high gloss Gartley interior wall decorative resin panel

  • 30-199 Sheets
    $230.00
  • >=200 Sheets
    $190.00
Type:
gartley resin panel
- +
available
custom size
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
10 day(s) after payment received
Customization:
Graphic customization (Min. Order: 200 Sheets)
Customized packaging (Min. Order: 200 Sheets)
Contact Supplier
Samples - $1.00 /Sheet, 1 Sheet (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Gartley
Model Number:
acrylic wall panel
Sample:
available
Thickness:
2~20mm
Bending Strength:
42.2mpa
Feature:
3d wood pattern,marble texture
Utility:
wall panel,cabinet,elevator wall,tv wall
Waterproof:
Excellent
Color:
blue,red,gloden
Material:
decorative resin wall panel
Design:
Custom-made

Packaging & Delivery

Selling Units:
Single item
Single package size:
250X130X30 cm
Single gross weight:
300.0 kg
Package Type:
clear plastic film protect high gloss resin panel surface,3cm foam with wooden pallet
Picture Example:
package-img
Lead Time :
Quantity(Sheet) 1 - 30 >30
Est. Time(days) 10 To be negotiated
Product Description

 GARTLEY Decorative resin wall panel is an unique and artistic product with totally handmade process.with high quality polymer material, Jiateli has high stability,fire resistant, environment friendly features.popular for feature wall, commercial display stand,nightstand,furniture,table,showcase in hotel,office,club,karaok and other commercial decoration


Standard Size:1220*2440mm(48"*96")
Thickness:2~20mm

Surface Finish:high gloss
Available in custom size and thickness

Process:bend,curve,cut,drill,glue,paint,sculpture

Available backing material:MDF,Fire-resistant MDF,Plywood,aluminium panel

SPECIFICATIONS FOR TRANSLUCENT RESIN PANEL

Physical Property
Hardness
R-SCALE
110
Water Ratio
%
0.2
Density
g/cm3
1.3
Mechanical Behavior
Flexural Strength
Mpa
80
Flexural Modulus
Mpa
2150
Izod Impact Strength
J/M
90
Optical Property
Impact Resistance
J
33
Flammability Rating
_
V2
Translucent
%
89
Installation Process

make wood/aluminium/stainless steel frame to get back lighting

bottom led lighting to get bottom to top lighting transparent

back lighting feature wall

ceiling hardware for  hanging partition,wall

hardware for divider and partition

hanging ceiling lighting

BEND
Oven Bending---evenly heating by Oven,take the panel out of Oven and put it on the prepared moulds,press and mould you want,then cooling the bending panel
CUT
Wood saw,ceramic saw,marble cutting machine are all applicable for cutting,and portable manual driller for drilling
LIGHT
Better use fluorescent lamp or neon light or LED,>15cm away from the resin panel.if between 10~15cm,better use a refecting paper on the lamp back panel.
DAMAGE PREVENTION
Avoid prolonged exposure to strong chemicals such as acids, bases and solvents.
REPAIRING
any dirts on the surface,use soap water or ammonia detergent to clean then dry cloth to clean the surface.
Small cuts, scratches and stains grind it by using sand paper,first 800#(with water),second 1000#(with water),then use wax(usually car wax is ok.) to polish it.
Deeper cuts or damage due to shocks,such as cracks,may require the intervention
of a service centre, in order to perform a craftsman like repair.

Packing&Delivery
Packaging
Size
250 (L) * 130 (W) * 40 (D)
Weight
1.25 T
Packaging Details

clean all translucent stone panel.clear PE film project polish/matte surface finish.30pcs 1220*2440*8mm standard size panel in one wooden box/pallet.The normal package is wooden box(Size: L*W*H).the wooden box will be fumigated.or pack it according to customers special request.

Size
40 (L) * 40 (W) * 30 (D)
Weight
15kgs
Packing Details

single packed into plastic bag and strong,neutral,brown cardboard box,box padded on all sides with styrofoam plates(2~3cm thick)

then 5~10pcs inner carton to one master carton.or pack it according to customers special request.

Packaging
Size
250 (L) * 130 (W) * 50 (D)
Weight
1.5T
Packaging Details





50pcs 1220*2440*6mm standard size panel in one wooden box/pallet.metal strap 20ft container can load 8~10pcs wooden box/pallet.all box/pallet placed orderly and easy for your uploading on arrivial.
certifications
Our Services

Pre-Sales Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

After-Sales Service

* Training how to fabricate column,cube,box
* support in technology and installation
* Engineers available to service overseas.

FAQ


Q1.What is the feature of your panel?
•fire resistant B class
•net weight is half of natural marble.weather and water resistant
•eco-friendly to get touch with food,fruit.get USA FDA certificate
•our panel has over 89% lighting transparent.availabel to curve/bending,drill,sculpture,paint,gule shape

Q2.May I customize products?
of course.Naiteli has research and development deparment to help you get your idea coming ture
we have OEM experience for over 10 years.

Q3.How much will the shipping cost?
we can arrange worldwide shipping.
we are committed to find best sevice and low cost shipping for you.the shipping charges are calculated
based on the ordered products.

Q4.If I want small trial order?
•small trial order is welcome.we can arrange free samples to you along with your orders.
•if you want to get free sample in priorit of trial order.it is still possible.but you would pay sample fee firstly
and sample fee will be returned when official order is placed.

Q5.How long can I get price?
we respond to every inquiry within 24 hours.so pls fell free to contact with us
