1. 360 degree full light beam angle led lighting, high lumen
2. Environmental friendly led lighting, no mercury content
3. Designed according to traditional halogen lamps.
4. Instant start led lighting, no delay and flickers.
5. Ra>80, 80LM/W, energy saving led lighting
6. IC Driver led lighting, constant current, safety guaranteed
7. More than 25,000hrs life time
8. Passed CE, RoHS, ERP, SAA certification.
Product datasheet
Electrical data
Rated wattage | 4.0W±0.2 |
Nominal voltage | 180-240V |
Operating frequency | 50/60Hz |
Power factor | 0.5 |
Claimed equiv. conventional lamp power | 40W |
Photometrical data
Nominal luminous flux | 470-520 |
Rated luminous flux | 570-520 |
Color temperature | 2700K |
Light color as per EN 12464-1 | Warm White |
Standard deviation of color matching | ≤5.0sdcm |
Dimensions
Overall length | 105.0mm |
Diameter | 60.0mm |
Commercial Type | A60 |
Life span
Nominal lamp life time | 25,000hrs |
Additional product data
Energy efficiency class | A++ |
Beam angle | 360° |
ApplicationAreas
1. Domestic Applications for chandelier lights.
2. General Illuminations with E14 or E27 sockets
Why Choosing New Lights as ur supplier:
1. We have a 17-year experience in lighting and we know what customer want and their concerns.
2. We are one of the few companies in China who produce the LED filaments and drivers all by our self.
3. We are very careful with the qualified raw material selection, Sapphire brackets, 99.9% gold wire, IC chip.
4. Our LED filament lamps can maintain a <10% light decay even under 80℃.
5. The latest technology of LED filament can reach 145-155lm/w for the whole bulb.
Package and Shipping
Option 1: choose a full container of either 20GP, 40GP or 40HQ and enjoy a better price.
Option 2: buy at LCL.
We offer the following shipping method:
1) Courier services lke FedEx, DHL for samples.
2) Air shipment for emergency order.
3) Sea Shipment for bulk order.
Sample Service
Small quantity of samples are free of charge, buyer shoulder the fright cost
Sample delivery time is around 3-7 days after confirmation
Customized Service
We accept OEM order and we can help customer design
We also offer ODM service to customer when needed
After-sale Service
We offer 7/24 Service
Any quality issue, once confirmed, we will compensate our customer
Certifications of led lighting
Production Process
Team and Fair Show
1. what is the advantages of ur LED Filament lamps?
1) we have got CE ROHS ERP and SAA cert which are approved by TUV and SGS.
2) It has a same look as incandescent bulbs with 360 degree beam angle, but high efficiency of 120lm/W,
3) good after-sale service with 2 years warranty.
4) we produce the LED filament and drivers all by ourselves, so that we can ensure the quality better than our competitors.
2. If I have some failed product ,how to deal with it ?
You may need to send us some details of the failed products such as the operating condition and the surroundings, better with picture.
Once we confirmed it is kind of Quality Issue from our side, we will send you replacement within ur next shipment.
3. What is the difference of copper and sapphire filament ?
Sapphire has a higher light output and bigger beam angle , but the price is bit higher.
While copper has lower lumen such 90-100/W, metal can not reflect the light so maybe there will be dark side , but the price Is lower with better heat sink.
