high quality Automatic 300CC EEC CVT ATV QUAD BIKE 4*4

FOB Reference Price:Get Latest Price
Report Suspicious Activity
Overview
Quick Details
Fuel:
Gas / Diesel
Displacement:
>300cc
Engine Type:
4 Stroke
Transmission Type:
Automatic
Transmission System:
Shaft Drive
Certification:
EEC
Place of Origin:
Zhejiang, China (Mainland)
Model Number:
fm300
Engine:
300CC AUTOMATIC CVT ENGINE
drive model:
shaft drive 4*4, 4*2 for optional
Brake:
F/R disc brake
ATV:
300CC ATV QUAD BIKE EEC ,OFF ROAD
Supply Ability
Supply Ability:
2000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
STEEL FRAME+CARTON BOX
Port
NINGBO port ,CHina

high quality Automatic 300CC EEC CVT  ATV QUAD BIKE 4*4



Item No.:

FM300

ENGINE TYPE

Single Cylinder, 4 Stroke, Water Cooled

MAX.POWER(KW/rpm)

14KW/7000rpm

MAX.TORQUE(N.m/rpm)

20N.m/5500rpm

MAX.SPEED

65Km/h

BORE STROKE

72.5mm × 66.8mm

DISPLACEMENT

276cm

COMPRESSION RATIO

10.3:1

CARBURETOR

CVK052

LUBRICATION

Combined Force-Feed and Splash Lubrication

AIR FILTER TYPE

Dry Air Filter Net

SPARK PLUG

DR8EA

STARTING

Electric Start

IGNITION

C.D.I

STARTING PROCEDURE

Start Electric Lock, Hold Brake, Press Start Switch

GEARSHIFT

Manual

SHIFT SWITCH

2W/4W Shift Button (Yellow)

TRANSMISSION

Automatic CVT with H/L/N/R

FINAL DRIVE SYSTEM

4WD / Shaft

BRAKE FRONT

Hydraulic Disc Brake

BRAKE REAR

Hydraulic Disc Brake

PARKING DEVICE

Mechanical Brake Lock on Rear Disc

BRAKE DISTANCE

7m/30km/h

FRONT SUSPENSION

Mcpherson Suspension

REAR SUSPENSION

Swing Arm

SHOCK ABSORBER(F)

Double

SHOCK ABSORBER(R)

Single

BATTERY

12V/14AH

ENGINE OIL

1.5L

TRANSMISSION OIL

0.8L

REAR OIL

0.3L

FUEL

90# Unleaded Gasoline

FUEL CAPACITY

12.5L

TURNING RADIUS

3280mm

MAX.LOAD(kgs)

156kg

FRONT TIRE

25x8-12

REAR TIRE

25x10-12

RIM MATERIAL

steel

OVERALL

2016×1180×1237mm

PACKING SIZE

2280×1290×870mm

WHEELBASE(mm)

1271mm

SEAT HEIGHT(mm)

895mm

GROUND CLEARANCE

183mm

NET WEIGHT(kgs)

275kgs

COLOR

Red, Blue, Orange, Black, Army Green, Camo

LOADING QUANTITY

8pcs/20'GP, 18pcs/40'GP, 27pcs/40'HQ
