self-loading concrete mixer truck mobile cement mixer for sale

$13,235.00 / Set | 1 Set (Min. Order)
Model Number:
HW-SL1.2
Concrete Output:
70m3/10 hours
$13,235.00
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Power(W):
58kw
Weight:
7500kg
Warranty:
1 year
Condition:
New
After-sales Service Provided:
Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Online support
Place of Origin:
China
Brand Name:
Hengwang
Certification:
ISO
Dimension(L*W*H):
6100*1850*3000
Applicable Industries:
Construction works
UNIQUE SELLING POINT:
Low Maintenance Cost
After Warranty Service:
Video technical support, Online support
Local Service Location:
None
Showroom Location:
None
Mixing capacity:
1.2 m3
wheel tread:
1850mm
bucket capacity:
0.3 m3
discharge:
70m3/day(10 hours)
mixer material:
Manganese plate
Enigne:
Yunnei /Yuchai /Dongfanghong
Water tank:
1.5 m3
tyre:
rail tyre
Option:
rotate and weighing
loading:
40 full container

Packaging & Delivery

Selling Units:
Single item
Single package size:
45X25X25 cm
Single gross weight:
68.0 kg
Package Type:
40 full container
Lead Time :
Quantity(Sets) 1 - 5 >5
Est. Time(days) 7 To be negotiated

alibaba trade assurance.JPG

Product Description

self loading concrete mixer truck

Self Loading Concrete Mixer is  a kind of multifunctional machinery which combines the transit mixer, concrete mixer and wheel loader together. It can automatically load, measure, mixing and discharge concrete mixture. Equipped with powerful Yunnei / YUCHAI (Cummins optional ) Diesel engine and 4 wheel  drive plus 2 wheel steering,  the self loading concrete mixer is just like a truck and the operator can drive it to where it needs to go. It is very convenient for loading material, such as cement, aggregate, stone,etc .

We have different capacity 0.8m3 ,1.2m3 ,1.8m3 ,2.0m3 ,2.4m3 ,3.5m3 etc.



Advantage :

1. Italy leading design, automatic feeding mixing system
2. Simple and convenient operation
3. High efficiency output, save time and labor, save cost
4. The perfect combination of mixing truck and loader.

5.Standard equip with auto water metering supply , drive camara . and weighting system ,seat rotary , Air conditioning ,etc optional .









Parameter





Mixing capacitym31.2
Drum capacitym31.4

angle of inclination
°16
Rotation Speedr/min 0-14
Rotation Direction Feeding:clockwise  discharge:anticlockwise
Drum blade Two sets of spiral blades and four sets
 of auxiliary blades
Slump of concretemm70-260
  Hydraulic actuation system
Oil pump model CBGV-4025
Motor model  BMSS-250
Reduction gear ratio  1:10
  Water System
Tank tank capacity/water
supply type
L540/Self - contained automatic timing automatic unblocked
 water supply mechanism
  Chassis main performance parameters
engine main performance parameters
Engine model/displacementL CF4B68G-Z-13B2/CF4C100T-Z-13B2
Type Direct injection four stroke water - cooled
supercharged diesel engine
Rated Powerkw/r/min 55KW/2400   78KW/2400
maximum torqueN.m/r/min 255/1500-1800    380/1500-1800
maximum travelling speedkm/h24
minimum turning radiusmm5000
 gradeability%26
Tyre  23.5/70-16
driving mode 4×4
Total Weightkg4580
Maximum loading weightkg2800
Maximum total vehicle masskg7380
Sizemm 6100*1850*3000
