hot melt glue labeling machine

Feedback Ratings
US $55238.00 / Set | 1 Set (Min. Order)
Quantity:
- + Sets available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
30 day(s) after payment received
Customization:
Customized logo (Min. Order:: 1 Sets)
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Type:
Labeling Machine, rotary
Condition:
New
Application:
Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical
Packaging Type:
Bottles
Packaging Material:
Wood
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
380V
Power:
8KW
Place of Origin:
China (Mainland)
Brand Name:
LIVINGH2O
Model Number:
RRJ-1209R
Dimension(L*W*H):
3000*2500*2000mm
Weight:
3000KG
Certification:
CE Certificate
After-sales Service Provided:
Engineers available to service machinery overseas

Packaging & Delivery

Selling Units:
Single item
Single package size:
3100X2600X2100 cm
Single gross weight:
3000.0 kg
Package Type:
Wooden Case
Lead Time :
30

Opp/Bopp Hot Melting Glue Labeling Machine





Opp/Bopp Hot melting labeling:


OPP plastic labels are non-toxic, environment protecting, and look nice and attractive. The technological development of label is rapid. Including o indicating the brand, composition and shelf life, the developers are now working to develop product packaging of low-cost, impact resistance and strong attractive appearance. With the new technology development of shrink packaging system and the emergence of underlying and adhesive of shrink labels, the roll label material OPP plastic label technology provides the processors with a labeling process of low cost, nontoxic and environment protection, low feed consumption and high resolution.

The production process of the roll label material OPP plastic adhesive is short, and its price is affordable. To use the roll label materials such as OPP, BOPP and composite paper to replace the PVC shrink label film; it can achieve more than 30% cost reduction. And it is non-toxic, waterproof. The patterns are not easy to be out of shape. This product is of high class and is the best eco-labels.





Machine performance characteristics:


1.Humanization touch screen,simple operation,with on-line help function
2.Using german high-speed servomvtor andecontroller for label feeding sy stem to make sure high-speed of accuracyandstable label cutting and fe ding
3.The main motor adpts for ultra power imported motor,guarantee stabilit y and operation for the running of machine
4.Use German colour code detection electric sensor,raise prcise of label feeding
5.Perfect running protection system can realize the alarm of stop such a s lack of label,omit labeling,bottle jam,temperature inspection,lack o f air source.
6.The rotary type of mold position labeling way can make sure the accura cy and stability of label sealing.
7.Adopts for Siemens etc imported world famous electric components guara nteeing the reliability and lasting stability
8.Reserve online interface function,conveniently for connecting with oth er equipments





Technical parameters:


Power supply three-phase 380V 50 Hz 8000W
Machine dimensions 3000*2500*2000mm (customizable)
Method of speed adjustment uninterrupted-adjust rate
Max Speed of labels feed max speed of 150 m/min
Labeling precision ±1mm
Maximum label width 150mm(standard width,can be adjusted)
The maximum length of label 500mm
The maximum diameter of label 600mm
Paper core diameter 152mm
Labeling glue hot melt,glue at both ends of each label
Gluing temperature 120~160℃
Labeling type for products suitable for round or square
Type of label opp label,paper-plastic composite film label,paper labelcontainrs made of plastic,metal,glass
Diameter of container 40mm-100mm


Production capaciy:
RRJ-1209R (12 per circle): 9000B/H
RRJ-1615R (16 per circle): 15000B/H
RRJ-2024R (20 per circle): 24000B/H
RRJ-2436R (24 per circle): 36000BPH
Machine weight about 3000 kg
