  • 2.47 Inch 480x480 400 Int 35 Pin MIPI-DSI Interface Transmissive HX8379-C Tft Lcd Module Display Touch Screen
  • 2.47 Inch 480x480 400 Int 35 Pin MIPI-DSI Interface Transmissive HX8379-C Tft Lcd Module Display Touch Screen
  • 2.47 Inch 480x480 400 Int 35 Pin MIPI-DSI Interface Transmissive HX8379-C Tft Lcd Module Display Touch Screen
  • 2.47 Inch 480x480 400 Int 35 Pin MIPI-DSI Interface Transmissive HX8379-C Tft Lcd Module Display Touch Screen
  • 2.47 Inch 480x480 400 Int 35 Pin MIPI-DSI Interface Transmissive HX8379-C Tft Lcd Module Display Touch Screen
  • 2.47 Inch 480x480 400 Int 35 Pin MIPI-DSI Interface Transmissive HX8379-C Tft Lcd Module Display Touch Screen
2.47 Inch 480x480 400 Int 35 Pin MIPI-DSI Interface Transmissive HX8379-C Tft Lcd Module Display Touch Screen

2.47 Inch 480x480 400 Int 35 Pin MIPI-DSI Interface Transmissive HX8379-C Tft Lcd Module Display Touch Screen

  • 1 - 999 Pieces
    $18.90
  • 1000 - 9999 Pieces
    $13.90
  • >= 10000 Pieces
    $3.90

Customization:

Brightness（Min.Order: 500 pieces）
Backlight（Min.Order: 500 pieces）
PIN（Min.Order: 500 pieces）
Storage Temp（Min.Order: 500 pieces）
View product details

2.47 Inch 480x480 400 Int 35 Pin MIPI-DSI Interface Transmissive HX8379-C Tft Lcd Module Display Touch Screen

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Resolution Display: 2.47-inch TFT LCD module with 480x480 resolution, delivering crisp visuals for applications requiring detailed graphics.
  • Touch Integration: Built-in touch screen functionality with HX8379-C controller for responsive user interaction.
  • Advanced Interface: MIPI-DSI 35-pin interface ensures seamless connectivity to modern processors and embedded systems.
  • Versatile Display Technology: Transmissive design with a gradient color scheme (green-to-blue) optimized for readability in varied lighting conditions.

Key features

  • 1. Material Technology

    • With REACH and FCC-certified materials, ensure compliance with global safety and environmental standards. The tempered glass display panel and durable black frame provide robust protection against scratches and impacts, outperforming non-certified modules*.

  • 2. Interactive Design

    • With a touchscreen interface and MIPI-DSI interface, enable seamless integration into smartphones, wearables, or IoT devices. The circular shape offers design flexibility compared to standard rectangular displays, adapting to unique device form factors*.

  • 3. Performance Parameters

    • With 400 nits brightness and 480x480 resolution, achieve vivid, crisp visuals in bright environments, up to 40% brighter than standard LCD modules*. The HX8379-C controller ensures stable performance for high-demand applications like industrial displays or gaming accessories.

  • 4. Scenario Solutions

    • With a detachable 35-pin flexible ribbon cable, simplify installation and upgrades in compact devices like smartwatches or tablets. The transmissive TFT technology ensures clarity in direct sunlight, ideal for outdoor or commercial use cases*.

  • 5. Certification Standards

    • With dual REACH and FCC certification, meet stringent regulatory requirements for consumer electronics, reducing compliance risks for global markets compared to uncertified alternatives*.

Product details

2.47 Inch 480x480 400 Int 35 Pin MIPI-DSI Interface Transmissive HX8379-C Tft Lcd Module Display Touch Screen

The 2.47-inch 480x480 TFT LCD module combines high-resolution display capabilities with a flexible MIPI-DSI interface, making it ideal for wearable devices, industrial controls, and IoT applications. Its transmissive design ensures clarity in bright environments, while the HX8379-C controller optimizes performance and reliability.

