single shaft shredder

  • >=1 Sets
Model Number:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)


Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Quick Details
Place of Origin:
Jiangsu, China
Plastic Type:
Machine Type:
Plastic Shredder
Shaft Design:
Max.Production Capacity (kg/h):
Production Capacity (kg/h):
100 - 10000 kg/h
Brand Name:
Film Crusher
1 Year
After-sales Service Provided:
Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support, Engineers available to service machinery overseas
Applicable Industries:
Hotels, Building Material Shops, Farms, Restaurant, Home Use, Food Shop
Key Selling Points:
After Warranty Service:
Video technical support, Online support, Field maintenance and repair service
Local Service Location:
Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Peru, Saudi Arabia, Indonesia, Pakistan, Mexico, Russia, Spain, Thailand, Japan, Australia, Morocco, South Korea, Chile, Romania
Showroom Location:
Marketing Type:
Ordinary Product
Machinery Test Report:
Video outgoing-inspection:
Warranty of core components:
1 Year
Core Components:
Motor, Gearbox
film shredder
films,woven bags,ton bags
pp pe
Buyer's Requirement
Plastic Industry
Other name:
China Plastic Shredder
Strong Plastic Crusher
Supply Ability
Supply Ability:
1 Set/Sets per Month
Packaging & Delivery
Packaging Details
wooden case and pe film wrapping single shaft shredder.
shanghai port
Picture Example:
Video Description
Product Description
CF-SS series plastic shredder is designed to meet the waste recycling requirements of various industries, and is suitable for plastic, paper, wood,Fiber, rubber, domestic garbage recycling, etc., there are many types of recyclable materials. According to the material feed size and output,And the output size of the final product to configure the optimal solution for the customer.
This series of pp pe shredder uses Siemens programming control system.Can be controlled automatically, with start, stop,reverse and overload automatic reverse control functions, with low speed, high torque, low noise.

CF-SS series single shaft shredder can be used for HDPE, PP-R, PVC, ABS, and other plastic pipes, profiles and pipe materials, the recycling of headstock and waste materials. After years of research and development by our company, we have made technical improvements and made breakthroughs in innovation. The new-generation film shredder developed by the company has greatly improved the work efficiency, and the blades tools are the imported alloy materials. Increase the hardness of the blade surface and increase the service life of the tool. The cutter head adopts a square-corner arc structure design, which promotes the contact area between the cutter and the raw material, and can be recycled, which greatly improves the service life of the cutter head. The size of the material shredded by the single-shaft shredder is 5 ~ 12㎝, and then crushed by the secondary conveyer and the crusher, which can meet the granulation requirements and directly perform granulation production.
The single-shaft shredder is composed of a motor, a hard toothed surface reducer, a rotating knife shaft, an imported moving knife, a fixed knife, a frame, a machine base, a box, a hydraulic cylinder, an oil pump, a cylinder, a working platform and other major structures.
A fixed knife is installed on the frame, and a detachable embedded movable knife is installed on the rotary knife shaft. The number of the movable knife depends on different models and the size of the rotary knife shaft. Change the angle until the sides are blunt and then sharpen the knife. Because it is a claw type moving knife and rotary cutting, and the fixed knife and moving knife are imported SKD11 materials, the hardness after heat treatment reaches HRC60 ° or more, so the service life is long. Strong cutting ability, high production capacity, normal use up to 1,000 tons or more need to sharpen.
When the shredder is working, the materials are advanced by hydraulic cylinders and equipped with clamping devices. Adopt Siemens programming control system, which can be controlled automatically. It has start, stop, reverse and overload automatic reverse control functions. It has the characteristics of low speed, large torque and low noise.
Related Products
Detailed Images
Shredding principle
Push box pushes the material
towards the blade rotor
Blades shred the material
The push box continues to push
the material towards the blades rotor to increase output

The blade is made of D2, and all four corners can be used.
Blader rotor
High-performance blades rotor
This kind of blades rotor is commonly used for PE, PP, PET materials,Hard materials and soft feet in paper, wires and cablesShred.
Hard blades rotor
This blades rotor is for ABS,
PC,Designed with hard materials
such as nylon.Props sink deeper
and cut less in a single shot.
Reduce impact and noise.
Film blades rotor
The blades rotor adds a translation knife to effectively cut the film.In addition, the blades rotor is welded with a
wear-resistant layer, which increases the life of the knife stick.
Company Introduction
Zhangjiagang Chinafor Machinery Co.,Ltd is a professional manufacturer and trader specializing in EPS recycling machinery,Plastic Mixing,Plastic Bottle Recycling,Plastic Extruder,Plastic Shredders ,we producting many types of recycling machine for waste recycling.Our boss has been a mechanical engineer for over twenty years.
After Sales Service
FCL delivery, directly wrap film package packing;LCL, wrap with wrapping film first, then pack in wooden case, the wooden case is fumigation-free, in line with exportrequirements.
(The equipment can be packaged according to customer's requirement)FOB Shanghai
