vegetable horizontal packing machine

$4,200.00 - $11,990.00 / Set | 1 Set (Min. Order)
Model Number:
P-280
$4,200.00
- +
available
P-350
$4,800.00
- +
available
S-350
$5,500.00
- +
available
All 6 Options
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
10 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Application:
Chemical, Commodity, Food, Medical, Machinery & Hardware
Packaging Material:
Plastic, Paper
Type:
Multi-Function Packaging Machine
Condition:
New
Function:
Filling, Sealing, Wrapping, Laminating
Packaging Type:
Stand-up Pouch, Bags, Film
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
220v 50/60Hz
Power:
2.4KVA
Place of Origin:
Zhejiang, China
Brand Name:
CECLE
Dimension(L*W*H):
(L)3770X(W)670X(H)1450mm
Certification:
CE
Speed:
40~230 bags/min
After-sales Service Provided:
Engineers available to service machinery overseas

Packaging & Delivery

Selling Units:
Single item
Single volume:
3 cm 3
Single gross weight:
600.0 kg
Lead Time :
Quantity(Set) 1 - 1 >1
Est. Time(days) 10 To be negotiated
Product Description
Technical parameter
Model
P-280
P-350
S-350
P-500
S-500
S-650
Surface
Spray
Stainless
Spray
Stainless
System
Single servo
Three servo
Single servo
Three servo
Packing speed
30-200bags/min
10-180 bags/min
10-150 bags/min
30-180 bags/min

Packing size (mm)
 L 60- 280
W 10- 40/40-80
H 5- 25/25-40
 L     80- 320
W    30- 100
H        5- 50
   L  120-999
W    30-180
 H       5-100
   L    150-6000
W     100-260
 H        5-130
Max.width of film
<280mm
<360mm
<500mm
<650mm
Thickness of film
≥0.02mm
≥0.025mm
Power
220V,50/60HZ,2.5kw
220V,50/60HZ,6kw
Overall size (mm)
4790*700*1520
4700*800*1550
4700*800*1550
4800*1200*1700
Weight (kg)
500kg
600kg
1100kg
Package
2.2CBM,2CASES
2.3CBM,2CASES
2.8CBM,2CASES
Packing material
OPP/PP,OPP/CPP,PT/PE,PE,KOP/CPP,PT/PE,AL/PE etc

Remark
Our machine can be customized with packing size,spay or stainless,servo system,etc
If you are not satisfied with the models above,pls send us an inquiry for further details.

Additional equipment
a. Automatic coding device
b. Automatic labeling device
c. Punch device, gusset device
d. Nitrogen filling, air discharging device, and alcohol spraying device
e. No material automatic shutdown
What's the difference between singe servo and three servos system?
1.
The speed of three servos system is faster
2.
Three servos system is more stabilization
3.
It is easer to contral by three servos system
Main characteristics

1. Adopt a higher precision Servo system,with PLC & AC inverter intelligent and stepless controlling,which can realize simple operation and more correctly cutting.

2. High-sensitive photo sensor,automatically adjust,track,find cutting point,accumulatively count packs,automatic measuring bag length.

3. Digital and independent PID temperature controlling,suitable for various packing materials.New type double fin sealing design makes the packaging high efficiency and beauty.

4. Adjustable bag former and pitches,enable and change of packing products conveniently.

5. The area connect to products are fully stainless steel.With timing belt transmission,compact structure,lower noise and less shake.

6.Variety of optional device is available,like: Touch screen/Date coder/Labels applicator/Euro slot or hole punch/Gusset forming/Nitrogen or gas inflation/Spraying alcohol/Automatic film splicer/Auto feeding/Desiccant feeder/Auto falling/Products conveyor/No products no packing /check weigh/Metal detector etc.

Our Company
Certifications
Our Business
Our Service
FAQ

Q: Are you a factory or a trading company?
A: We are factory manufacturing packaging machines and we provide perfect OEM and after-sale service.

Q: Can you send me the video to show how the machine works?
A: Certainly, we have made video of every machine and uploaded them to Youtube.

Q: How can I know your machine works well?
A: Before delivery, we shall test the machine working condition for you.

Q: How can I know your machine is designed for my product?
A: You can send us samples of your product and we test it on machine.

Q: How can I pay my order?
A: We accept T/T, Western Union paying methods. For those orders less than 500USD, we accept PayPal to pay.

Q: Do you have a CE certificate?
A: For every model of machine, it has a CE certificate.
