Automatic Field Coil Winding Machine for Stator Coils Electric Precision Coil Winding Equipment With Advanced Technology

Technical specifications

Customization guide

Adjustable parameters include:

• Winding Diameter: Customize to fit 10–50mm coil sizes for diverse applications.
• Speed Settings: Optimize cycle time (5–30 RPM) to match production demands.
• Material Compatibility: Configure feeders for copper, aluminum, or composite wires.
  With modular design, users can expand stations or integrate sensors for real-time quality checks.

Get inspired

Enhance your production line with this precision winding machine. Whether manufacturing small electric motors or large industrial transformers, its automation and accuracy ensure consistent coil quality. Pair it with advanced material feeds for 24/7 operation or upgrade to Pro models for aerospace-grade tolerances.

Choose your model

Supplier's note

1. Technical Breakthroughs:

   • CNC Automation: Enables complex winding patterns with ±0.005mm precision (Pro model), reducing defects by 90%.
   • Modular Design: Stations can be reconfigured in 2 hours, cutting downtime vs. fixed systems.
   • Dual-Speed Motors: Base model’s 15 RPM ensures reliability, while Pro’s 30 RPM outperforms industry benchmarks by 20%.

2. Version Selection Guide:

   • Base Model: Ideal for SMEs producing standard motors (e.g., HVAC systems) with limited budgets.
   • Advanced Model: Choose for automotive or robotics applications needing 15μm tolerance and 4-channel feeds.
   • Pro Model: Required for aerospace or medical devices where ±0.005mm precision and RoHS compliance are critical.
     Example: With the Pro’s advanced tolerance, you can wind stator coils for turbine generators that withstand extreme thermal cycles. Pair its 6-channel feed with high-conductivity copper to achieve 20% lower energy losses.
