solar water pump inverter sukam solar inverter price mppt solar inverter with low price

FOB Reference Price:Get Latest Price
$705.00 - $1,200.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
GTS
Model Number:
GTS-3KW
Output Power:
3KW
Output Type:
Single
Size:
420 x 415 x 170MM
Weight:
18KG
Input Voltage:
48V
Output Voltage:
230V
Type:
DC/AC Inverters
Output Frequency:
50Hz/60Hz
Output Current:
13.6A
RATED POWER:
3000W
Maximum PV Array Power:
4500 W
Nominal DC voltage/Maximum DC voltage:
360VDC/500VDC
MPPT Range @ Operating Voltage:
250VDC ~ 450VDC
NO. of MPPT Tracker/Max. input current:
1way /18A
Battery Voltage:
48 VDC
Maximum Battery/AC Charge Current:
25 A/30A
Communication Port:
RS-232/USB
Grid output Voltage Range:
184 - 265 VAC
Waterproof:
IP20
Supply Ability
Supply Ability:
200 Piece/Pieces per Week It can be customized
Packaging & Delivery
Packaging Details
Carton Package, Wooden Package
Port
SHANGHAI


3KW Hybrid On&Off Solar Inverter With Battery Backup



1.Introduction

The hybrid PV inverter can provide power to connected loads by utilizing PV power, utility power and battery power. Depending on different power situations, this hybrid inverter is designed to generate continuous power from PV solar modules (solar panels), battery, and the utility. When MPP input voltage of PV modules is within acceptable range (see specification for the details), this inverter is able to generate power to feed the grid (utility) and charge battery. This inverter is only compatible with PV module types of single crystalline and poly crystalline. Do not connect any PV array types other than these two types of PV modules to the inverter.



2.Main Features

  • Pure sine wave output
  • Self-consumption and Feed-in to the grid
  • Programmable supply priority for PV, Battery or Grid
  • User-adjustable battery charging current suits different types of batteries
  • Programmable multiple operation modes: Grid-tie, off-grid and grid-tie with backup
  • Built-in timer for various mode of on/off operation
  • Multiple communication for USB, RS-232, Modbus and SNMP
  • Monitoring software for real-time status display and control
  • Parallel operation up to 6 units for 10KW

3.Specification



4.Parameter



5.Schematic diagram



6.Unpacking&Overview





7.Certification

Packaging & Shipping

Carton Package or Pallets.

Gross Weight:18KG

Gross Size: 140 x 295 x 468MM

Shipping
1. FedEx/DHL/UPS/TNT for small module samples, Door-to-Door;
2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;
3. Customers specifying freight forwarders or negotiable shipping methods!
4. Delivery Time: 5workdays for samples; 15 workdays for batch goods.
Our Services

1. We are Alibaba Assessed Gold Supplier,Popular Supplier.

2.100% QC inspection Before Shippment.

3. CE certificated,competitve price.

4. 7*24 online EMAIL service!

Company Information

Zhangjiagang Great-Trust New Energy Technology Co., Ltd.

Tel: +86 51258978702  Fax: +86 51258978703  Mobile: +86 18021230698(Mr.Jack)

FAQ

Q1.Are you a factory or trading company?

We are industry and trade integration. We have 120 factory workers and 10 of them are quality control and engineer guys. Welcome to visit our factory.

Q2. All products have a warranty?

Yes, we supply 1 to 25 years warranty for our products
