Automatic Toroidal Filter Coil Winding Machine,transformer Big Toroid Core Coil Winding Machine

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Automatic Toroidal Coil Winding: Precision-engineered to automate the winding of filter coils around large toroid cores for transformers, ensuring consistent and high-quality output.
  • Versatile Core Adaptation: Designed to handle various sizes and shapes of toroidal cores via adjustable components and a central circular mounting structure, optimizing compatibility with diverse manufacturing needs.

Key features

  • 1. Corrosion-Resistant Steel Construction

    • With a robust steel body treated for corrosion resistance, you can ensure long-term durability in industrial environments. The 5-year warranty surpasses industry standards*, offering peace of mind for continuous operation.

  • 2. Programmable Touchscreen Interface

    • With an intuitive touchscreen control panel, you can preset winding parameters and store multi-program configurations, streamlining workflows compared to manual models*. This design reduces setup time and enhances operational precision.

  • 3. High-Speed Automatic Winding

    • With advanced motorized winding capabilities, you can achieve output speeds up to 25% faster than traditional manual systems*, enabling rapid production cycles for large-scale manufacturing demands.

  • 4. Adaptable Core Compatibility

    • With adjustable core holders and precision alignment features, you can accommodate a wide range of toroid core sizes and shapes, making it versatile for both prototyping and commercial production scenarios*.

  • 5. ISO-Certified Quality Assurance

    • With compliance to ISO 9001 quality management standards, you can ensure consistent precision and safety in coil winding processes, meeting rigorous industrial certification requirements*.

Product details

Automatic Toroidal Filter Coil Winding Machine,transformer Big Toroid Core Coil Winding Machine

The Automatic Toroidal Filter Coil Winding Machine is a high-precision industrial solution designed for efficient and automated winding of toroidal transformer cores. Built with robust steel construction and a programmable control system, it ensures durability, accuracy, and adaptability for diverse manufacturing needs. With a 5-year warranty, it guarantees long-term reliability in demanding production environments.

Technical specifications

FeatureSpecificationBenefit
MaterialSteel construction with metal componentsEnhanced durability and longevity
Control SystemProgrammable touchscreen interfacePrecise parameter adjustment for complex tasks
Winding Precision±0.1mm toleranceConsistent coil alignment for high-quality outputs
Core CapacityAdjustable for 50–300mm diameter coresVersatility for varying toroid sizes
Winding Speed0–150 RPM programmableBalances speed and precision for production needs
CertificationCE, ISO 9001Compliance with global industrial standards

Customization guide

Adjustable parameters include coil diameter range, winding speed, and material thickness tolerance to meet specific production requirements. Ideal for customizing setups for varying core geometries or high-volume manufacturing demands.

Get inspired

With its programmable control system, you can optimize winding patterns for intricate toroid designs. The robust steel frame ensures stability even under heavy loads, while the adjustable core capacity lets you handle projects from small prototypes to industrial-scale cores.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Winding Speed0–100 RPM0–125 RPM (+25%)0–150 RPM (+50%)*
Tolerance±0.2mm±0.15mm±0.1mm
Core Diameter Range50–200mm50–250mm50–300mm
Load Capacity50kg75kg (+50%)100kg (+100%)
Automation LevelSemi-automatedFully automatedAI-assisted adaptive

Supplier's note

  1. Technical Breakthroughs:

    • Steel Construction: Provides unmatched durability for harsh industrial environments.
    • Programmable Control: Enables precise winding patterns, reducing human error by 40% compared to manual systems.
    • Adaptive Core Capacity: Accommodates a 60% wider range of toroid sizes than traditional models.

  2. Version Selection Guidance:

    • Base Model: Ideal for small-to-medium workshops requiring cost-effective, semi-automated winding for standard cores (e.g., 50–200mm).
    • Advanced Model: Recommended for mid-scale manufacturers needing faster speeds (+25% RPM) and broader core compatibility (up to 250mm).
    • Pro Model: Best for high-volume production lines handling large cores (300mm) and requiring AI-driven precision (e.g., aerospace or power grid components).

*Pro Model’s 50% speed boost enables 20% faster production cycles than industry benchmarks.
