china machinary for small business 1410 laser cutting engraving machine for plywood

FOB Reference Price:Get Latest Price
$3,300.00 - $4,500.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
LT-1410
Power(W):
90w
Report Suspicious Activity
Overview
Quick Details
After-sales Service Provided:
Video technical support, Engineers available to service machinery overseas
Applicable Material:
Acrylic
Laser Type:
CO2
Cutting Area:
1400*1000mm
Cutting Speed:
600mm/s
Graphic Format Supported:
AI
Application:
Laser Cutting
Condition:
New
Cutting Thickness:
0-30mm
CNC or Not:
Yes
Cooling Mode:
Water Cooling
Control Software:
Leetro
Place of Origin:
Shandong, China (Mainland)
Brand Name:
Lintianzhiyuan
Certification:
CE
Warranty:
2 Years
Machine model:
LT-1410
Laser power:
90W/100w/130w/150w
Laser type:
Sealed CO2 laser tube, wavelength: 10.64μm
Cooling mode:
Circulating water cooling
Laser power control:
0-100% software control
Control system:
Leetro control system
Max. engraving speed:
60000mm/min
Max cutting speed:
36000mm/min
Repetition accuracy:
0.01mm
Supply Ability
Supply Ability:
200 Set/Sets per Month
Packaging & Delivery
Packaging Details
plywood case with water-proof materials
Port
Qingdao, Ningbo, Tianjing



Product Description

 Features

1) working area:1400*1000mm, could be changed and designed by our professional design team

2)Internationally advanced accessories: Taiwan square linear rails, high quality stepper motor, focus lens,

3) special design for thick and heavy materials: lower but heavy load-bearing worktable, two laser heads

with different length and focus distance

4) high precision guarantee

5) perfect after-sale service and high quality make sure customer use machine well.

6) most reasonable price make customer could accept it.



Technical Parameters

Model

LT-1410 laser cutting machine

Working area

1400* 1000mm

Laser tube power

90-100w Reci laser tube

Max. engraving speed

1000mm/s

Max. cutting speed

600mm/s

Laser type

CO2 laser tube RECI/EFR

Life time of laser tube

8000~10000hours

Work table

Electric up and down, Honeycomb table

Min. forming character

1*1mm

Max. scanning precision

0.0254mm

Positioning precision

0.01mm

Laser tube cooling

Water cooling

Power supply

220V/380V, 50Hz-60Hz

Drivers and motors

 Leadshine drivers M583 and stepper motor 450A

Control system

Leetro control system 6585

Guide rail

Hiwin linear square guide rail

Tranmision

Shanghai Fulong belt

Software included

Laser cut 6.1

Design software

CorelDraw, AutoCAD (compatible), Photoshop

Picture format supported

PLT, DXF, BMP, AI (direct), JPG, GIF, PGN, TIF (conversion)

360° slope engrave

Yes

Communication interface

USB

Operating system

Windows98/2000/XP/VISTA/7

Engrave curve surface

< 1.5mm

Cooler

Water pump

Certificate

CE, FDA

Dimension

1950*1420*1110mm

Optional parts

  1. Up and down platform
  2. 2. Rotary attachment
  3. 3. Auto focus 4.
  4. Honeycomb table

























Applied materials

a. stone: marble,granite, white marble etc.

b.art crafts: wood,bamboo,elephant's tusk,bone,leather,marble,sea shell etc.

c. advertisement:double color board,acrylic engraving and cutting,label engraving,crystal etc.

d. model industry:sand table construction model,plane model etc.

e. packing:rubber engraving,plastic,doubling plate,die board cutting etc.

f. leather and cloth process:compound leather,man-made leather,fabric,fur ,toy etc.

g. other industry : marble,granite,glass,crystal engraving,paper/greeting card cutting etc.







Packaging & Shipping

















































































Our Services

1,Two year warranty time, we can repair and replace parts for free in one year.
2,Technical support in 24 hours online, TM, Skype, E-mail, solving the relative questions in time.
3,Life time free maintenance service.
4,Free training course at our factory with professional engineers.
5,We provide the consumable parts at agent price when you need replacement.
FAQ

Please let us know following information:


1.What kind of material do you want to cut?

2.What is the mostly used thickness and what is the maximum thickness?

3. What is the MAX dimension of your materials ?

4. After cut, what will be the metal used for? (application)

5. Are you an end user or reseller?

According to your above information,we'll recommend the most suitable machine to you.

                        Looking forward to become cooperative partner
