Etc. When designing a cable assembly, a number of factors need to be considered such as, work load, abrasion, cycle life, and flexibility, environment, cost, safety .etc. the larger the diameter ,the greater the work load capacity and the less flexible it will be.
WARNING :Breaking strength should never be considered the rope's working load ,safety factor 5:1 ,Coating must be removed from installation area when attaching fittings
Refer to the drawing as below:
All of specification custom-made available. the tighter tolerance ,the higher the cost of the cost.
how to choose material:
1.stainless steel :
providing good corrosion resistance and strength comparable to galvanized carbon steel grades.
Zinc coated carbon steel offers some corrosion resistance. It remains ductile over long periods of working. Usually higher break strengths than stainless steels.
1. How do you design a wire cable assembly? Of course, we have to know your application firstly and a number of factors have to be considered, such as workload, safety abrasion, environment, cycle life, flexibility, cost, When we design the steel wire cable assembly.
2. What’s the safety factor of your product?
General, use a 5 to 1 or 3 to 1 safety factor when we design it, example: breaking load is (1000N) 100kg, the safety factor is 5:1 (200N) Breaking strength should never be considered the rope's working load
3. What’s the lead time of my order?
It largely depended on the size of your order .normally, 15days. if you are in urgent need of it, we will try my best to meet your requirements.
4. How to place an order?
We produce according to customers’ specifications, so you’d better give us complete information as specified below:
