Adjustable Orifice Plate

Adjustable Orifice Plate

$899.00-$899.00/ Set|1 Set/Sets(Min. Order)
View product details

Adjustable Orifice Plate

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Flow Measurement Precision: Measures liquid and gas flow with 1.0% accuracy, enabling reliable data collection in industrial and commercial settings.
  • Adjustable Orifice Design: Flange-mounted configuration allows customization of flow rates and pressure differentials, adapting to varying operational requirements.

Key features

  • 1. Corrosion-Resistant Material Technology

    • With a corrosion-resistant polymer body (e.g., polypropylene), you can ensure durable performance in harsh industrial environments, outlasting traditional metal-based orifice plates in chemical exposure scenarios*.

  • 2. Adjustable Orifice Design for Versatility

    • With an adjustable orifice design, you can achieve precise flow control without recalibration, eliminating the need to replace fixed orifice plates for different flow rates*.

  • 3. High Accuracy and Compatibility

    • With 1.0% measurement accuracy and dual output (4-20mA/pulse), you can deliver precise data for both industrial monitoring systems and legacy control panels, 20% more accurate than standard orifice plates*.

  • 4. Modular Flange Integration for Industrial Use

    • With a flange connection and modular design, you can seamlessly integrate into pipelines for liquid/gas applications, adapting to diverse industrial setups like chemical processing or HVAC systems*.

  • 5. EPR Germany Certified Sustainability

    • With EPR Germany certification, you can meet strict environmental regulations for packaging and disposal, ensuring compliance in eco-conscious industries compared to non-certified alternatives*.

Product details

Adjustable Orifice Plate

The Adjustable Orifice Plate is a precision flow measurement device designed for industrial applications requiring accurate fluid or gas flow regulation. Its flange-mounted design ensures secure integration into pipelines, while its corrosion-resistant polypropylene material and EPR Germany certification guarantee reliability in harsh environments.

Technical specifications

FeatureSpecificationApplication Scenario
MaterialPolypropylene (blue)Corrosion-resistant applications in chemical or water treatment plants
Accuracy±1.0% of readingPrecise flow measurement in oil/gas pipelines
Connection TypeFlange-mountedSecure integration into industrial piping systems
Medium CompatibilityLiquid/GasVersatile use in HVAC systems or fluid distribution networks
Output Signal4-20mA, PulseReal-time data transmission to SCADA systems
Power Source220VAC, 24VDCFlexible power options for diverse installations
CertificationEPR_Germany_PackingCompliance with EU safety and packaging standards

Customization guide

Adjustable orifice size and flange dimensions to meet specific pipe diameter requirements. The modular bolt-and-nut design allows easy adaptation to custom pipeline configurations.

Get inspired

With its flange-mounted design and precise accuracy, this orifice plate ensures reliable flow control in demanding industrial environments. Whether managing liquids in chemical plants or gases in energy systems, its robust construction and versatile outputs simplify integration into existing infrastructure.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Accuracy±1.0%±0.5%±0.25%
Max Pressure100 bar150 bar (+50%)200 bar (+100%)
MaterialPolypropyleneStainless Steel 316High-Carbon Alloy

Supplier's note

  1. Technical Breakthroughs:

    • Precision Accuracy: The Pro Model’s ±0.25% accuracy exceeds industry standards, enabling ultra-precise flow control in pharmaceutical or semiconductor applications.
    • Material Advancement: The Advanced Model’s stainless steel 316 body provides 30% higher corrosion resistance than polypropylene, ideal for marine or acidic environments.
    • Modular Design: Adjustable orifice plates allow users to customize flow rates on-site, reducing downtime compared to fixed-plate systems.

  2. Version Selection Guide:

    • Base Model: Suitable for general industrial use (e.g., water treatment) where cost efficiency is prioritized.
    • Advanced Model: Recommended for food processing or oil/gas industries needing enhanced durability and moderate precision.
    • Pro Model: Best for high-pressure chemical plants or aerospace testing, where extreme accuracy and corrosion resistance are critical.

With the Pro Model’s 200 bar pressure rating, you can safely handle high-stress applications like hydraulic systems. Pair its alloy material with 4-20mA output for seamless automation in smart factories.
