self amalgamating rubber splicing tape

  • 100-4999 Rolls
    $1.50
  • 5000-9999 Rolls
    $1.20
  • >=10000 Rolls
    $1.00
1 batch = 100 Rolls
Color:
Black
Specifications:
0.76mm*19mm*9.1m
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
25 day(s) after payment received
Customization:
Customized logo (Min. Order: 10000 Rolls)
Customized packaging (Min. Order: 10000 Rolls)

More

Graphic customization (Min. Order: 10000 Rolls) Less
Contact Supplier
Samples - $1.00 /Roll, 1 Roll (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Material:
Polyester
Use:
Masking
Adhesive Side:
Single Sided
Adhesive:
Rubber
Adhesive Type:
Pressure Sensitive
Feature:
Waterproof
Design Printing:
No Printing
Place of Origin:
Hebei, China
Brand Name:
LIANTU
Model Number:
HY-20
Product name:
self amalgamating rubber splicing tape
Color:
Black
Width:
19mm, 25mm
Application:
electrical wire harness tape
Name:
rubber splicing tape
Thickness:
35mic-65mic
Length:
5m, 9.14m, 10m
Usage:
Packing Cartons
Certificates:
ISO9001
Type:
Pressure Senstive Adhesive Tape

Packaging & Delivery

Selling Units:
Multiple of
Package size per batch:
57X46.5X13 cm
Gross weight per batch:
22.0 kg
Package Type:
1roll in a plastic bag
Picture Example:
package-img
Lead Time :
Quantity(Roll) 1 - 10000 >10000
Est. Time(days) 25 To be negotiated
Video Description
Product Description

Product Application

This tape is a self amalgamating , low voltage rubber tape which meets the requirements of ASTM-D-4388,Type I, It easily conforms to irregular shapes and surfaces yielding a void free, electrically stable build up. Compatabile with all extruded dielectric cable insulation.
Property
Value
Unit
Text Method
Total thickness
0.76
mm
ASTM-D-4325
tensile strength
250
psi
ASTM-D-4325
Elongation at break
400
%
ASTM-D-4325
contiouous Operation Temperature
80
ASTM-D-4325
Emergency Overload Temperature
95
ASTM-D-4325
Dieletric
20
KV/mm
ASTM-D-4325
Standard sizes
thickness
width
length
0.5mm
19mm
9m
0.76mm
19mm
9m
0.76mm
25mm
9m
0.76mm
38mm
9m

other size and corse are available customization.

Packing & Delivery
Recommend Uses

Ethylene propylene rubber adhesive tape is an excellent shape,self-melting ethylene-propylene base insulation tape, this is a no need vulcanization, stable property tape,has good insulation performance, ethylene propylene rubber self adhesive tape not only can be used for low voltage insulation but also for high pressure 69000 volts voltage insulation.

Features:

l It can be used for docking and termination of cable,the emergency overload temperature can reach 130℃
l Ethylene-propylene rubber base
l Physical and electrical properties are not affected by the drawing originated.
l Self-melting tape
l Excellent electrical properties
l Special polyester release paper,will not stick on tape when unfold the tape
l Can be used for solid dielectric cable insulation layer
1)Polyethylene (high and low density)

2)XLPE
3)PVC
4)Butyl rubber
5)EPR
6)Oil-based rubber


Main insulation recovery of 600-69000 volts solid dielectric cable;
The maximum of 35000 volts solid dielectric cable on the make the stress cone main insulation;
Intermediate head and terminal sheath recovery;
Moisture-proof sealing of electrical connections;
Busbar insulation;
Cable end sealing.

Our Company

Shijiazhuang Liantu import and Export Trading Co.,Ltd

WE Liantu electrical focus on electrical tapes.
Specially manufacture, wholesales and retail PVC electrical tape, cotton insulation tape,EPR rubber self -fusing tape, butyl waterproof sealing tape,PVC wrapping tape, Bopp packing tape.
Accept OEM orders, customize you brand logo, packing printing and delivery request.
We proud of our quality, we focus on electrical tapes high quality, strong adhesion, longtime anti-aging using life, good insulation and waterproof, day after day hard work we try our best to improve the quality, keep it in the top, now we can very sure our tapes can protective you safe when doing electrical works, live and working.
Good price is our aim, we keep the quality in the best and try best to reduce the produce cost, high tech control auto-machine produce less waste, reasonable workers arrangement,working with stable supplier partner make materials stable and cheaper, reduce delivery cost, keep our produce cost lower and price competitive.
Best service is our working custom, we are a team-leaning- share-cooperate, do our best for you:special product knowledge,helpful advice, quickly response.welcome you join us working together.
With our successful cooperation, our products sales to Russia, U.A.E,India,Iran,Turkey,Egypt,Thailand,Singapore,Malaysia,Indonesia,Vietnam,Korea...........as its good quality, competitive price, honestly helpful working team, we get good reputation.
Welcome your enquiry and visit.

Our Service
Contact

More details , please contact :

Shijiazhuang Liantu Import and Export Trading Co.Ltd
Address : Huigu Building A604, No.95 Qilian Street,Shijiazhuang city ,  Hebei Province,China 050011
Contact person : Eileen Wu
Whatsapp : 008618932904172
Skype : lt2tape
