ac dc power supply 48v 1250mA 60w for LED Lighting

Feedback Ratings
  • 120-239 Pieces
    $2.50
  • 240-359 Pieces
    $2.49
  • 360-999 Pieces
    $2.48
  • >=1000 Pieces
    $2.45
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Customization:
Customized logo (Min. Order: 1000 Pieces)
Customized packaging (Min. Order: 2000 Pieces)

More

Graphic customization (Min. Order: 1000 Pieces) Less
Contact Supplier
Samples - $7.72 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
NRSky
Model Number:
NRN-12-60
Output Power:
60W
Output Type:
Single
Input Voltage:
100-265V
Output Voltage:
12V/DC
Output Frequency:
47-63Hz
Output Current:
5A
Protections:
Short Circuit/Over voltage/Overload/Over-Temperature
Efficiency:
87%
Size:
110*78*35
Weight:
0.17kg
Certificates:
CE ROHS
Application:
LED related products
Warranty:
3 Years
IP Grade:
IP20
Packing:
40pcs/CTN
Wattage:
60W

Packaging & Delivery

Selling Units:
Single item
Single package size:
12X8X4 cm
Single gross weight:
0.19 kg
Package Type:
1pc in a gift box, 120pcs in a carton
Lead Time :
Quantity(Piece) 1 - 100 101 - 1000 >1000
Est. Time(days) 3 7 To be negotiated
Product Description
SPECIFICATIONS FOR NRC-12-150
Item No.
NRC-12-150
Dimension
200*958*37mm
Net Weight
0.39kg
Packing
40pcs/CTN
INPUT
Voltage Range
100-240V/AC
Frequency Range
50~60Hz
AC Current
0.12A/175V 0.1A/230V
Leakage Current
0.5mA/240V/AC
OUTPUT
Output Voltage
12V±0.5%
Rated Current
12.5A
Rated Power
150W
Current Range
0~12.5A
Voltage Tolerance
±0.5%
Line Regulation
±0.5%
Hold Up Time(Typ)
50ms/230VAC 16ms/115VAC at full load
Efficiency
≥87%
PROTECTION
Over Current
105~150% Rated output power
Protection Type: Hiccup Mode, recovers automatically after fault condition is removed.
Over Voltage
13.8~16.2V
Protection Type: Shut down o/p voltage, re-power onto recover.
Short Circuit
Auto Recover
Protection Grade
IP20
ENVIRONMENT
Working Temp
-20~40℃ refer to output load derating curve
Working Humidity
20~95% RH-Nondensing
Storage Temp
-40~85℃
Storage Humidity
10~95% RH
Temp Coefficient
±0.03%/℃(0~50℃)
Warranty
3 Years
Vibration Frequency
10~500Hz, 2G 10 min/1 circle, period of 60 min, each long X, Y, Z axes.

Main Features

1) 100% full load aging test.

2) Conform safety standard and EMC.

3) Wide input voltage suitable for all the countries .

4) We support OEM/ODM.

5) Built-in EMI filter, very low ripple.
