export to india galvanized steel coil z275

FOB Reference Price:Get Latest Price
$600.00 - $1,000.00 / Metric Tons | 25 Metric Ton/Metric Tons (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Standard:
AISI, ASTM, BS, DIN, GB, JIS
Grade:
SGCC
Thickness:
0.14~1.2mm
Place of Origin:
China
Brand Name:
hengze
Model Number:
CGCC
Type:
Steel Coil
Technique:
Cold Rolled
Surface Treatment:
Coated
Application:
Boiler Plate
Special Use:
Wear Resistant Steel
Width:
600~1250mm
Length:
as your requirements
Product Name:
Prepainted galvanized steel
Top coating thickness:
20-25um
Back coating thickness:
5-7um
Color:
all RAL colors or customers samples color
Zinc coating:
40-275g/m2
Coil ID:
508mm,610mm
Coil weight:
3-8mt
Paint:
PE, PVDF, SMP, HDP
Packaging:
Standard export seaworthy packing
Payment:
30% deposit, 70% by T/T against B/L copy; or by L/C
Supply Ability
Supply Ability:
300000 Metric Ton/Metric Tons per Year
Packaging & Delivery
Packaging Details
Standard export packing, 4 eye bands and 4 circumferential bands in steel, galvanized metal fluted rings on inner and outer edges, galvanized metal and waterproof paper wall protection disk, galvanized metal and waterproof paper around circumference and bore protection
Port
Qingdao, Tianjin,Shanghai, any port of China

export to india galvanized steel coil z275   PPGI Color Coated Steel Sheet in Coil



1.Description & Specification:



PPGI Coils PPGI Steel Coil PPGI Prepainted Galvanized Steel Coil
PPGI is pre-painted galvanised iron, also known as pre-coated steel, coil coated steel, color coated steel etc., typically with a hot dip zinc coated steel substrate



 The hot dip metallic coating process is also used to manufacture steel sheet and coil with coatings of aluminium, or alloy coatings of zinc/aluminium, zinc/iron and zinc/aluminium/magnesium which may also be factory pre-painted. While GI may sometimes be used as a collective term for various hot dip metallic coated steels, it more precisely refers only to zinc coated steel. Similarly, PPGI may sometimes be used as a general term for a range of metallic coated steels that have been pre-painted, but more often refers more precisely to pre-painted zinc coated steel.



 Zinc coated steel substrate for PPGI is typically produced on a continuous galvanising line (CGL). The CGL may include a painting section after the hot dip galvanising section, or more commonly the metallic coated substrate in coil form is processed on a separate continuous paint line (CPL). Metallic coated steel is cleaned, pre-treated, applied with various layers of organic coatings which can be paints, vinyl dispersions, or laminates. The continuous process used to apply these coatings is often referred to as Coil Coating.



 The steel thus produced in this process is a prepainted, prefinished and ready for further processing into finished products or components. to use material.



 The coil coating process may be used for other substrates such as aluminium, or aluminium, stainless steel or alloy coated steel other than "pure" zinc coated steel. However, only "pure" zinc coated steel is typically referred to as PPGI. For example PPGL may be used for pre-painted 55%Al/Zn alloy-coated steel (pre-painted GALVALUME(r) steel*)







Thickness

0.14mm-1.2mm

Width

600mm-1250mm

Single weight

Max 6.0MT

Zinc thickness

30-275g/m2

Steel gardes

TDC51D2,TDC51D+AZ,TDC51D, GR.A, GR. B, SPCC, SPHC, DX51D, ect.

Standard

JIS G3302, JIS G3313, ASTM A653, GB/T2518-88, GB11253-89,, BS, ect.

Packing

Wrapped by plastic film and waterproof paper, and then fastened on

wooden pallet.Or as you request.

Used

Used in building material, roof, profile,pipe making, furniture making, etc.

Minimum quantity

Can be 25MT

Price

FOB Tianjin Port or Qingdao Port 600-950USD/MT

Delivery time

within 25 days after receiving 30% deposit or copy of LC at sight

Payment terms

T/T or L/C

Supply ability

10,000 MT per month







2.Material Composition Sheet:



Steel Grade

Chemical Composition (%)

Mechanic Property

C.B of Coating

Coating

C

Si

Mn

S

P

T.S

Y.S

E.L





x103

x103

x102

x103

x103

Mpa

Mpa

%

D=0 180°

G/M²

JIS G3302 SGCC

12

30

41

31

21

480

300

13

OK

Z60-150

JIS G3302 SGCH

12

10

21

18

8

680

650



OK

Z60-150

ASTM A653 CS.B

20

30

60

35

30

386

205-380

20

OK

Z60-275

DX51D+Z

29

21

18

1.8

11

355

245

38

OK

Z60-275

G550

20

6

73

5

17

715

654

8

OK

Z60-275





3.Painting:

Category of Painting

Item

Code

Polyester

PE

High-durability polyester

HDP

Silicon modified polyesters

SMP

Polyvinylidene fluoride

PVDF

Easy-Cleaning

Painting Thickness

Top side: 20+5microns;

Bottom side: 5~7microns.

Color System

Produce according to RAL Color System or as per buyer’s color sample.

Painting structure

Top surface

Bottom surface



Primer coating

No coating

1/0

Primer coating

Primer coating

1/1

Primer coating + Finish coating

No coating

2/0

Primer coating + Finish coating

Primer coating or single back coating

2/1

Primer coating + Finish coating

Primer coating + Finish back coating

2/2





4.MCL Process

Our Services





5.Application:



1. Buildings and constructions: roofing, ceilings, gutters,  venting lines, indoor decorations, window frames, etc.
2. Electrical appliances: computer shells, washing machines, refrigerators, dehumidifiers, video recorders, water heaters, etc.
3. Agricultural equipments: troughs, feeding tools, agricultural driers, irrigation channels, etc.
4. Vehicle parts:  back-seat plates of buses and trucks, conveying systems, oil tanks, etc





6.Advantage:



1. Excellent corrosion resistance: The zinc layer provides a good protection of Pre-painted Galvanizeed Steel Sheet.
2. High heat resistance: The reflective surface of the material aids in efficiently reflecting the sunlight away and in turn reducing the amount of heat transmitted. The thermal reflectivity converts into energy savings.
3. Aesthetics: Pre-Painted Galvanized steel sheet is available in plethora of patterns and multiple sizes as per the requirements that given by our customers.
4. Versatility: can be used in the various areas.







Packaging & Shipping

7.Packaging&Shipping





Company Information

8.Our Company













9.Questions&Answers
