super bright ip computer/laptop control p10 outdoor advertising standing led electronc board

FOB Reference Price:Get Latest Price
$930.00 - $1,130.00 / Square Meter | 1 Square Meter/Square Meters (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Model Number:
LW-PH10-1R1G1B D
Brand Name:
Lightwell--RGB A
Screen Dimension:
mini/giant,any size,3*2m,4*3m.....
Pixels:
10mm
Display Function:
Text,message,graphic,excel sheet,flash,video,picture,flash
Tube Chip Color:
red/green/blue/yellow/pink/dual/full color
Usage:
Semi-outdoor/indoor/outdoor
Pixel pitch:
10mm(PH10mm) displayer,monitor
LED chip:
cree/epistar/silan/opto/Nichia
high waterproof:
Front:IP67/IP68 back:IP65(shockproof ,dustproof,waterproof)
installation methods:
one pillar/two pillar/hanging/rental/truck/wall mounted
Led display:
outdoor waterproof commercial advertising digit video module display
outdoor display:
advertising video led display screen/sign/panel/board/billboard
control system(box):
LINSN/colorlight,3G/GPRS/GSM/WIFI/U DISK/USB wireless system
usage:
square,street,shop,house roof,office,bus,taxi
Many selection:
p3/p4/p5/p6/p7.62/p8/p10/p12/p14/p16/p18/p20/p25
warranty time:
5 years
Supply Ability
Supply Ability:
3000 Square Meter/Square Meters per Month
Packaging & Delivery
Packaging Details
1.Anti-shaking wooden package(plywood)
2.Air freight case
3.Anti-static carton case
Port
Shenzhen
Lead Time :
3-12 working days(including testing time)

Outdoor advertising video full color led display



Display advantage and feature

Indoor and outdoor LED displays, because of its characters of high brightness, low working voltage, low power consumption, environmental friendly, long life span, impact resistance and stable functions, have get rapid growth and have attracted more people’s attention.

LED display is controlled by computer and can play all kinds of information in the form of pictures, Videos, texts. (Such as 3D animation, Video, TV and DVD program, Live show).It has strong practical applicability.

LED display has a wide development perspective. It is currently applied in bus stations, docks, airports, shopping plazas, banks, bourse exchanges, building market, industrial enterprise management and other public places .It will have a even more bright future.



1.Description

outdoor full color led display, full color led display board, full color led screen

2.Our main product:
outdoor led display and indoor led display:
advertising led display, rental led display, stage background led display,curtain led display,perimeter led screen,mobile led display, taxi top led display,scoreboard led display

3.Application:
plaza,leisure square,exoressways, entertainment square,commercial center, banks,scools,hospitals,hotel.



Module:

Back shell
Bayer materials
Electroplating processing
-- Anti- high/low temperature(85°C/ -40°
C)
-- Anti- chemical corrosion
-- Strong & durable

PCB board
FR4 A2 material
Four-layer
-- enlarge circulation area
-- decentralizing driving current

Front mask
High-strength material,adding10% fiber
High-low temperature test & rapid aging-destructive test &anti-impact test
Streak & special oil processing
-- Three-dimensional quality
-- High level planeness
-- Distinguish presentation
-- Square hole design
-- Excellent optical performance



P10 outdoor full color led display



                      Find the display,Find the professional



1.Module





2.POWER SUPPLKY



3.controller



LINSN,COLORLIGHT,DBstar



4.CABLES







5.CABINETS







6.FULL SET CABINET





7.FULL SET DISPLAY



 8.Display testing





9.Usage

10.PACKAGE

NO.ItemParameter
1Module typeXHX-PH10
2Pixel pitch10mm
3Pixel density10,000dots/sqm
4LED encapsulationDIP
5LED typeCopy 346
6Module resolution16*16dots
7Module demmension160*160mm
8Pixel configuration1R1G1B
BESD-OFPH10 Cabinet Parameter
NO.ItemParameter
1Dimension960*960mm
2Physical resolution96*96dots
3Module quantity36
4Weight65KG
5MaterialIron/Aluminum
Screen Parameter
NO.ItemParameter
1Red wavelength625±5nm
2Green wavelength525±2.5nm
3Blue wavelength470±2.5nm
4Max brightness6000cd/sqm
5Viewing angleHorizontal:110 degree;Vertical:75degree
6Viewing distance10-100m
7Max power consumption850W/sqm
8Color display10.7billion
9Driving Method1/4 Static,Constant current
10Refresh frequence480HZ
11Iuput signalRF,S-VIDEO,rgb,RGBTV,YUT
,YC,COMPOSITION
12MTBF5,000hours
13Lifespan100,000hours
14Failure dot ratio<0.0001
15Input VoltageAC110V/60HZ;AC220V/50HZ
optional
16Working environmentTemperature-20 C~ +60 C;
Humidity:10%~95%
17Water proofIP65(front);IP54(rear)
Warranty: 2 years
Control system:Sending card+receiving card+Hub card+DVI card+PCTV non-liner editting card+multi-function car+video processor+transmission cable(for optional)
LED chip type:CREE,Silan,Nichia,Taiwan,and so on
Other types:XHX-P12,P16,P20,P25,P31.25,P37.5,P40etc.

Display module catalog

P3 full color led module------------Size:96mm*96mm------------------32*32

P4 full color led module------------Size:128mm*128mm---------------32*32

P5 full color led module------------Size:160mm*160mm---------------32*32

P6 full color led module------------Size:192mm*96mm-----------------32*16

P7.62 full color led module--------Size:244mm*122mm---------------32*16

P8 full color led module------------Size:256mm*128mm----------------32*16

P10 full color led module-----------Size:160mm*160mm----------------16*16

P16 full color led module-----------Size:256mm*128mm-----------------16*8

P16 full color led module-----------Size:256mm*256mm-----------------16*16

P20 full color led module-----------Size:320mm*160mm-----------------16*8

P25 full color led module-----------Size:200mm*200mm------------------8*8

P31.25 full color led module-------Size:250mm*250mm------------------8*8

.................................