Technical specifications

FeatureSpecificationApplication Scenario
Display TypeTFT LCDGeneral-purpose embedded systems
Resolution480 x 480 pixelsHigh-definition UI interfaces
Brightness400 nitsOutdoor devices requiring sunlight readability
InterfaceMIPI-DSI (35-pin)Seamless integration with modern SoCs
Controller ICHX8379-CEnhanced color accuracy and low power consumption
CertificationsREACH, FCCCompliance for global electronics markets
Display Size2.47 inches (circular)Wearables and compact devices

Customization guide

Adjustable parameters include:

  • Color Gradient: Customize the screen’s gradient (e.g., green-to-blue) to match branding or design themes.
  • Frame Material: Choose between lightweight plastic or rugged metal for durability.
  • Interface Compatibility: Adapt the MIPI-DSI pin configuration for specific motherboard requirements.

Get inspired

With its high-brightness transmissive panel and flexible MIPI-DSI interface, this TFT LCD module is perfect for creating sleek, sunlight-readable displays for smartwatches, industrial control panels, or IoT dashboards.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Brightness350 nits+14% (400 nits)+20% (420 nits)*
Resolution480x480480x480480x480
CertificationsREACHREACH + FCCREACH + FCC + RoHS
Controller ICHX8379-CHX8379-C (enhanced)HX8379-C Pro
Temperature Range-20°C to 70°C-30°C to 80°C-40°C to 85°C

Supplier's note

  1. Three Technical Breakthroughs:

    • HX8379-C Controller: Delivers 20% faster data processing than legacy controllers, enabling smoother animations.
    • 400-nit Brightness: Outperforms industry standards (typically 300 nits) for superior outdoor visibility.
    • MIPI-DSI Interface: Supports 20% faster data transfer than parallel interfaces, reducing latency in real-time applications.

  2. Optimal Version Selection:

    • Base Model: Ideal for cost-sensitive projects (e.g., basic wearables) requiring standard certifications.
    • Advanced Model: Best for industrial IoT devices needing FCC compliance and wider temperature tolerance.
    • Pro Model: Perfect for extreme environments (e.g., automotive or aerospace) where durability and high brightness are critical. With its RoHS certification, it also meets stringent global regulatory demands.

Frequently asked questions

  • Which TFT LCD module suits wearable devices like smartwatches?

  • How to clean the TFT LCD screen without damaging the ribbon cable?

  • TFT vs OLED: Which is better for portable devices with certification requirements?

  • Can this TFT LCD module’s gradient color be customized for branding?

  • Is the TFT LCD module FCC and REACH certified for industrial use?

  • Does the MIPI-DSI interface work with Raspberry Pi or Arduino?

  • How does the transmissive type improve outdoor visibility?

  • Is the flexible ribbon cable resistant to frequent bending in wearable devices?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Display ResolutionSmartwatches, medical devices480x480 (HD) ▲ vs Industry Standard: 320x240 (QVGA)Higher clarity for detailed content (e.g., medical imaging)Increased power consumption compared to lower resolutions
Interface TypeMobile devices, IoT gadgetsMIPI-DSI (35-pin) ▲ vs Industry Standard: Parallel/LVDS interfacesFaster data transfer, lower power draw for mobile integrationRequires compatible hardware/drivers
CertificationsConsumer electronics (EU/US markets)REACH/FCC compliant ▲ vs Non-compliant alternativesEnsures regulatory compliance for global marketsHigher upfront certification costs
Display TechnologyWearables, industrial monitorsTFT LCD (HX8379-C controller) ▲ vs OLED/EPD alternativesWide viewing angles and stable performance in bright environmentsSlower refresh rates and higher power use vs OLED
Brightness/TransmissiveOutdoor devices, sunlight applications400 nits (transmissive) ▲ vs Industry Standard: 250–300 nitsSuperior visibility in direct sunlight (e.g., dashboards)Requires continuous backlighting (adds power draw)
Touchscreen IntegrationInteractive kiosks, tabletsCapacitive touch overlay ▲ vs Non-touch or resistive variantsAccurate multi-touch interaction for user interfacesAdds thickness/cost vs non-touch or basic resistive screens
