100A 125A 200A 300A 400A PCB High Voltage Connector

$7.99-$49.59/ Piece|10 Piece/Pieces(Min. Order)
View product details

100A 125A 200A 300A 400A PCB High Voltage Connector

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Power Connectivity: Designed to handle rated currents from 100A to 400A, enabling reliable power transmission in high-voltage applications.
  • PCB Mount Compatibility: Features screw-terminal termination and PCB mounting options with right-angle or straight orientations for seamless integration into circuit boards and industrial systems.
  • Protection & Durability: IP67-rated housing (metal and plastic composite) ensures resistance to dust, water, and high temperatures, safeguarding against environmental hazards.

Key features

  • 1. Material Technology: Corrosion-Resistant Metal and High-Temperature Plastic

    • With a corrosion-resistant metal body combined with high-temperature-resistant plastic, ensure durability and reliable insulation in harsh industrial environments. Outperforms standard plastic-only connectors in extreme conditions*.

  • 2. Interactive Design: Modular Configuration and Screw Termination

    • With a modular design and screw termination, easily customize configurations and secure connections for diverse applications. Achieves 50% faster assembly than non-modular connectors*.

  • 3. Performance Parameters: High Current Capacity Up to 400A

    • With a rated current of up to 400A, handle heavy-duty power demands for industrial machinery or electric vehicles. Delivers 2x higher capacity than standard 200A connectors*.

  • 4. Scenario Solutions: Versatile for High-Power Applications

    • Designed for high-power scenarios like electric vehicles and industrial systems, ensuring continuous operation in demanding environments. Suitable for commercial use, unlike home-grade connectors*.

  • 5. Certification Standards: IP67 Protection

    • With IP67 certification, guarantee dust and water resistance, meeting rigorous industrial safety standards. Exceeds IP54 ratings common in basic connectors*.

Product details

100A 125A 200A 300A 400A PCB High Voltage Connector

The 100A-400A PCB High Voltage Connector series delivers robust power transmission solutions for high-current applications. Engineered with metal and high-temperature-resistant plastic, these connectors feature IP67 protection and screw termination for secure, reliable connections in harsh environments. Available in right-angle and straight orientations, they are ideal for electric vehicles, industrial machinery, and power distribution systems.

Technical specifications

FeatureSpecificationApplication Scenario
Material CompositionMetal core + High-Temperature PlasticWithstands prolonged exposure to 120°C+ environments
Protection LevelIP67 (Dust/Waterproof)Harsh industrial settings with moisture/dust
Rated Current100A-400A (adjustable per model)Electric vehicle battery systems, solar inverters
Mechanical StabilityHigh (Screw Locking Mechanism)Vibration-prone machinery or automotive use
Termination TypeScrew TerminalSecure, tool-based connections for high-power circuits

Customization guide

Adjustable Parameters:

  • Pin Configuration: Customize pin spacing and count (1P to multi-pin) to match PCB layouts.
  • Current Rating: Select from 100A-400A to align with system power demands.
  • Orientation: Choose right-angle or straight designs for optimal space utilization.

Get inspired

With these connectors, engineers can build safer, more efficient power systems. For instance, the 400A Pro Model enables high-power EV charging stations, while the 125A Base Model suits compact solar inverters.

Choose your model

ParameterBase Model (125A)Advanced Model (200A)Pro Model (400A)
Rated Current125A200A (+60% vs Base)400A (+100% vs Base)*
Operating Temp Range-40°C to 120°C-40°C to 150°C-40°C to 180°C
Weight250g320g (+28%)450g (+80%)

Supplier's note

  1. Key Breakthroughs:

    • IP67 Protection: 20% higher ingress resistance than industry standards, enabling use in outdoor environments.
    • Modular Design: Customizable pin configurations reduce assembly errors by 30%.
    • High-Temperature Plastic: Maintains structural integrity at 180°C, outperforming competitors’ 150°C limits.

  2. Version Selection Guide:

    • Base Model: Ideal for low-to-mid-power systems (e.g., home solar inverters) requiring cost-effective solutions.
    • Advanced Model: Targets industrial robotics and HVAC systems needing 200A+ handling without excessive weight.
    • Pro Model: Designed for EV charging stations and heavy machinery where 400A+ currents and extreme temperatures are standard.

*Comparative benchmarks: Industry average for 400A connectors typically weighs 500g; our Pro Model reduces weight by 10% while maintaining strength.

Frequently asked questions

  • Which 100A-400A PCB high-voltage connector model suits EV battery systems?

  • How do I clean a PCB mount high-voltage connector with screw termination?

  • Metal vs plastic in PCB high-voltage connectors: Which ensures better heat resistance?

  • Can I customize pin spacing for a right-angle PCB high-voltage connector?

  • Is the 200A PCB connector IP67-compliant for outdoor use?

  • What’s the max current for a straight 1P PCB high-voltage connector?

  • Are these connectors UL-certified for industrial power systems?

  • Can I mix 125A and 400A PCB connectors in the same system?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
100A Base ConnectorStandard industrial equipmentRated Current: 100A (IEC 60947-1); IP67 (immersion up to 1m for 30min)Cost-effective for low-power systems; compact size ▲Limited to moderate loads; fewer customization options
125A Advanced ConnectorEV charging stations (Level 2)Rated Current: 125A (IEC 60947-1); Metal-plastic hybrid housing ▲▲Handles medium EV charging;耐高温 up to 125°C (ASTM D6228)Heavier than Base; requires专业安装
200A Base ConnectorIndustrial robotics systemsScrew Termination (IEC 60297); Straight/Right-Angle Options ▲Robust for repetitive use (10,000 mating cycles IEC 60512-50); IP67 protectionNot suitable for extreme high-current applications
200A Advanced ConnectorHeavy machinery power distribution4-Pin Configuration ▲▲▲; Locking Mechanism (UL 94 V-0 rated)Supports parallel wiring for 400A+ systems;防震 up to 5g (MIL-STD-810G)Higher cost; bulkier design
300A Base ConnectorSolar invertersPCB Mount Design (ISO 9001 certified); 1P ConfigurationDirect PCB integration reduces wiring errors; lightweight plastic housingLower temperature tolerance (max 105°C)
400A Advanced ConnectorElectric vehicle battery packs400A Rating (IEC 60947-1);全金属外壳▲▲▲; 360° EMI Shielding (CISPR 25)Handles high-power快充;耐高温 up to 150°C;防爆设计 (ATEX 2014)Requires专业工具安装;最贵选项
