread(L)m5.92
Outrigger spread(W)mFully extended:7.1,intermediately extended:4.8
Tail slewing radiusmm3900
Main boom lengthm11.4 - 43.0
Boom angle°-2 - 80
jib lengthm9.2,14.6Low-mounted, open-type
Offset°5,25,45
