arduino 4 Axis mach3 Cnc Controller Kit for Milling Machine

No reviews yet

Shenzhen Scotle Technology Ltd.18 yrs

arduino 4 Axis mach3 Cnc Controller Kit for Milling Machine

Service

Free replacement parts

View details

Key attributes

no. of spindles

Single Phase

machinery test report

Provided

number of axes

core components

Bearing, motor, Pump, Other

warranty

1 Year

voltage

220V/110V

video outgoing-inspection

Provided

cnc or not

CNC

machine type

CNC Router

key selling points

Easy to Operate

working table size(mm)

300×400

power (kw)

0.5

weight (kg)

range of spindle speed(r.p.m)

1 - 11000 rpm

positioning accuracy (mm)

0.03 mm

travel (x axis)(mm)

280 mm

travel (y axis)(mm)

375 mm

repeatability (x/y/z) (mm)

0.03 mm

Spindle Motor Power (kw)

0.5

place of origin

Guangdong, China

brand name

Chinacnczone

dimension(l*w*h)

615x480x390mm

After-sales Service Provided

Engineers available to service machinery overseas

Rack material

6061 and 6063 Hard aluminum alloy

Engraving area

280*375mm

Z-Axis Stroke

55mm, Engraving depth depends on the length of the tool edge)

Acceptable material thickness

≤75mm

Rail type

Chromeplate shaft+Linear Bearings,)(Surface hardening 61HRC)

Type of screw

Ball screw,Pitch 4mm

Spindle motor

500W/11000r/min

Spindle Collet type

ER11,1/8"(3.175mm) Collet

Stepper motor and drive

two-phase hybrid stepping motor , 1.8A/PHASE,40N.cm, 8 segments drive.

Packaging and delivery

Selling Units

Single item

Single package size

61X53X42 cm

Single gross weight

30.000 KG

Lead time

Customization options

Customized logo (Min. order: 20 sets)

Customized packaging (Min. order: 20 sets)

Graphic customization (Min. order: 20 sets)

View details

Product descriptions from the supplier

Warning/Disclaimer

California Proposition 65 Consumer WarningView more

This product has acquired the relevant product qualification(s)/license(s) of certain applicable country/countries.View more

FREE shipping capped at $20 on your first order

Minimum order quantity: 1 set

$520-680

Sample price: $520

*Taxes and import charges will be calculated at checkout

Variations

Select now

Shipping

Dropship this product to your store

···

4 interest-free payments with

Protections for this product

Delivery via

Expect your order to be delivered before scheduled dates or receive a 10% delay compensation

Secure payments

Every payment you make on Alibaba.com is secured with strict SSL encryption and PCI DSS data protection protocols

Standard refund policy

Claim a refund if your order doesn't ship, is missing, or arrives with product issues

1-year warranty

Access to free parts replacement and repair coverage

Quantity (sets)	1 - 1	> 1
Lead time (days)	3	To be negotiated
