5331R XYZ Soldering Robot 5 Axis PCB Board LED Component Five Axis Robotic Soldering Machine for SMD

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Precision Soldering: Equipped with a five-axis robotic arm (X, Y, Z, and two rotational axes), enabling high-precision soldering of SMD components onto PCB boards and LED assemblies.
  • Automated Assembly: Designed to handle repetitive tasks such as placing, aligning, and soldering small electronic components with minimal human intervention.

Key features

  • 1. Advanced Material Technology

    • With a corrosion-resistant metallic frame, the 5331R ensures structural durability in industrial environments. This robust design withstands prolonged use and harsh conditions better than plastic-bodied models*, making it ideal for high-throughput manufacturing settings.

  • 2. Intuitive Interactive Design

    • Equipped with a digital control panel and programmable presets, you can quickly adjust soldering parameters for different SMD components. The emergency stop button and user-friendly interface reduce operational errors compared to manually controlled systems*.

  • 3. Precision Performance Parameters

    • The five-axis robotic head enables sub-millimeter positioning accuracy, delivering 20% faster soldering speeds than four-axis models*. This ensures flawless assembly of delicate PCB boards with tight component spacing.

  • 4. Versatile Scenario Solutions

    • Designed for both prototyping and mass production, the machine handles small-batch customization and high-volume manufacturing seamlessly. Its modular workstations adapt to diverse SMD component sizes and assembly workflows*.

  • 5. Compliance with Certification Standards

    • Certified to ISO safety standards and RoHS regulations, the 5331R guarantees eco-friendly operation and operator safety. This meets global manufacturing compliance requirements for electronics assembly*.

Product details

5331R XYZ Soldering Robot 5 Axis PCB Board LED Component Five Axis Robotic Soldering Machine for SMD

The 5331R XYZ Soldering Robot is a precision robotic assembly machine designed for high-precision SMD (Surface Mount Device) soldering on PCB boards. With its 5-axis robotic head and modular design, it offers customizable automation solutions for electronics manufacturing, ensuring accuracy, safety, and adaptability for diverse assembly needs.

Technical specifications

FeatureSpecificationBenefit
5-Axis Robotic HeadXYZ + 2 rotational axesEnables complex 3D component placement
Precision Control±0.02mm positioning accuracyEnsures flawless soldering on delicate PCBs
Modular WorkstationsAdjustable clamps for 10-50mm componentsSupports varied component sizes
Safety FeaturesEmergency stop, IP54-rated enclosuresProtects operators and equipment
Material CompatibilityHandles metal, plastic, and ceramic partsVersatile for mixed-component assemblies

Customization guide

Adjustable parameters:

  • Axis Range: Customize XYZ axis travel (up to 600mm) to fit PCB dimensions.
  • Tooling: Swap soldering tips or grippers for different SMD types.
  • Workstation Size: Modify clamping zones for large or small PCB batches.

Get inspired

With the 5331R’s 5-axis precision, automate repetitive SMD soldering tasks to reduce defects and labor costs. Ideal for electronics manufacturers needing reliable, scalable assembly solutions.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Positioning Accuracy±0.05mm±0.03mm±0.02mm*
Max Payload1.5kg2.0kg3.0kg
Cycle Time2.5s per joint2.0s (20% faster)1.8s (30% faster)*
Safety FeaturesEmergency stopIP54 + sensorsIP65 + AI collision detection

Supplier's note

  1. Technical Breakthroughs:

    • 5-Axis Motion: Enables complex PCB assembly without repositioning.
    • Modular Design: Reduces downtime by 40% via quick workstation swaps.
    • AI Safety: The Pro Model’s collision detection prevents 98% of accidental errors.

  2. Version Selection Guide:

    • Base Model: Ideal for small workshops assembling standard SMD components (e.g., resistors, capacitors).
    • Advanced Model: Suitable for medium-scale production needing faster cycles and IP54-rated durability.
    • Pro Model: Best for high-volume manufacturers requiring sub-0.03mm precision and industrial-grade safety (e.g., aerospace or medical electronics).

With the Pro Model’s triple-certified chemical resistance, operators can safely handle corrosive fluxes while its 3.0kg payload accommodates heavy-duty PCBs. Pair this with the AI collision detection to eliminate downtime—a key advantage for 24/7 production lines.
