high frequency computer keyboard sticker making machine

FOB Reference Price:Get Latest Price
US $2,000-3,500 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Jiazhao
Model Number:
JZ-5K/8K-TR
Voltage:
380V
Power:
5KW/8KW/10KW
Frequency:
40.68MHz/27.12MHz
Welding Area:
Customization
Dimensions:
1.1*1.7*1.55m
Weight:
700KG
Usage:
welding sealing embossing
After-sales Service Provided:
Engineers available to service machinery overseas
Welding time:
0-10s
Biggest pressure:
400KG
Operation mode:
Foot step / pneumatic
Temp range:
0~200℃
Rectifier:
Silicon diode
Power input:
8KVA / 15KVA
Press stroke:
50mm
SupplyAbility
SupplyAbility:
30 Set/Sets per Month
Packaging & Delivery
Packaging Details
standard export wooden case weight lifting belt Making Machine
Port
Shekou/Yantian port of Shenzhen
Lead Time :
7~15 days after confirming payment PVC Water container welding



Product Description



  All our products are custom, tell us some dedails of your product(product name,material ,dimension ), we will pick up one machine best for you.

Model

JZ-5K-SB(RB)

JZ-8K-SB(RB)

JZ-10K-SB(RB)

JZ-12K-SB(RB)

High frequency power

5KW

8KW

10KW

12KW

Oscillation tube

7T85RB

7T69RB

3069RB

E3130RB

Biggest pressure

470KG

700KG

Customization

Gap of electrodes

230mm

210mm

Press stroke

200mm

Size of upper plate

200*350mm

400*600mm

Customization

Size of lower plate

400*600mm

600*800mm

Supply voltage

220V/380V(50/60HZ)

          380V/60MHz

Frequency

27.12MHz or 40.68MHz

Power input

8.5KVA

15KVA

20KVA

Rectifier

Silicon diode

Temp range

0~200°C

Station

Two work station push table or round turn table

Operation mode

Full pneumatic

Welding time

0~10s adjustable

Physical size

1.1*2.0*1.8m

1.1*2.7*1.85

Customization



Description

welding for shoe, shoes material, trademarks, vest embossing, leather and so on.





  1. Use a vacuum tube, the output power is stable and reliable.
  2. High sensitive spark over-current protects circuit, can automatically cut off high frequency and suppress spark.
  3. Equipped with frequency stabilizer and high frequency shielding device, make the high frequency interference a lowest level.
  4. Manually adjust the mold, horizontal and quadrangular adjustment, easily to adjust mold.
  5. Can automatically complete two welding process, improve work efficiency.
  6. Equipped American automatic over-current spark protection system, protects tube life and mold.
  7. Use standard international industry band.
  8. The Silicon tube has strong resistance to voltage, Taiwan “AIRTAC” pneumatic components and microswitch.
  9. Taiwan “CKC” timestamp, precise locking time settings.

Advantage:

1. East  to operate: General worker can operate it after simple training



2. Interlock  protection system: this system can lock equipment once there is  abnormal phenomenon



3. Strong and durable welding effect: side wall / cleat belts can be welded on base belt tightly, which can not be  tear out easily.



 Machine Detail:





Samples:

















Packaging & Shipping

1. Strong PlyWooden Case can afford the long dumpy transportation despite sea or railway,low damage guranteed & customer's suggestion is welcome;

2. Fumigation , keep air in circulation & can avoid the harmful pest being taken to the destination.





Our Services

Pre-sale services:

1.      provide professional technical support;

2.      send the product catalog and instruction manual;

3.      if you have any question please contact us online or send us email, we promise we will give you a reply as soon as possible;

4.      personal call or visit is warmly welcome

sale of services:

1.      we promise honesty and enthusiasm, it’s our pleasure to serve you as you purchasing consultant.

2.      We guarantee punctuality, quality and quantities strictly implement the terms of contract

After-sale service:

1.      Where to buy our products for one year warranty and life long maintenance

2.      24 hours telephone service online

3.      A large stock of components and parts, easily-worn parts.







FAQ



Company Information

Shenzhen Jiazhao Hightech limited company is an improving high frequency ultrasonic automatic/semi-auto equipment manufacturing unit. The enterprise is dominant in leather welding cutting, plastic welding, heating fusing, blister packaging machine, developing mating and related devices.

Business field &items

high frequency welding machine

ultrasonic plastic welding machine

blister packaging machine

human-communication semi-auto/auto high frequency/ultrasonic devices

leather handbag leather case, shoe wear high frequency fusing equipment with whole factory.

computer CNC engraving mold, high frequency mold,(electric packaging mold, leather fusing mold), ultrasonic mold, industrious clamping mold



  specific medical products machine

   PVC PETsingle and double face blister packaging machine

   electric blister paper machine

   car articles, door board, sunshield welding machine

  tooth packaging mahcine

  non-woven bag,shoe case,suitcase pants ultrasonic production line

   toys plastic electric ultrasonic machine

  specific  canvas pain ting cloth tent, treadmill machine

  stationary raincoat plastic bag(PVC,EVA,TPU) high frequency electric machine

   cell phone computer bag, electric book, learing machine, moving keyboard, whole factory device leather equipment

   leather (PVC ,PU) derma handbag suitcase bag, carpet, shoe, chemistry cloth high frequency embossing machine.

Jiazhao hot-sell machines:

Jiazhao designed molds:

Jiazhao welded samples:



Contact us:

     All our products are custom, tell us some dedails of your product(product name,material ,dimension ), we will pick up one machine best for you.

     We will give customers a prompt response on getting the inquiry, promise reply will be passed within 24 hours(expect holiday).

     Customers can talk with our salesperson on line through TradeManager, Email,skype,QQ or call us at any time
