fpc cable 0.4mm and 0.5mm pitch fpc connector FPC/FFC Flexible board

FOB Reference Price:Get Latest Price
$0.10 - $2.00 / Piece | 1 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 500 501 - 1000 >1000
Est. Time(days) 3 5 Negotiable
Customization:
Customized logo (Min. Order: 1 Pieces)
Customized packaging (Min. Order: 1 Pieces)

More

Graphic customization (Min. Order: 1 Pieces) Less
Samples:
$3.00 /Piece | 1 Piece (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China
Brand Name:
OEM
Model Number:
NH-A64
Base Material:
Polyimide/PET
Copper Thickness:
1oz
Board Thickness:
0.075 ~0.4mm
Min. Hole Size:
0.20mm
Min. Line Width:
0.075mm/0.075mm(3mil/3mil)
Min. Line Spacing:
0.05mm
Surface Finishing:
immersion gold, osp etc
Product name:
2018 Hot sale 0.4mm pitch fpc cable, fpc board
Material:
Polyimide/PET
MOQ:
1piece
Service:
ODM OEM EMS
Application:
FPC connectors
Layer:
1-6
Certificates:
ISO9001:2008
Customized:
Yes
character:
soft
Type:
PCB
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
1)Wrap in air bubble film 2) Put into foam box 3) Packed with extra carton box, which make sure the goods safety in transportation. 4) We can accept customized package.
Port
Guangzhou Shenzhen
Lead Time :
Quantity(Pieces) 1 - 500 501 - 1000 >1000
Est. Time(days) 3 5 To be negotiated

fpc cable 0.4mm and 0.5mm pitch fpc connector  FPC/FFC Flexible board

_01All of our products are custom made from dimension, color, material requirment, cable length, tracks pitch, total thickness etc..



Also add special structure to make the products more attractive, like backlight, fluorecent etc..



Expect for getting your design idea, then we will work hard together to achieve it.

FPC Parameter
MaterialPolyimide (Kapton)Polyester (PET)Remarks&Test Merhod
Number of Layer1-6 layer1-2 layer
Min. Line Width/Min. Line Spacing Single side0.075(3mil)
Double side0.075(3mil)
Min.Hole Diameter Drilling(P.T.H)Ø 0.20mm
PunchingØ 0.5mm
Dimension ToleranceConducting Wire width(W)±0.03mmW≤0.5mm
Hole Diameter(H)±0.05mmH≤1.5mm
Accumulated spacing±0.05mmP≤25mm
Outer Dimension(L)±0.05mmL≤50mm
Conducting Wire and Outer(C)

±0.075mm

C≤5.0mm
Surface treatment   Ni(0.05-2um)/Au(0.05-1.25)
Pb/Sn(2-20um) Primary flux
H.A.L(for polyimide only)
Chemical Ni(0.8-1.5um)
OSP
Insulation Resistance1000ΩIPC-TM-650 2,5,3,2 at Ambient
Dielectric Strength5KWIPC-TM-650 2,5,6,1
Surface Resistance5*10122*1012IPC-TM-650 2,5,1,7
Volume Resistance1*10151*1015IPC-TM-650 2,5,1,7
Dielectric Constant(1MHz)4.03.0MIL-P-55617
Divergence Coefficient(1MHz)0.040.03MIL-P-55617
Peeling Strength(180℃ Direction)1.0kg f/cm1.2kg f/cmIPC-TM-650 2,4,9
Welding strength300/10 secs210℃/10 secs
Combustion assisting94 V-O94 V-OUL94
