5V9V12V15V24V Mini UPS Uninterruptible Power PCB Router Optical Cat Monitoring Backup Power Supply PCBA Circuit

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Uninterruptible Power Backup: Provides seamless power supply for devices during outages, supporting voltages of 5V, 9V, 12V, 15V, and 24V to ensure compatibility with routers, optical monitoring systems, and PC components.
  • Modular Circuit Design: Features a customizable PCB layout with adjustable voltage outputs and expandable components (e.g., potentiometers, ICs), enabling tailored solutions for specific applications.

Key features

  • 1. Advanced Material Technology

    • With FR-4 epoxy resin circuit boards and HASL (Hot Air Solder Leveling) surface finishing, ensure long-term durability and reliable performance in demanding environments. The corrosion-resistant materials maintain structural integrity even under frequent use or harsh conditions.

  • 2. Customizable Interactive Design

    • With adjustable potentiometers and a toggle power switch, customize voltage/current settings and control power delivery effortlessly. This modular design allows users to fine-tune parameters for specific applications, such as optimizing backup power for routers or surveillance systems.

  • 3. Versatile Performance Parameters

    • Supporting 5V–24V output voltages in a compact PCB form factor, this unit delivers compatibility with diverse devices while minimizing space requirements. Its multi-voltage capability outperforms single-output solutions for projects needing flexibility.

  • 4. Scenario-Specific Solutions

    • Provide uninterrupted power backup for critical electronics like routers, optical monitoring devices, and PCs during outages. The design prioritizes continuous operation for home or commercial use, ensuring minimal downtime for connected systems.

  • 5. Safety-Compliant Construction

    • Constructed with industry-standard materials (FR-4, insulated copper wires) and components, this PCB meets electrical safety requirements for reliable, low-risk operation. The toggle switch and modular wiring further enhance user safety during assembly and use.

Product details

5V9V12V15V24V Mini UPS Uninterruptible Power PCB Router Optical Cat Monitoring Backup Power Supply PCBA Circuit

The 5V/9V/12V/15V/24V Mini UPS PCB provides reliable backup power for routers, optical monitoring systems, and other critical electronics. Built with modular design and industrial-grade components, it ensures seamless operation during power outages while offering customizable voltage outputs and robust durability.

Technical specifications

FeatureSpecificationBenefit
MaterialFR-4 epoxy laminate (main and secondary circuit boards)High thermal stability and electrical insulation for long-term reliability
Surface FinishingHASL (Hot Air Solder Leveling)Enhanced solder joint durability and compatibility with automated assembly
Voltage Outputs5V, 9V, 12V, 15V, 24V (adjustable via potentiometers)Versatile compatibility with diverse electronic devices and systems
ComponentsResistors, capacitors, inductors, ICs, LED indicator, toggle switchModular design allows customization for specific power management needs
WiringInsulated copper wires (blue/black)Safe and efficient power delivery with standard industry color coding
CertificationMeets RoHS and UL safety standardsEnsures compliance with global electronics manufacturing regulations

Customization guide

Adjustable voltage outputs (via potentiometers) and modular component slots allow users to tailor the PCB for specialized applications. For example:

  • Custom voltage ranges: Modify output settings to match device requirements (e.g., 9V for sensors, 24V for industrial actuators).
  • Component expansion: Add capacitors or inductors to enhance energy storage or filtering capabilities.
  • Functionality upgrades: Integrate additional ICs for advanced power monitoring or fault detection.

Get inspired

Ideal for safeguarding IoT devices, network routers, or optical monitoring systems during power fluctuations. Its compact design and customizable voltage options make it a flexible solution for DIY projects, small businesses, or industrial automation setups.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Voltage Range5V-12V5V-24V5V-24V (full-range tuning)
Backup Time15 minutes30 minutes60 minutes*
Efficiency85% (vs. industry avg.)90% (+5% improvement)95% (+10% improvement)*
Component DensityStandardEnhanced (extra capacitors)Premium (dual IC redundancy)

Supplier's note

  1. Technical Breakthroughs:

    • FR-4 + HASL: Combines thermal resistance and corrosion protection, outperforming traditional PCB materials in harsh environments.
    • Modular Potentiometers: Enable field-adjustable voltage outputs without re-engineering the circuit.
    • UL-certified safety features: Exceeds industry benchmarks for fault tolerance and surge protection.

  2. Version Selection Guidance:

    • Base Model: Best for hobbyists or small-scale projects requiring basic 5V-12V backup (e.g., Raspberry Pi setups).
    • Advanced Model: Targets SMEs needing 24V support and longer runtime for security cameras or sensors.
    • Pro Model: Designed for industrial users demanding uninterrupted power (e.g., factory automation systems). Its 95% efficiency reduces energy waste by 20% compared to legacy UPS systems.

*Pro Model’s 60-minute backup and 95% efficiency exceed industry standards by 30% and 10%, respectively.

Frequently asked questions

  • Which 5V-24V Mini UPS PCBA model suits small office routers or optical devices?

  • How to clean and maintain the PCB components for longevity?

  • FR-4 vs other PCB materials: Why is it best for industrial use?

  • Can I customize the voltage or add sensors to the Mini UPS PCBA?

  • Is the Mini UPS PCBA circuit FDA/CE/RoHS certified for safety?

  • What’s the backup duration for Cat monitoring systems using this UPS?

  • How do I install this PCBA circuit in a router or optical device?

  • Does the Mini UPS handle extreme temperatures for industrial use?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Voltage Output StabilityData centers, industrial automation±2% (IEC 61000-3-2 Class D) ▲
Industry: ±5%, Base: ±3%		Ensures stable power for sensitive equipmentHigher cost due to advanced regulation components
Backup DurationServers, IoT devices60 mins (IEC 62034) ▲
Industry: 15 mins, Base: 30 mins		Extended uptime during power outagesLarger battery increases size/weight
Noise LevelOffice environments, home labs35 dBA (ISO 3744) ▲
Industry: 45 dBA, Base: 40 dBA		Quieter than a whisper (35 dBA)Passive cooling limits high-temperature performance
EfficiencyRenewable energy systems92% (ENERGY STAR® certified) ▲
Industry: 85%, Base: 90%		Reduces energy waste by 20%+Advanced components add to manufacturing complexity
Surface FinishingHigh-reliability electronics manufacturingENIG (Electroless Nickel Immersion Gold) ▲
Industry: HASL, Base: HASL		30% better corrosion resistance (per ASTM B542)ENIG requires specialized soldering techniques
ModularityDIY projects, prototypingHot-swappable components (customizable via JST connectors)Easily integrates sensors/actuators (e.g., Arduino compatibility)Requires soldering skills for configuration adjustments
