realtek chip ofeixin OEM/ODM rtl8723 wifi wireless module

FOB Reference Price:Get Latest Price
US $2.3-3.2 / Piece | 50 Piece/Pieces (Min. Order)
Supply Ability:
200000 Piece/Pieces per Day
Port:
SZ
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
FN-LINK
Model Number:
F23BUUM13-W2
power voltage:
3.3Vdc ±10% I/O
WIFI Standard:
IEEE802.11b/g/n
Operating Frequency:
2.4GHz
Interface Type:
USB
DATA Rates:
150M
Antenna:
External Antenna
Security:
WEP,TKIP,AES,WPA,WPA2
OS Support:
Windows/Android /Linux
Dimension:
L13*W12 mm
Main Chipset:
RTL8723BU
Packaging & Delivery
Packaging Details
Blister parking,take-up package,vacuum packaging
Delivery Time
Shipped in 7 days after payment
Note

    Respect of the customer,please contact the sales staff before purchasing module to carry out pre-sale consultation.Otherwise,the module may not meet your needs or modules have no inventory.
    Detailed specifications docs,please download form the official website.
    skype:nickren999

Product Introduction

Introduction

 F23BUUM13-W2 is a small size and low profile of WiFi + BT Combo module with LGA (Land-Grid Array) footprint, board size is 13.2mm*12.0mm with module thickness of 2mm. It can be easily manufactured on SMT process and highly suitable for tablet PC, ultra book, mobile device and consumer products. It provides USB interface for WiFi to connect with host processor and high speed USB interface for BT. It also has a PCM interface for audio data transmission with direct link to external audio codec via BT controller. The WiFi throughput can go up to 150Mbps in theory by using 1x1 802.11n b/g/n MIMO technology and Bluetooth can support BT2.1+EDR/BT3.0 and BT4.0.

Features

  Operate at ISM frequency bands (2.4GHz)
 SDIO for WiFi and UART for Bluetooth
 IEEE standards support: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11d, IEEE802.11e, IEEE 802.11h, IEEE 802.11i
 Fully Qualified for Bluetooth 2.1+EDR specification including both 2Mbps and 3Mbps modulation mode
 Fully qualified for Bluetooth 3.0
 Fully qualified for Bluetooth 4.0 Dual mode
 Full–speed Bluetooth operation with Piconet and Scatternet support
 Enterprise level security which can apply WPA/WPA2 certification for WiFi.
 WiFi 1 transmitter and 1 receiver allow data rates supporting up to 150 Mbps downstream and 150Mbps upstream PHY rates

Application range:

Tablet / notebook
Advertising machine /TV board
OTT/IPTV/DVB/STB
DV/ IPC/Mini driving recorder / doorbell
Smart TV / intelligent projector Pico
VR/AR terminal
Wireless storage
Printer /POS machine / electronic said
Vehicle mounted front / rear terminal
UAV / robot
Intelligent Gateway
Toys
Lighting lamps / intelligent street lamps
Smart home appliances / appliances
Instrument and meter (water, electricity, gas)
Smart city and other consumer electronic products

Detailed parameters
Model No
F23BUUM13-W2
Main Chipset
RTL8723BU
WIFI/BT Interface
USB
WIFI Standars
EEE802.11 b/g/n  BT v2.1+EDR/BT3.0/3.0+HS/4.0
Date Rates
150Mbps
Certification
RoHS,REACH
RF Antenna
external Antenn
OS Supported
Android /Linux/ Windows
Operating Frequency
2.4GHz
Operating Voltagc
3.3V
Dimensions
L x W : 13 x 12  mm
RF Chains
1T1R
Operating temperature
-0°C to 70°C
Storage temperature
-40°C to 85°C
