200mm Diameter Gantry Type Cnc Plasma Cutter Metal Pipe Cutting Machine for Cutting 6mm Thick Pipe

200mm Diameter Gantry Type Cnc Plasma Cutter Metal Pipe Cutting Machine for Cutting 6mm Thick Pipe

  • 1 - 49 Sets
    $15,000
  • 50 - 99 Sets
    $9,000
  • >= 100 Sets
    $4,990

Customization:

Customized logo（Min.Order: 1 pieces）
Customized packaging（Min.Order: 1 pieces）
Graphic customization（Min.Order: 1 pieces）
View product details

200mm Diameter Gantry Type Cnc Plasma Cutter Metal Pipe Cutting Machine for Cutting 6mm Thick Pipe

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Precision Plasma Cutting: Equipped with a high-precision plasma torch, this CNC machine specializes in cutting carbon steel pipes up to 6mm thickness with a 200mm diameter, ensuring clean edges and minimal material waste.
  • Automated Gantry System: The gantry-type design enables fully automatic operation, allowing for programmable cutting paths via CNC control to handle complex geometries and repetitive tasks efficiently.

Key features

  • 1. Corrosion-Resistant Metal Construction

    • With a durable steel and aluminum body, ensure long-lasting performance in industrial environments. The corrosion-resistant design extends lifespan by ~30% compared to standard models*.

  • 2. Programmable CNC Control System

    • With an intuitive CNC interface, automate precise cutting paths for consistent results. Reduces manual adjustments by up to 40% compared to traditional methods*.

  • 3. High-Power Cutting Efficiency

    • With 3kW rated power, effortlessly cut through 6mm thick carbon steel pipes. Achieves speeds up to 25% faster than manual cutters*.

  • 4. Versatile Gantry Design

    • With a rotating gantry and adjustable plasma torch, handle pipes up to 200mm in diameter. Ideal for industrial-scale applications requiring multi-angle cutting flexibility*.

  • 5. Enhanced Safety Compliance

    • With safety shields and interlocks, meet industrial safety standards for operator protection. Meets stricter safety protocols than basic models*.

Product details

200mm Diameter Gantry Type Cnc Plasma Cutter Metal Pipe Cutting Machine for Cutting 6mm Thick Pipe

The 200mm Diameter Gantry Type CNC Plasma Cutter is a high-precision industrial machine designed for automated cutting of carbon steel pipes up to 6mm thickness. With a robust gantry structure and advanced CNC control system, it delivers consistent performance in pipe fabrication, automotive manufacturing, and construction applications.

Technical specifications

FeatureSpecificationApplication Scenario
Gantry Diameter200mmCutting large-diameter pipes and structural components
Material CompatibilityCarbon steelIdeal for fabrication of steel pipes, frames, and tubing
Rated Power3kWEfficient energy consumption for sustained operation
Automation LevelFully automaticStreamlines production in high-volume manufacturing
Rotating Arm360° adjustable rangeEnables multi-angle cutting for complex geometries
CNC Control SystemProgrammable path planningCustomized cutting paths for precise designs
Safety FeaturesIntegrated shields + interlock systemEnsures operator safety during high-temperature plasma cutting

Customization guide

Adjustable parameters include torch head angle, gantry speed, and plasma output intensity to accommodate specialized pipe dimensions, material thickness, or surface finish requirements.

Get inspired

With its gantry design and automated plasma cutting technology, this machine empowers manufacturers to achieve clean, repeatable cuts on carbon steel pipes. Whether fabricating intricate automotive parts or structural components, this CNC plasma cutter ensures precision and efficiency.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Max Cutting Speed2.0 m/min+15% (2.3 m/min)+30% (2.6 m/min)*
Accuracy±0.1mm±0.08mm±0.05mm
Max Material Thickness6mm8mm10mm
Power3kW3.5kW4kW

Supplier's note

  1. Technical Breakthroughs:

    • The rotating arm enables multi-angle cutting, reducing repositioning time by 25%.
    • Plasma technology ensures minimal heat distortion, critical for thin-walled pipes.
    • Full automation cuts labor costs by 40% compared to manual plasma cutters.

  2. Version Selection Guide:

    • Base Model: Ideal for standard pipe fabrication shops needing reliable, cost-effective cutting of 6mm carbon steel.
    • Advanced Model: Suitable for medium-scale manufacturers requiring faster throughput (2.3 m/min) and thicker (8mm) material handling.
    • Pro Model: Best for heavy industrial applications where ultra-precision (±0.05mm) and 10mm material thickness are required.

*Pro Model’s 2.6 m/min speed exceeds industry benchmarks by 30%, enabling rapid production of complex pipe assemblies.

Frequently asked questions

  • Which CNC plasma cutter model suits small workshops for cutting 200mm diameter carbon steel pipes?

  • How to maintain the plasma torch on a metal pipe cutting machine for optimal performance?

  • Can the 200mm CNC plasma cutter handle stainless steel pipes alongside carbon steel?

  • Does the gantry-type CNC plasma cutter support custom cutting paths for pipe fabrication?

  • Is the 3kW rated power sufficient for cutting 6mm thick carbon steel pipes?

  • What safety certifications does the industrial pipe cutting machine have?

  • Can this CNC plasma cutter adjust for pipe diameters smaller than 200mm?

  • How does automation improve productivity for pipe cutting tasks?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
CNC Plasma CuttersPipe fabrication, construction projectsFull automation (ISO 9001), 6mm carbon steel (ASTM A36), 3kW (IEC 60038), ±0.1mm precision (ISO 10360), IP54 safety (IEC 60529)High precision ▲, reduces labor, handles complex cuts, cost-effective for medium-scale productionHigher initial cost, requires skilled operators, limited to conductive materials
Laser Cutting MachinesAerospace, intricate designs±0.05mm precision (ISO 10360), 20mm thickness (AWS C1.1), 5kW+ power (IEC 60038)Ultra-precise ▲, cuts non-conductive materials, versatile for complex shapesHigh operational costs, slower for thick materials, requires ventilation systems
Manual Pipe CuttersSmall-scale repairs, thin-walled pipesHandheld design, up to 25mm (ASME B31.1), portable, no power requiredLow cost, no electricity needed, easy to useLabor-intensive, low precision, limited to thin materials (≤25mm)
Hydraulic Pipe CuttersThick-walled pipes, construction sites2000 PSI force (ISO 6743), up to 100mm thickness (ASTM A53), durable buildHandles thick materials ▲, faster than manual methods, robust for heavy-duty useBulky design, requires hydraulic power, less precision compared to CNC systems
Flame Cutting MachinesThick metal plates, outdoor operationsUp to 500mm thickness (AWS D1.1), propane fuel (NFPA 58), portableCuts extreme thickness ▲, suitable for outdoor use, low maintenanceSlow process, produces slag, safety risks from open flames
Waterjet Cutting MachinesDelicate materials, complex shapes±0.1mm precision (ISO 10360), cuts any material (ISO 9001), no heat-affected zoneVersatile for any material ▲, no thermal distortion, ideal for non-ferrous metalsHigh operational costs, slow for thick materials, requires water recycling systems
