pressure transmitter 350bar pressure transmitter 4~20ma silicon pressure transmitter 4-20MA

  • 2-49 Pieces
    $45.00
  • 50-199 Pieces
    $40.00
  • 200-499 Pieces
    $35.00
  • >=500 Pieces
    $25.00
Material:
Stainless steel
Accuracy:
0.5%FS
Type:
Gauge pressure Absolute pressure Sealing pressure
Pressure Range:
-0.1Mpa~0.1Mpa
$
- +
available
0~0.6Mpa
$
- +
available
0~1Mpa
$
- +
available
All 8 Options
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
15 day(s) after payment received
Customization:
Customized logo (Min. Order: 2 Pieces)
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
Meacon
Model Number:
MIK-P300
Pressure type:
gauge pressure absolute pressure sealed pressure
Pressure range:
-0.1...0/0.01...60Mpa
Power supply:
9~36V
signal output:
4~20mA;1~5V;0~10V;0~5V;RS485
Accuracy:
0.3%FS/0.5%FS
overload pressure:
150%FS
Water Proof:
IP65
MOQ:
1
OEM:
Yes
Application:
Water Oil Air Pressure Measurement
Product Certification certification
CE Certified.

Packaging & Delivery

Selling Units:
Single item
Single package size:
20X10X10 cm
Single gross weight:
0.500 kg
Lead Time :
Quantity(Pieces) 1 - 100 >100
Est. Time(days) 15 To be negotiated
Video Description
Products Description
  MIK-P300 pressure transmitter is kind of device based on pressure layer, which inside expert integrate circuit can transform sensor milli-volt signal to standard far distance transmission current signal, and it can be directly joined with computer joint clip, control instrument ,aptitude instrument or PLC etc. conveniently. The series' product is applied extensively in the professions, such as the industry process control, petroleum, chemical engineering and metallurgy etc. Carry the distance delivers and can adopt electric current exportation method.
Specification
Pressure Type
Gauge pressure/ absolute pressure /sealing pressure
Power Supply
24VDC(9~36V)
Signal Output
4~20mA;1~5V;0~10V;0~5V;RS485
Range
-0.1…0/0.01…60Mpa
Accuracy
0.3%、0.5%
Long Term Stability
±0.2%FS/year
Ingress Protection
IP65
Pressure Connection
G1/4, G1/2,1/2NPT,1/4NPT, M20*1.5etc.(optional)
Measure Medium
Gas, water, oil etc. (non-explosion-proof area)
Electrical Connections
DIN connector type, M12 connector, cable connector type
Time Response
≤10ms(up to 90%FS)
Housing material
304/316L stainless steel
Fill Fluid
Silicon oil
Operation conditions
Working Temperature
-20℃~85℃
MediumTemperature
-20℃~85℃
Storage Temperature
-40℃~125℃
Compensation Temperature
-10℃~70℃
Application
Product details
Wiring instruction
