new electronic multihead combination weigher machine for sticky food/biscuit/candy/fries/peanut

FOB Reference Price:Get Latest Price
$5,000.00 - $10,000.00 / Sets | 1 Set/Sets (Min. Order)
Power:
1kw
Model Number:
ZH-A10
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 25 Negotiable
Report Suspicious Activity
Overview
Quick Details
Warranty:
1 Year
Application:
Chemical, Commodity, Food, Medical, Machinery & Hardware, Other
Packaging Material:
Paper, Plastic, Other
Type:
Multi-Function Packaging Machine
Applicable Industries:
Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Retail
Condition:
New
Function:
Filling, Sealing, Wrapping, Other
Packaging Type:
Bags, Bottles, Cans, Cartons, Case, Pouch, Stand-up Pouch, Other
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
220V 50/60Hz
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
Zon Pack
Dimension(L*W*H):
1650(L)*1120(W)*1150(H)
Certification:
CE Certification
After-sales Service Provided:
Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support, Engineers available to service machinery overseas
Name:
ZH-A10 Multihead Weigher
Weighing Range:
10-2000g
Accuracy:
±0.1-1.5g
Max Weigh Speed:
65 Bags/Min
Gross Weight(Kg):
400
Hopper Volume(L):
1.6/2.5
Driver Method:
Stepper motor
Interface:
7"HMI
Package Volume (mm):
1650(L)*1120(W)*1150(H)
Supply Ability
Supply Ability:
99 Set/Sets per Month
Packaging & Delivery
Packaging Details
Film pack inside, wooden case outside
Port
Shanghai/Ningbo Port
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 25 To be negotiated
Video Description
Product Description

Application

ZH-A10 is suitable for weighing grain, stick, slice, globose, irregular shape products such as candy, chocolate, jelly, pasta, melon seeds, roasted seeds, peanuts, pistachios, almonds, cashews, nuts, coffee bean, chips ,raisins, plum, cereals and other leisure foods, pet food, puffed food, vegetable, dehydrated vegetables ,fruits, sea food, frozen food, small hardware, etc


Example:

                                                              TECHNICAL SPECIFICATION
                                  Model
ZH-A10
                     Weighing Range
10-2000g (Can multi-drop)
                   Max Weigh Speed
65 Bags/Min
                          Accuracy
±0.1-1.5g
                  Hopper Volume(L)
1.6/2.5
                    Driver Method
Stepper Motor
                       Option
Timing Hopper/ Dimple Hopper/ Printer/Overweight Identifier / Rotary Top Cone
                      Interface
7''HMI/10''HMI
                Power Parameter
220V/ 1000W/ 50/60HZ/ 10A
                Package Volume (mm)
1650(L)×1120(W)×1150(H)
                  Total Weight(Kg)
400
                                                                      TECHNICAL FEATURE
1) The amplitude of vibrator can be auto-modified for more efficient weighing.
2) High precise digital weighing sensor and AD module have been developed.
3) Multi-drop and succeeding drop methods can be selected to prevent puffed material blocking the hopper.
4) Material collecting system with function of unqualified product remove, two direction discharge, counting, restore default setting.
5) Multi-language operation system can be selected basing on customer's requests.


Details

Options

                     Flat Surface

                     Teflon Surface

                             Dimpled Surface

Main Parts


Touch screen

Brand: WEINVIEW
Original: Taiwan
It has advanced human-machine communication skills and brand development ideas.


Photosensor

Brand: Autonics
Original: Korea
Autonics is now a total solution provider in sensors and controllers offering more than 6,000 items to the various fields of industrial automation.



Air cylinder

Brand: SMC/AIRTAC
Original: Japan/Taiwan
It is a well-known supplier/manufacture of pneumatic equipments in the world market.


System Unite:

1)Z Shape bucket elevator

2)10 heads multihead weigher

3)Working platform

4)Vertical packing machine

5)Product conveyor


Our Company

Our Projects

Our Certifications

Our products have undergone many professional certifications.

Our Customers

Our Exhibition


Our Service
Packing & Delivery
Packaging Details
Film pack inside, Wooden case outside
Delivery Time
Within 25 working days
Shipping Ways
By Sea
By Train
By Plane
By Car
        Note
We also can pack it according to customers special request.
