china vfd manufacturers 5 kw vfd ac inverter

FOB Reference Price:Get Latest Price
  • 5 - 29 Pieces
    $1,100.00
  • >=30 Pieces
    $1,000.00
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
OEM or MUST
Model Number:
PV3500
Output Power:
1 - 200KW
Output Type:
Single
Size:
700*485*325mm
Weight:
25kg-100kg
Input Voltage:
12V/24V/48V
Output Voltage:
110V/220V/230V/240V
Type:
DC/AC Inverters
Output Frequency:
50Hz/60Hz
Output Current:
45A~120A
Output waveform:
pure sine wave
Rated power:
4KW--12KW
Surge power:
3*rated Start Power
Battery Voltage:
24V/48V DC
RS485:
Yes
Max PV charge current:
120A optional
Frequency:
50Hz/60HZ Auto
Display:
LED+LCD
Color:
silver red green
Warranty:
12 Months
Supply Ability
Supply Ability:
8000 Piece/Pieces per Month china vfd manufacturers 5 kw vfd ac inverter
Packaging & Delivery
Packaging Details
1pc/carton
with wooden package outside for china vfd manufacturers 5 kw vfd ac inverter
Shipping weight: 96kg
Net weight: 75kg
Port
Shenzhen
Lead Time :
Shipped in 25 days after payment

china vfd manufacturers 5 kw vfd ac inverter

Model: PV3500  12KW

Main Features:

* Low frequency pure sine wave output

* power range 4kw-12kw

* inbuilt 60A or 120A MPPT solar charge controller

* RS485 with free CD

* 50Hz/ 60Hz auto sensing

* automatically send signal to start generator

* inbuilt pure copper transformer







Product Description

Part One: Product Showcase of Air Condition Single Phase DC 48V 8KW Solar Power Inverter



1) with RS485 communication port, so that you can collect all the inverter datas through your computer



  2Three colors for your choice: Silver, red, and green





 3) Connection& Diagram: Hybrid one, can connect with both PV and utility



4) Details display:



Back terminal: battery connection terminal, battery temperature terminal, AC circuit breaker &switch, remote control port, PV in terminal, AC in terminal, earthing terminal





Top Setting button: can adjust the charge current, select the battery type, and set operation mode, such as PV priority mode, AC priority mode, PV&AC combined mode.





Part Two: Wanna Know the Specification of Air Condition Single Phase DC 48V   12KW Solar Power Inverter?



MODELPV35-5KPV35-6KPV35-7500PV35-10KPV35-12.5KPV35-15K
Default Battery System Voltage24VDC48VDC24VDC48VDC24VDC48VDC48VDC48VDC48VDC
INVERTER OUTPUTContinuous output power5KVA/4.0KW8KVA/4.8KW7.5KVA/6.0KW10KVA/8.0KW12.5KVA/10.0KW15KVA/12.0KW
Surge rating (20ms)12.0KW15.0KW18.0KW24.0KW30.0KW36.0KW
Capable of starting electric motor2HP3HP3HP4HP5HP6HP
Output waveformPure sine wave/ same as input (bypass mode)
Inverter efficiency (Peak)>88%
Line mode efficiency>95%
Power factor0.8
Nominal output voltage RMS220V/230V/240VAC(+/-10% RMS)
Output frequency50Hz/60Hz +/-0.3 Hz
Short circuit protectionYes(1sec after fault)
Typical transfer time10ms(max)
AC INPUTVoltage230VAC
Selectable voltage range155~280VAC(For Personal Computers)
Frequency range50Hz/60Hz (Auto sensing) 40-80Hz
BATTERYMinimum start voltage20.0VDC/21.0VDC for 24VDC mode (40.0VDC/42.0VDC for 48VDC mode)
Low battery alarm21.0VDC+/-0.3V for 24VDC mode (42.0VDC+/-0.6V for 48VDC mode)
Low battery cutoff20.0VDC+/-0.3V for 24VDC mode (40.0VDC+/-0.6V for 48VDC mode)
High voltage alarm32.0VDC+/-0.3V for24VDC mode (64.0VDC+/-0.6V for 48VDC mode)
High battery voltage recover31.0VDC+/-0.3V for 24VDC mode (62.0VDC+/-0.6V for 48VDC mode)
Idle Consumption-Search Mode<25W when power saver on
AC CHARGEROutput VoltageDepends on battery type
Charger AC Input Breaker Rating30A30A30A40A50A63A
Max charge power rating1/3 Rating power
Overcharge Protection S.D.31.4VDC for 24VDC mode(62.8VDC for 48VDC mode)
Maximum Charge Current65A35A65A40A65A50A70A80A100A
BTSContinuous Output PowerYes Variances in charging voltage & S.D. voltage base on the battery temperature
BYPASS & PROTECTIONInput Voltage WaveformSine wave (grid or generator)
Nominal voltage220V/230V/240VAC
Max input AC voltage300VAC for 230VAC HV mode
Nominal input frequency50Hz or 60Hz
Overload Protection (SMPS Load)Circuit breaker
Output Short Circuit ProtectionCircuit breaker
Bypass Breaker Rating40A40A40A50A63A63A
Max Bypass Current40Amp80Amp
Rated voltage24VDC/48VDC
PV open circuit voltageOperational max =145VDC temperature corrected VOC
SOLAR CHARGERMaximum PV Charge Current60A60A(120A Optional)
DC Voltage24V/48V atuo work48V
Maximum PV Array Power1600W3200W1600W3200W1600W3200W3200W(6400W for 120A Optional)
MPPT Range @ Operating Voltage(VDC)32-145VDC FOR 24V mode, 64-145V for 48V mode64-145VDC
Maximum PV Array Open Circuit Voltage147VDC147VDC
Maximum Efficiency>98%
Standby Power Consumption<2W
MECHANICAL SPECIFICATIONSMountingWall mount
Dimensions (W*H*D)414*575*211mm414*645*211mm
Net Weight (Solar CHG) kg38+2.548+2.549+2.560+2.566+2.570+2.5
Shipping Dimensions(W*H*D)505*701*330mm505*771*330mm
Shipping Weight (Solar CHG) kg40+2.550+2.551+2.562+2.568+2.572+2.5
OTHEROperation Temperature Range0°C to 40°C
Storage Temperature-15°C to 60°C
Audible Noise60dB MAX
DisplayLED+LCD
Loading(20GP/40GP/40HQ)140pcs/280pcs/320pcs





 Service:



Trade Assurance----You will get refund up to 100% Trade Assurance Order amount if the goods is not shipped on time or does not meet the quality requirements



24 hours Online----You will get my quotation and response within 24hours



12 months warranty----You will get the spare parts and maintaince guides if any break dowm



Available spare parts----You will get the spare parts for after-sale service



After-sale service----You will be servised by the professional after-sale service center if any problems



To be regular clients or Agents of MUST----You will get the beautiful gifts and many Preferencial Policy



24 Hours After-service consultancy just for you and to make your problems to solve easily.
(Hedy  Whatsapp:+86 15118135723)



Company Information

Brief Introduction of  MUST Power Limited & Revenue





Full CE Approval& Golden Supplier of Alibaba



Testing Machine&Aging room& Production line

All together there is 8 production lines, and there is quality testing amchine at the end of each line so that we could control the quality very well.



Aging Room: every procuct will be placed in the againg room to test at least 4hours, and the engineers and employees of MUST will change the working mode during this time.





MUST Power Show Room Viewing







Packaging & Shipping



Packing:

1pc/carton
with wooden package outside
Packing size: 890*620*415mm
Shipping weight: 96kg
Net weight: 75kg

Shipping:

For samples, like 1-3pcs, you'd better choose the air shipping; for bulk order, you can shoose by air, by express, or by sea.



Our Services



Good News:



Place order via Trade Assurance

You will get:

1) 100% money refund for quality problems or late shipment

2) You will get refund up to 100% trade assurance amount if the goods is not shipped online

3) You can pay by your credit card.

Samples are Available for Testing and Market Test. OEM is warm welcomed.

1-Year Warranty on MUST POWER Products

Guides and After-sell service Consultancy

Must Power Team will offer these guides below.

  A. Need Accessories

  B. Products Repair and maintainence

  C. Power Problems to Solve

  D. Power Protection Solutions, etc.

24 Hours After-service consultancy just for you and to make your problems solved easily.

MUST Professional International Sales Team Show
FAQ



1.Q: Can I have sample before formal order?

     A: Sure, it will be warm welcomed.



2. Q: What's the warranty:

    A: 12 months.



3. Q: What's the payment methods?

    A: Usually we accept T/T  (Telegraphic Transfer), and Western Union.



4. Q: OEM is available?

    A: Yes, OEM is welcomed.



Welcome to contact me freely.
